READ THIS MANUAL CAREFULLY!
It contains important safety information.
NOTICE: The removal or modification of evaporative
emission-related parts on this OHRV is illegal.
Violators may be subject to civil and/or criminal
penalties as provided under California and federal law.
OWNER'S MANUAL
YXF10WPZM/YXF10WPAM
LIT-11626-34-02
B4J-F8199-10

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WOLUERINE RMAX and is the answer not in the manual?

Questions and answers

Related Manuals for Yamaha WOLUERINE RMAX

Summary of Contents for Yamaha WOLUERINE RMAX

  • Page 1 READ THIS MANUAL CAREFULLY! It contains important safety information. NOTICE: The removal or modification of evaporative emission-related parts on this OHRV is illegal. Violators may be subject to civil and/or criminal penalties as provided under California and federal law. OWNER’S MANUAL YXF10WPZM/YXF10WPAM LIT-11626-34-02 B4J-F8199-10...
  • Page 2 EBU31032 Operating, servicing and maintaining a passenger vehicle or off-road vehicle can expose you to chemicals including engine exhaust, carbon monoxide, phthalates, and lead, which are known to the State of California to cause cancer and birth defects or other reproductive harm. To minimize exposure, avoid breathing exhaust, do not idle the engine except as necessary, service your vehicle in a well-ventilated area and wear gloves or wash your...
  • Page 3 Congratulations on your purchase of the Yamaha YXF10WPZM / YXF10WPAM. It represents the result of many years of Yamaha experience in the production of fine sporting, touring, and pace- setting racing vehicles. With the purchase of this Yamaha, you can now appreciate the high de- gree of craftsmanship and reliability that have made Yamaha a leader in these fields.
  • Page 4 EBU31080 IMPORTANT MANUAL INFORMATION EBU31070 FAILURE TO FOLLOW THE WARNINGS CONTAINED IN THIS MANUAL CAN RESULT IN SERI- OUS INJURY OR DEATH. Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to poten- tial personal injury hazards.
  • Page 5  This vehicle complies with all state off-highway noise level and spark arrester laws and regulations. EBU31111 YXF10WPZM / YXF10WPAM OWNER’S MANUAL ©2021 by Yamaha Motor Corporation, U.S.A. 1st edition, March 2020 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Corporation, U.S.A.

  • Page 6: Table Of Contents

    On–Command drive knob EBU31120 CONTENTS “2WD/4WD/DIFF. LOCK” ....5-16 D-mode knob VEHICLE IDENTIFICATION ..... 1-1 “SPORT/TRAIL/CRAWL” Identification numbers......1-1 (YXF10WPZM) ........5-17 Accelerator pedal ....... 5-18 LOCATION OF THE WARNING AND Brake pedal ........5-19 SPECIFICATION LABELS ....... 2-1 Parking brake lever ......5-19 Drive select lever ........
  • Page 7 Trailer hitch bracket and receiver..5-37 OPERATION ..........7-1 Auxiliary DC jacks....... 5-38 Engine break-in........7-1 Auxiliary DC connectors..... 5-39 Starting the engine .......7-2 Yamaha Adventure Pro powered by ® Drive select lever operation and Magellan ......... 5-40 reverse driving ........7-3 FOR YOUR SAFETY –...
  • Page 8 Engine oil and oil filter ......9-11 Parking brake lever free play Why Yamalube ........9-19 adjustment ........9-42 Transmission oil ......... 9-20 Brake light switch adjustment ....9-43 Continuously Variable Transmission Cable inspection and lubrication ..9-44 (CVT) ..........9-23 Pedal lubrication .........9-44 Final gear oil ........
  • Page 9 Vehicle Emission Control Information label ..........12-1 Emission Regulation (California)..12-1 Vehicle data recording ....... 12-1 NOISE REGULATION ......12-3 MAINTENANCE RECORD ....12-4 YAMAHA MOTOR CORPORATION, U.S.A. 2020 AND LATER MODEL SIDE-BY-SIDE LIMITED WARRANTY........12-5 YAMAHA EXTENDED SERVICE (Y.E.S.) ..........12-7...

  • Page 10: Vehicle Identification

    EBU38890 VEHICLE IDENTIFICATION EBU32781 EBU32800 Vehicle identification number Identification numbers The vehicle identification number is stamped Record the vehicle identification number, into the frame. model label information and key identification number in the spaces provided below. VEHICLE IDENTIFICATION NUMBER: MODEL LABEL INFORMATION: 1.
  • Page 11 * * * * - * * * 1 1 1 1. Model type code 2. Production code 1. Model label 3. Color code Your specific model can be identified by EBU32790 Key identification number checking the model type code found on the The key identification number is stamped on model label.
  • Page 12 1. Key identification number...

  • Page 13: Location Of The Warning And Specification Labels

    EBU31130 LOCATION OF THE WARNING AND SPECIFICATION LABELS 1 1 1...
  • Page 15 Read and understand all of the labels on your vehicle. They contain important information for safe and proper operation of your vehicle. Never remove any labels from your vehicle. If a label becomes difficult to read or comes off, a replacement label is available from your Yamaha dealer.
  • Page 16 WARNING Improper use of cargo area, rear seats, and/or cage/frame Never carry can result in severe passengers injury or death from in cargo bed. loss of control, overturn or other accidents. Maximum Load for total of Rear Passengers and Cargo: 600 lbs (272 kg) Maximum Vehicle Load: 1124 lbs (510 kg) •...
  • Page 17 This unit contains high pressure nitrogen gas. requirements for rollover protection structures Mishandling can cause explosion. m=950Kg for ISO3471 Read owner’s manual for instructions. Do not incinerate, puncture or open. YAMAHA MOTOR CORPORATION U.S.A. B4M-F2259-00 6555 Katella Avenue, Cypress, California 90630-5101, U.S.A. B4J-F4164-00 6 YXF10WPZM...
  • Page 18 WARNING YAMAHA MOTOR CORPORATION U.S.A. certifies this ROV complies with the American National Standard for Recreational • Improper tire pressure or overloading this vehicle may Off-Highway Vehicles, ANSI/ROHVA-1-2016 Standard. cause severe injury or death from loss of control or Date of manufacture **/** rollover.
  • Page 19 PREMIUM UNLEADED GASOLINE ONLY WARNING 91 Min. Pump Octane (R+M) / 2 1TD-F415E-00 Improperly loading a trailer or pulling an object can affect handling, stability, and risk of overturn or other accidents. • Secure load to prevent it from shifting. •...
  • Page 20 WARNING Improper Use of Off-Highway Vehicle Can Cause Severe Injury or Death Be Prepared • Fasten seat belts. • • Wear an approved helmet, eye protection • and protective gear. • • Driver must be able to comfortably reach all •...
  • Page 21 WARNING Improper Use of Off-Highway Vehicle Can Cause Severe Injury or Death WARNING Be Prepared Pay Attention and Plan Ahead Improper Use of Off-Highway • Fasten seat belts. If you think or feel the vehicle Wear an approved may tip or roll, reduce your Vehicle Can Cause Severe Injury •...

  • Page 22: Safety Information

    Wolverine RMAX4. While understanding all parts of this manual are important for vehicle owner- ship, be sure to read this chapter and the instructions in Chapter 8 before operating your Yamaha Wolverine RMAX4. Also use these two chapters and the labels on the vehicle to instruct new op- erators and passengers.
  • Page 23 DRIVER UNDER • This vehicle is designed to carry the driver and three passengers. Never carry passengers in the cargo bed. • The driver and passengers should wear seat belts properly. • The driver and passengers must be able to put both feet flat on the floorboard while seated upright with their backs against the backrests.
  • Page 24  Secure cargo so that it will not shift – a loose load could change handling unexpectedly or be thrown forward and strike occupants. While using your Yamaha Wolverine RMAX4  Keep your body completely inside the vehicle at all times. Keep both hands on the steering wheel.
  • Page 25  Abrupt maneuvers or aggressive driving, even on flat, open areas, can cause loss of control, including rollovers. The Wolverine RMAX4 has higher ground clearance and other features to handle rugged terrain, and, as a result, can overturn in situations where some other vehicles may not.
  • Page 26 • Avoid paved surfaces. Turn gradually and go slowly if you must drive on pavement. This vehicle is designed for off-road use only.  If you think or feel that the vehicle may tip or roll, keep your body completely inside the protec- tive structure of the vehicle: •...
  • Page 27 Genuine Yamaha Accessories Choosing accessories for your Wolverine RMAX4 is an important decision. Genuine Yamaha Ac- cessories, which are available only from a Yamaha dealer, have been designed, tested, and ap- proved by Yamaha for use on your Wolverine RMAX4.
  • Page 28 Many companies with no connection to Yamaha manufacture parts and accessories or offer oth- er modifications for Yamaha vehicles. Yamaha is not in a position to test the products that these aftermarket companies produce. Therefore, Yamaha can neither endorse nor recommend the use of accessories not sold by Yamaha or modifications not specifically recommended by Yamaha, even if sold and installed by a Yamaha dealer.

  • Page 29: Description

    EBU31170 DESCRIPTION EBU31180 Left view 2,3 4 1. Winch (YXF10WPZM) 7. Door 2. Fuses 8. Engine oil tank 3. Battery 9. Coolant reservoir 4. Air filters 10.Brake fluid reservoir 5. Shoulder bolster 11.Front shock absorber assembly 6. Seat belt...

  • Page 30: Right View

    EBU31190 Right view 1. Brake/tail light 2. Cargo area 3. Seat belt 4. Fuel tank cap 5. Transmission oil dipstick 6. Oil filter cartridge 7. Rear shock absorber assembly 8. Spark arrester...

  • Page 31: Controls And Instruments

    EBU31200 Controls and instruments 6 7 8 1. Speed Management System switch 10.Glove compartment 2. Steering wheel 11.USB jack (YXF10WPZM) 3. Multi-function meter unit 12.Drive select lever 4. Main switch 13.Parking brake lever 5. D-mode knob (YXF10WPZM) 14.Accelerator pedal 6. Winch switch (YXF10WPZM) 15.Brake pedal 7.
  • Page 32 2 2 2 1. Rear passenger handhold 2. Auxiliary DC jack (YXF10WPZM) The vehicle you have purchased may differ slightly from those shown in the figures of this man- ual.

  • Page 33: Instrument And Control Functions

    EBU3121C INSTRUMENT AND CONTROL The operation of the indicator and warning FUNCTIONS lights, and the multi-function meter can be EBU31221 confirmed at this time. Main switch EBU31241 Off position “ ” All electrical circuits are switched off. The key can be removed. EBU31251 Start position “...

  • Page 34: Indicator Lights And Warning Lights

    EBU31268 EBU39290 Low-range indicator light “ ” Indicator lights and warning lights This indicator light comes on when the drive select lever is in the “L” position. EBU39300 High-range indicator light “ ” This indicator light comes on when the drive select lever is in the “H”...
  • Page 35 EBU39340 High beam indicator light “ ”  See pages 5-16 and 7-6 for more informa- This indicator light comes on when the high tion on selecting the drive mode. beam of the headlight is switched on.  Due to the synchronizing mechanism in the EBU39351 differential gear case, the drivetrain icon Differential gear lock indicator light “...
  • Page 36 If the warning light does not go off, light remains on, have a Yamaha dealer stop the engine and allow it to cool. (See page check the vehicle.
  • Page 37 Yamaha dealer check the EPS system. display will indicate an error code (see page The electrical circuit of the warning light can 5-12). Have a Yamaha dealer check the self- be checked by turning the key to “ ” (on). If diagnosis system.

  • Page 38: Multi-Function Meter Unit

    EBU39390 Battery voltage warning light “ ” seat belt is properly latched, have a Yamaha This warning light comes on if the detected dealer check the electrical circuit. battery voltage is less than 10 volts, or greater than 18 volts.
  • Page 39 The multi-function meter unit is equipped with tween “MPH” and “km/h”, turn the key the following: to “ ” (off), then while holding the “SELECT”  speedometer button pushed, turn the key to “ ” (on).  odometer Odometer and tripmeters ...
  • Page 40 single trip, or to estimate the distance that Clock, hour meter, voltage display and can be traveled with a full tank of gas, etc. The coolant temperature display service tripmeter shows the distance traveled since it was reset at the last maintenance. Push the “SELECT”...
  • Page 41 “Hi”, there may be trouble with the battery 6. Push the “SELECT” button, and then re- charging circuit or the battery may be lease it to start the clock. faulty. If this occurs, have a Yamaha dealer check or repair the vehicle.
  • Page 42 Coolant temperature display  The coolant temperature display can be set to “°C” or “°F”. To switch the temperature units, turn the key to “ ” (off), then while holding the “RESET” button pushed, turn the key to “ ” (on). ...
  • Page 43 Fuel gauge If the electrical circuit for the fuel gauge is not working correctly, all display segments will flash repeatedly. Have a Yamaha dealer check the vehicle. D-mode indicator 1. Fuel gauge The fuel gauge indicates the amount of fuel in the fuel tank.
  • Page 44 To adjust the brightness 1. Push the “SELECT” button until the  When the Speed Management System brightness level is displayed. switch (page 5-13) is set to the “ ” (on) 2. Use the “RESET” button to set the bright- position, the D-mode function is deactivat- ness level.

  • Page 45: Speed Management System

    If a problem is detected in any of those cir- cuits, the warning lights will come on or flash, and the display will indicate an error code. If the display indicates an error code, note the code number and have a Yamaha dealer check the vehicle. ECB00812 NOTICE...
  • Page 46 6. Turn the main switch to “ ” (on) and confirm that the speed management icon comes on. (See page 5-10.) The main switch must be turned to “ ” (off) and then back to “ ” (on) before Speed Management System changes are recog- nized by the vehicle.

  • Page 47: Light Switch

    that the electric starter will not have EBU39410 Light switch “ ” enough power to crank the engine. If this should happen, remove the battery and re- charge it. EBU39431 Winch switch “ ” (YXF10WPZM) 1. Light switch “ ” Set the switch to “...

  • Page 48: On-Command Drive Knob "2Wd/4Wd/Diff. Lock

     “DIFF. LOCK” (four–wheel drive with the EBU39121 On–Command drive knob differential gear locked): Power is supplied “2WD/4WD/DIFF. LOCK” to the front and rear wheels with the differ- ential gear locked. Unlike standard four– wheel drive, all wheels turn at the same speed regardless of traction.

  • Page 49: D-Mode Knob "Sport/Trail/Crawl" (Yxf10Wpzm)

    EBU39441 EWB04380 D-mode knob WARNING “SPORT/TRAIL/CRAWL”  Confirm what mode is selected before (YXF10WPZM) starting off.  Before changing the D-mode, be sure to stop the vehicle and take your foot off the accelerator pedal. Mode “TRAIL” Mode “TRAIL” offers smooth acceleration, linear engine response and strong engine braking.

  • Page 50: Accelerator Pedal

    Mode “CRAWL” EBU31413 Accelerator pedal Mode “CRAWL” offers the most gentle en- gine response. This mode is suitable for situ- ations that require sensitive throttle operation, such as rock crawling or muddy trails. When the Speed Management System switch is set to the “ ”...

  • Page 51: Brake Pedal

    EBU37650 Brake pedal When the brake pedal is pressed and then the accelerator pedal is pressed, the brake over- ride system will not engage. EBU35642 Parking brake lever 1. Brake pedal Press the brake pedal to slow and stop the vehicle.

  • Page 52: Drive Select Lever

    To release the parking brake, pull slightly on The drive select lever is used to shift the the lever, press the release button, and then transmission into the low, high, neutral, and push the lever to its original position. reverse positions. (See page 7-3.) EBU39450 ...

  • Page 53: Fuel Tank Cap

    Remove the fuel tank cap when refueling. To open, turn counterclockwise. When finished When driving under heat-stress conditions, it refueling, install the fuel tank cap by screwing is recommended to reduce throttle at regular it down clockwise. intervals to allow the V-belt to cool. EBU37390 ECB03900 Doors...

  • Page 54: Passenger Seat Cushion

    Front door Rear door 1. Handle 1. Handle 2. Door 2. Door EBU37600 Passenger seat cushion To remove the passenger seat cushion, lift the front of the cushion, and then pull the cushion off. 5-22...

  • Page 55: Adjusting The Driver Seat Position

    1 1 1 1. Passenger seat cushion EBU34993 To install the seat cushion, insert the projec- Adjusting the driver seat position tions on the rear of the seat cushion under the The driver seat position can be adjusted to seat frame, and then insert the projection on suit the driver’s preference.

  • Page 56: Adjusting The Steering Wheel Position

    while operating the vehicle, otherwise the steering wheel may suddenly change posi- tion, which may lead to an accident. [EWB04000] To adjust the steering wheel position, pull the 2 2 2 steering wheel position adjusting lever and move the steering wheel to the desired posi- tion.

  • Page 57: Rearview Mirror (Yxf10Wpzm)

    EBU36953 EBU36184 Rearview mirror (YXF10WPZM) Seat belts Front seat belts 1. Rearview mirror (YXF10WPZM) Rear seat belts Adjust the rearview mirror before starting off. 5-25...

  • Page 58: Glove Compartment

    Always wear the seat belts properly while rid- Store lightweight or frequently used items, ing in the vehicle. (See page 8-5.) such as your driving gloves or vehicle docu- ments, in this compartment.  If the vehicle is driven without the driver Glove compartment load limit: 5.0 kg (11 lb) seat belt fastened, a buzzer will sound.

  • Page 59: Cup Holders

    ECB02241 NOTICE To protect from damage, do not put metal items, like tools, or sharply edged items di- rectly in the storage compartment. If these items must be stored, wrap them in appro- priate cushioning material. 1 1 1 1. Storage compartment (center console) Maximum load limit: Center console storage compartment: 3.5 kg (7.7 lb)
  • Page 60 Front cup holders EWB03240 WARNING 1 1 1  Never ride with any open or glass con- tainers in the cup holders; otherwise, the contents may spill and the glass contain- ers may be thrown about and break, and possibly injure people in the vehicle dur- ing sudden braking or an accident.

  • Page 61: Cargo Bed

     Do not exceed the specified maximum EBU37592 Cargo bed load limits. Heavier cargo could cause The rear passenger seats fold up and slide loss of control because of improper forward. weight balance. Cargo area maximum load: 272.0 kg (600 (Total weight of rear passengers and cargo) Use the cargo hooks to tie down loads.
  • Page 62 Moving a rear seat forward 1. Pull the rear of the seat cushion to lift it 1. Seat lock lever 3. Remove the seat belt buckle storage compartment cover and place the buck- les in the compartment. 2. While pulling the seat lock lever, slide the seat forward completely until it locks in place.
  • Page 63 Moving a rear seat to its original position 1. Open the seat belt buckle storage com- partment cover and lift up the seat belt buckles. 1. Seat belt buckle storage compartment cover 1. Buckle 2. Install the seat belt buckle storage com- partment cover.

  • Page 64: Front And Rear Shock Absorber Assemblies

    Opening and closing the tailgate To close Lift the tailgate to the original position, and then push the tailgate to securely lock it in place. EBU39681 Front and rear shock absorber assem- blies The shock absorber assemblies are equipped with a spring preload adjusting nut and a compression damping force adjuster.
  • Page 65  A special wrench can be obtained at a 2. Loosen the locknut. Yamaha dealer to make this adjustment. 3. Turn the spring preload adjusting nut in  The spring preload setting is determined by direction (a) to increase the spring pre-...
  • Page 66 Front spring preload setting: Minimum (soft): Distance A = 519.3 mm (20.44 in) Standard: Distance A = 509.3 mm (20.05 in) Maximum (hard): Distance A = 499.3 mm (19.66 in) Rear spring preload setting: Minimum (soft): Distance A = 475.2 mm (18.71 in) 1.
  • Page 67 Compression damping force Compression damping force settings: To increase the compression damping force Minimum (soft): and thereby harden the compression damp- Standard: ing, turn the compression damping force ad- juster in direction (a). To decrease the Maximum (hard): compression damping force and thereby soften the compression damping, turn the adjuster in direction (b).

  • Page 68: Winch (Yxf10Wpzm)

    Winch Owner’s Manual pri- Take the shock absorber assembly to a or to use. Never let anyone come between Yamaha dealer for any service. the winch and pulled object or the winch and anchor point. Do not use the winch un-...

  • Page 69: Trailer Hitch Bracket And Receiver

    2. Receiver This vehicle is equipped with a trailer hitch bracket and a 2" (5 cm) receiver for a stan- dard trailer hitch. Trailer towing equipment can be obtained at a Yamaha dealer. See page 7-8 for loading information. 5-37...

  • Page 70: Auxiliary Dc Jacks

    EBU39572 Auxiliary DC jacks 1. USB jack (YXF10WPZM) YXF10WPAM: 1. Front auxiliary DC jack This vehicle is equipped with a 12-V DC jack in the dashboard. YXF10WPZM: This vehicle is equipped with two 12-V DC jacks, one in the dashboard and one in front of the rear left passenger seat.

  • Page 71: Auxiliary Dc Connectors

    EBU39460  When the auxiliary DC jack is not being Auxiliary DC connectors used, cover it with the cap. This vehicle is equipped with auxiliary DC connectors. Consult your Yamaha dealer be- fore installing any accessories. 5-39...

  • Page 72: Yamaha Adventure Pro Powered By Magellan

    This vehicle is equipped with a connector for a GPS and navigation display. See your Yamaha dealer or visit shopyamaha.com for details. YXF10WPZM: This vehicle is equipped with Yamaha Adven- ® ture Pro powered by Magellan . Read the Yamaha Adventure Pro Owner’s Manual for more information.

  • Page 73: For Your Safety - Pre-Operation Checks

    Failure to inspect or maintain the vehicle properly increases the possibility of an accident or equipment damage. Do not operate the vehicle if you find any problem. If a problem can- not be corrected by the procedures provided in this manual, have the vehicle inspected by a Yamaha dealer. Pre-operation checklist ITEM...
  • Page 74 ITEM ROUTINE PAGE 6-6, 6-6, 6-6, 9-20, • Check front differential, transmission case, and rear final Drivetrain gear for leakage. 9-23, 9-26 • Check coolant level in reservoir. Coolant 6-6, 9-28 • Fill with coolant if necessary. Accelerator pedal • Check free play and for proper operation. Seat belts •...

  • Page 75: Front And Rear Brakes

    Apply the brakes firmly for one minute. If there  Check that there is no free play in the brake is any leakage, have the vehicle inspected by pedal. If there is free play, have a Yamaha a Yamaha dealer. dealer check the brake system. (See page 9-41.)
  • Page 76 EWB02522 EWB02532 WARNING WARNING Gasoline and gasoline vapors are ex- Gasoline is poisonous and can cause inju- tremely flammable. To avoid fires and ex- ry or death. Handle gasoline with care. plosions and to reduce the risk of injury Never siphon gasoline by mouth. If you when refueling, follow these instructions.

  • Page 77: Engine Oil

    If you carry a portable fuel container in the  Do not use oils with a diesel specifica- bed of your Yamaha Wolverine RMAX4, be tion of “CD” or oils of a higher quality sure to secure it with the cap tightened before than specified.

  • Page 78: Transmission

    Wash off any dirt or mud that EBU36030 Differential gear could affect operation. Have a Yamaha dealer Make sure there is no oil leaking from the dif- repair as necessary for proper operation. ferential gear case.

  • Page 79: Passenger Handhold

    Take the ve- resulting in serious injury or death in a crash. hicle to a Yamaha dealer or refer to the Servi- To help make sure your restraint systems are ce Manual for correct tightening torque.
  • Page 80 Tire pressure improper tire pressure may cause severe injury or death from loss of control or roll- over. Tire pressure below the minimum specified could also cause the tire to dis- lodge from the rim under severe driving conditions. [EWB04120] 1.
  • Page 81 Tire inspection OPERATING TIRE PRESSURE (cold): VEHICLE LOAD of 0.0–200.0 kg (0–441 lb) FRONT: (Recommended) 110.0 kPa (1.100 kgf/cm², 16.0 psi) REAR: (Recommended) 110.0 kPa (1.100 kgf/cm², 16.0 psi) Front: (Minimum) 103.0 kPa (1.030 kgf/cm², 15.0 psi) Rear: (Minimum) 103.0 kPa (1.030 kgf/cm², 15.0 psi) VEHICLE LOAD of 200.0–510.0 kg (441–...

  • Page 82: Operation

    If any abnormality is noticed EBU31890 during this period, consult a Yamaha dealer. Engine break-in There is never a more important period in the 0–10 hours:...

  • Page 83: Starting The Engine

    If a warning or indicator light does not Do not turn the key to the “ ” (start) position work as described above, have a Yamaha with the engine running; otherwise, damage dealer check the vehicle. to the electric starter may result.

  • Page 84: Drive Select Lever Operation And Reverse Driving

    2. Apply the brake pedal, then shift by mov- ing the drive select lever along the shift  Engine power is restricted when the engine guide. Make sure that the drive select le- is too cold. (See page 5-4.) ver is completely shifted into position. ...
  • Page 85 This includes when crossing difficult white. If the lights do not come on, ask terrain such as rocky surfaces, deep mud, a Yamaha dealer to inspect the electri- water, or when towing. cal circuits.  Due to the synchronizing mechanism in...
  • Page 86 1. Drive select lever 2. L (Low-range) 3. H (High-range) 4. N (Neutral) 5. R (Reverse) 4. Release the parking brake, if applied. 5. Check behind the vehicle for people or obstacles, and then release the brake pedal. 6. Press the accelerator pedal gradually and continue to watch to the rear while back- ing.

  • Page 87: On-Command Drive Knob

    EBU39151 On-Command drive knob The vehicle handles differently in each of the drive modes (“2WD”, “4WD” and “DIFF. LOCK”). For example, the vehicle requires more effort to turn in “DIFF. LOCK” than in “2WD”. Always stop the vehicle before changing the position of the On-Command drive knob. The meter display changes according to the selected drive mode.
  • Page 88  When using the differential gear lock (“DIFF. LOCK”), the differential gear lock indicator light and the drive train icon will flash until the differential gear lock properly engages/disengages.  When the differential gear lock indicator light and the drive train icon are flashing, turning the steering wheel back and forth will help the differential gear lock to engage or disengage.

  • Page 89: Parking

    EBU31930 EWB04260 Parking WARNING When parking, stop the engine and shift the Improper loading or towing can increase drive select lever into the neutral position. Ap- the risk of loss of control, an overturn, or ply the parking brake to help prevent the ve- other accident: hicle from rolling.
  • Page 90 Operating when loaded with cargo or tow- MAXIMUM LOAD LIMITS ing a trailer Cargo area (rear passengers and cargo): Drive more slowly than you would without a 272.0 kg (600 lb) Pulling load (gross trailer weight): load. The more weight you carry, the slower 8888 N (907 kgf, 2000 lbf) you should go.
  • Page 91 Pulling something other than a trailer Yamaha recommends that loads be trans- ported in the bed or in a trailer. If you need to move an object a short distance use a winch and follow the winch manufacturer’s instruc- tions.

  • Page 92: Basic Guide For Safe Use

    EBU31950 EBU39591 KNOW YOUR VEHICLE BASIC GUIDE FOR SAFE USE This off-road vehicle will handle and maneu- ver differently from cars, ATVs, go-carts, EBU31962 golf-cars and grounds-keeping vehicles. The As a Wolverine RMAX4 owner you are re- Wolverine RMAX4 has higher ground clear- sponsible for the safe and proper operation of ance and other features to handle rugged this vehicle.
  • Page 93  The driver must be able to place both feet As the owner/operator, it is your responsibility to protect yourself and your passengers from flat on the floorboard while seated upright accidents, including rollovers. The Wolverine with his/her back against the backrest. ...
  • Page 94 Passenger requirements Occupant protection system This vehicle is designed for the operator and EWB03350 WARNING three passengers. Allowing passengers to Do not make changes to the occupant pro- ride improperly can lead to serious injury or tection system. If you install aftermarket death.
  • Page 95 1 1 1 1. Seat belt 1. Rear passenger handhold 2. Shoulder bolster The Wolverine RMAX4 comes with a variety 3. Door of features to help reduce the risk of driver 4. Front passenger handhold and passenger injury. These features work to- gether, and when properly used, these fea- tures will help protect the occupants in the event of an accident.
  • Page 96  Be sure that each occupant’s seat belt of injury in accidents. The protective structure will not protect occupants in all rollovers or latch plate is inserted into the appropriate accidents. buckle.  Be sure the seat belt is not twisted, is close- Body parts outside of vehicle can be struck by passing objects or crushed during vehicle fitting across the hips and chest, and is...
  • Page 97 A crash can damage the restraint systems in Rear seat belts your vehicle. A damaged restraint system may not properly protect the person using it, resulting in serious injury or death in a crash. To help make sure your restraint systems are 3 3 3 working properly after a crash, have them in- spected and any necessary replacements...
  • Page 98 2. If the latch plate is not positioned in the correct location along the seat belt, ad- just its location up or down along the length of the belt. 1. Buckle 2. Latch plate 3. Release button 4. Put the lap portion of the belt low on your hips.
  • Page 99 6. Check if the seat belt shoulder position Doors suits the size of the driver and passen- The doors are designed to reduce the likeli- gers. hood that you will stick your leg out to stop To adjust the seat belt shoulder position, the vehicle from tipping over or for any other move the seat belt height adjuster left reason in a rollover.
  • Page 100 Passenger handhold The passenger handhold is provided to grip during operation to maintain proper position and balance. Holding onto the handhold helps to reduce the likelihood that the pas- sengers put a hand outside the vehicle if the vehicle begins to tip. The driver should make sure the passengers are holding onto the handhold with both hands before operating the vehicle.
  • Page 101 Adjusting the front passenger handhold posi- Seat and shoulder bolsters tion The seats and shoulder bolsters are designed The front passenger handhold can be adjust- to help keep you in the vehicle. Do not put ed to suit the passenger’s preference. your hand or arm on or outside of the shoul- To adjust the handhold position, push the le- der bolster during operation.
  • Page 102 could briefly jerk in one direction or back and forth as the tires and vehicle respond to the obstacle. This quick motion could injure your thumbs or wrist if your thumbs or hand(s) are inside the steering wheel. Grip the steering wheel so that your thumbs will not be hit by the spokes.

  • Page 103: Learning To Operate Your Vehicle

    EBU31984 LEARNING TO OPERATE YOUR VEHI- CORRECT GRIP EXAMPLE Personal protective equipment INCORRECT GRIP EXAMPLE 1. Approved motorcycle helmet 2. Eye protection 3. Long-sleeved shirt or jacket 4. Gloves 5. Long pants 6. Over-the-ankle boots The driver and passengers should wear the following to reduce risk of injury in an acci- dent: 8-12...
  • Page 104  Approved motorcycle helmet that fits prop- Practice for new Yamaha Wolverine erly RMAX4 users  Eye protection (goggles, helmet face shield, You should become familiar with the perfor- or protective eyewear) mance characteristics of the vehicle in a lar- ...
  • Page 105 Getting ready to ride Perform the Pre-Operation Checks on page 6-1. Follow the instructions starting on page 7-2 to start the engine. Turning Use care in turns – turning the steering wheel too far or too fast can result in loss of control or a rollover.
  • Page 106 For example, if you feel the back of the vehi- accelerator pedal slowly and smoothly. The cle start to slide to your right, steer to the centrifugal clutch will engage and the vehicle right. will begin to accelerate. If you think or feel that the vehicle may tip or Avoid higher speeds and sudden or hard ac- roll, keep your body completely inside the celeration until you are thoroughly familiar...
  • Page 107 Engine braking Parking on a flat area Engine compression braking is designed to When parking on a flat area, stop the engine assist you when operating your Wolverine and shift the drive select lever into the neutral RMAX4 off-road. With this feature, the engine position.
  • Page 108 5. Block the front and rear wheels with Your Yamaha Wolverine RMAX4 has higher rocks or other objects. ground clearance and other features to han- dle rugged terrain, and as a result, can over- Loading turn in situations where some vehicles may The total weight of operator, passengers, ac- not.
  • Page 109 to see far enough ahead of you. Use common side of a hill, which increases your risk of roll- sense and remember that some hills are too over. Practice first on gentle slopes before at- steep for you to climb or descend. Use proper tempting steeper hills.
  • Page 110 slow your descent. Release the brake and be- If you are sliding or skidding, try to steer in the gin to coast down the hill. Use engine braking direction the vehicle is sliding, to regain con- as much as possible, gently applying the trol.
  • Page 111 Pavement Wet brakes may have reduced effectiveness. This vehicle is designed for off-road use only. After leaving the water, test the brakes. If nec- Avoid paved surfaces. Turn gradually and go essary, apply the brakes several times to let slowly if you must drive on pavement. friction dry them out.
  • Page 112 drive before driving on a slippery surface and the risk of fire during operation or after leaving plan your path to avoid making abrupt ma- the vehicle, do not let brush, grass and other neuvers. materials collect under the vehicle, near the If you feel the vehicle begin to slide sideways muffler or exhaust pipe, or next to other hot or fishtail (rear-wheel sliding), steer into the di-...
  • Page 113 If there is any question about your ability to maneuver safely over the obstacle, you should turn around if the ground is flat and you have the room or back up until you find a less difficult path. 8-22...

  • Page 114: Periodic Maintenance And Adjustment

    To avoid death during service or while using the ve- possible burns, let brake components cool hicle. If you are not familiar with vehicle before touching them. service, have a Yamaha dealer perform the service.

  • Page 115: Owner's Manuals And Tool Kit

    EBU39490 Owner’s Manuals and Tool kit Store this manual and the Winch Owner’s Manual (YXF10WPZM), Yamaha Adventure Pro Owner’s Manual (YXF10WPZM) in a vinyl bag and always carry them in the glove com- partment as shown. Put the tool kit and tire pressure gauge in the storage compartment.
  • Page 116 Yamaha dealer to check the torque settings and adjust them as necessary.

  • Page 117: Maintenance Charts

    Even if the vehicle isn’t driven for the stated mileage or engine hours, the month maintenance intervals should still be followed. Items marked with an asterisk should be performed by a Yamaha dealer as they require special tools, data and technical skills. EBU35772...
  • Page 118 INITIAL EVERY month Whichev- ITEM ROUTINE er comes 1300 2500 2500 5000 first (mi) (150) (800) (1600) (1600) (3200) hours • Check for leakage. • Check for looseness and tighten all screw √ √ √ Exhaust system clamps and joints if necessary. •...
  • Page 119 EBU35803 General maintenance and lubrication chart INITIAL EVERY month Whichev- ITEM ROUTINE er comes 1300 2500 2500 5000 first (mi) (150) (800) (1600) (1600) (3200) hours • Check coolant leakage. √ √ √ √ √ • Repair if necessary. Cooling system •...
  • Page 120 INITIAL EVERY month Whichev- ITEM ROUTINE er comes 1300 2500 2500 5000 first (mi) (150) (800) (1600) (1600) (3200) hours √ √ √ √ √ • Check oil level. Differential gear √ √ • Change. • Check operation/brake pad wear/fluid leak- age.
  • Page 121 INITIAL EVERY month Whichev- ITEM ROUTINE er comes 1300 2500 2500 5000 first (mi) (150) (800) (1600) (1600) (3200) hours • Check balance, runout and for damage. √ √ √ √ 15 * Wheels • Replace if necessary. • Check bearing assemblies for loose- √...
  • Page 122 INITIAL EVERY month Whichev- ITEM ROUTINE er comes 1300 2500 2500 5000 first (mi) (150) (800) (1600) (1600) (3200) hours Fittings and fas- • Check all chassis fittings and fasteners. √ √ √ √ √ 23 * • Correct if necessary. teners EBU39510 ...

  • Page 123: Hood

    EBU32340 Hood To remove 1. Pull the tab on each hood lock up, and then turn the hood locks 1/4 turn clock- wise. 1. Tab 1 1 1 2. Hood lock 2. Remove the hood. 1. Tab 1. Hood 9-10...

  • Page 124: Engine Oil And Oil Filter

    To install EBU39602 Engine oil and oil filter 1. Insert the projections on the hood into the Check the engine oil level regularly. In addi- slots in the front grill, and then place the tion, the oil must be changed and the filter re- hood in the original position.
  • Page 125 To check the engine oil level 1. Park the vehicle on a level surface. If the engine is cold, take the vehicle for a 2. Remove the rear cup holder panel by re- short drive or let it idle for approximately 10 moving the quick fastener screws.
  • Page 126 9. Place the rear cup holder panel in the original position, and then install the quick fastener screws. 1 1 1 1. Engine oil tank filler cap 2. O-ring 3. Engine oil dipstick 4. Maximum level mark 5. Tip of the engine oil dipstick To change the engine oil 6.
  • Page 127 2 2 2 1. Cylinder head cap 1. Engine oil tank drain bolt 2. Engine oil tank filler cap 2. Gasket 6. Remove the engine oil tank drain bolt and its gasket to drain the engine oil from the oil tank. (Use a trough or a similar object as shown to prevent oil from spilling on the frame.) 1.
  • Page 128 7. Place an oil pan under the engine to col- lect the used engine oil. 8. Remove the engine oil drain bolts and their gaskets to drain the oil from the en- gine. 1. Oil cooler drain bolt 2. Gasket 11.
  • Page 129 12. Add 1.50 L (1.59 US qt, 1.32 Imp.qt) of 17. Turn the engine off and wait for 10 minu- the recommended engine oil to the en- tes. gine oil filler hole on the cylinder head. 18. Remove the engine oil tank filler cap, and 13.
  • Page 130 If the O-ring remains attached to the crankcase, oil leakage may occur. An oil filter wrench is available from a Yamaha dealer. 1. Right rear panel 2. Quick fastener screw 3. Bolt A 4.
  • Page 131 Make sure that the O-ring is properly seated. 1. Torque wrench 7. Install the drain bolts, and then add the specified amount of the recommended 1. O-ring engine oil. Check the engine oil level and 6. Install the new oil filter cartridge with an the vehicle for oil leakage.

  • Page 132: Why Yamalube

    7 N·m (0.7 kgf·m, 5.2 lb·ft) Bolt B: 7 N·m (0.7 kgf·m, 5.2 lb·ft) EBU38630 Why Yamalube YAMALUBE oil is a Genuine YAMAHA Part born of the engineers’ passion and belief that engine oil is an important liquid engine com- 9-19...

  • Page 133: Transmission Oil

    EBU37642 Transmission oil Check and change the transmission oil at the intervals specified in the periodic mainte- nance chart. 1 1 1 ECB02910 NOTICE When checking or changing the transmis- sion oil, make sure that no foreign material enters the transmission. If necessary, clean the filler cap and surrounding area.
  • Page 134 1. Transmission oil dipstick 1. Arrow mark 2. Maximum level mark 3. Minimum level mark The oil level should be between the minimum 5. With the arrow mark pointing outward, and maximum level marks. fully insert the dipstick into the oil filler hole and then remove it again.
  • Page 135 9. Install the passenger seat cushion. Oil will flow out immediately when the drain To change the transmission oil bolt is loosened. Take care not to lose the 1. Place an oil pan under the transmission bolt. case to collect the used oil. 2.

  • Page 136: Continuously Variable Transmission (Cvt)

    Yamaha dealer perform this main- tenance. More frequent inspections are rec- ommended if you often drive hard or operate in severe conditions. When worn, the V-belt should be replaced to prevent unintended breakdowns. Wear symptoms include:  Initial acceleration is slow or maximum speed is slow.
  • Page 137 ECB03590 NOTICE When checking or changing the final gear oil, make sure that no foreign material en- ters the final gear case. If necessary, clean the final gear oil filler bolt and surrounding area. Recommended oil: YAMALUBE 1. Final gear oil filler bolt SAE 80W-90 API GL-5 Hypoid gear oil 2.
  • Page 138 4. Install the drain bolt and its new gasket, Tightening torque: and then tighten the bolt to the specified Final gear oil filler bolt: torque. 23 N·m (2.3 kgf·m, 17 lb·ft) Tightening torque: Changing the final gear oil Final gear oil drain bolt: 1.

  • Page 139: Differential Gear Oil

    2. Remove the differential gear oil filler bolt EBU36065 Differential gear oil and its gasket, and then check the oil lev- Check the oil level and change the differential el. It should be up to the brim of the filler gear oil at the intervals specified in the period- hole.
  • Page 140 5. Install the differential gear oil filler bolt and its gasket, and then tighten the bolt to the specified torque. Tightening torque: Differential gear oil filler bolt: 23 N·m (2.3 kgf·m, 17 lb·ft) Changing the differential gear oil 1. Park the vehicle on a level surface. 1.

  • Page 141: Coolant

    7. Install the differential gear oil filler bolt and its gasket, and then tighten the bolt If genuine Yamaha coolant is not available, to the specified torque. use an ethylene glycol antifreeze containing corrosion inhibitors for aluminum engines and Tightening torque: mix with distilled water at a 1:1 ratio.

  • Page 142: Axle Boots

    9-10.) specified in the periodic maintenance chart. 5. Remove the coolant reservoir cap and Have a Yamaha dealer change the coolant. add coolant to the maximum level mark. WARNING! Never attempt to remove the radiator cap when the engine is hot.

  • Page 143: Checking The Spark Plugs

    If any spark plug shows a dis- tinctly different color, the engine could be op- erating improperly. Do not attempt to diagnose such problems yourself. Instead, have a Yamaha dealer check the vehicle. 1. Rear axle boot 9-30...
  • Page 144 If a spark plug shows signs of electrode ero- Spark plug gap: sion and excessive carbon or other deposits, 0.7–0.8 mm (0.028–0.031 in) it should be replaced. Clean the surface of the spark plug gasket Specified spark plug: and its mating surface, and then wipe off any NGK/LMAR8GI-8 grime from the spark plug threads.

  • Page 145: Air Filter Maintenance

    cause the rubber seal on the end of the cap The primary air filter should be cleaned and fits tightly. To remove the spark plug cap, oiled every 300–600 km (200–400 mi). simply twist it back and forth while pulling The secondary air filter should be replaced it out;...
  • Page 146 gine wear and possible engine damage. Additionally, the fuel injection system 1 1 1 would be affected, resulting in poor engine performance and possible overheating. To clean the primary air filter 1. Remove the hood. 2. Remove the air filter case cover by un- hooking the air filter case cover holders.
  • Page 147 1. Air filter element lock plate 7. Wash the foam material in warm soapy 2. Foam air filter element water to remove remaining solvent, then 3. Air filter frame rinse thoroughly with plain warm water. 5. Wash the foam material gently but thor- 8.

  • Page 148: Air Filter Check Hoses

    11. Pull the foam air filter element over its frame, and then install the lock plate. 12. Insert the primary air filter into the air filter 1 1 1 case, and then install the air filter case cover by hooking the holders onto the air filter case.

  • Page 149: V-Belt Case Drain Plug

    V-belt case, remove the drain plug to drain any water from the case. If water drains from the V-belt case after re- moving the drain plug, have a Yamaha dealer inspect the vehicle, as the water may affect other engine parts.

  • Page 150: Cleaning The Spark Arrester

    1. V-belt case drain plug 1. Tailpipe bolt 2. Remove the tailpipe by pulling it out of EBU37511 Cleaning the spark arrester the muffler, and then remove the gasket. EWB03370 3. Tap the tailpipe lightly, and then use a WARNING wire brush to remove any carbon depos- Hot exhaust system may cause burns.

  • Page 151: Valve Clearance

    48° 1. Tailpipe 1. Tailpipe 2. Spark arrester 5. Install the bolts and tighten them to the 3. Gasket specified torque. 4. Install the gasket, and then insert the tail- pipe into the muffler and align the bolt Tightening torque: holes.

  • Page 152: Brakes

    If a brake pad is place them as a set. damaged or if the lining thickness is less than 1.0 mm (0.04 in), have a Yamaha dealer re- place the brake pads as a set. 9-39...

  • Page 153: Checking The Brake Fluid Level

     Insufficient brake fluid may allow air to EBU32501 Checking the brake fluid level enter the brake system, reducing brak- Before starting off, check that the brake fluid ing performance. is above the minimum level mark. Check the  Clean the filler cap before removing. Use brake fluid level with the top of the reservoir only DOT 4 brake fluid from a sealed level.

  • Page 154: Brake Fluid Replacement

    Brake fluid may damage painted surfaces EBU32531 Checking the brake pedal or plastic parts. Always clean up spilled Have a Yamaha dealer check the brakes at fluid immediately. the intervals specified in the periodic mainte- nance chart. There should be no free play in As the brake pads wear, it is normal for the the brake pedal.

  • Page 155: Checking The Accelerator Pedal

    Periodically check the parking brake lever released. If the pedal free play is out of spec- free play. ification, have a Yamaha dealer adjust or re- 1. Shift the drive select lever into low gear place the throttle wire. “L”.

  • Page 156: Brake Light Switch Adjustment

    EWB04220 WARNING specification, have a Yamaha dealer ad- The brake light switch is part of the brake just it. override system. Improper adjustment may prevent the brake override system from working properly.

  • Page 157: Cable Inspection And Lubrication

    Cables can also become frayed or kinked. Lubricate the cable ends. If the cables do not operate smoothly, ask a Yamaha dealer to re- Recommended lubricant: Lithium-soap-based grease place them.

  • Page 158: Checking The Stabilizer Bushes

    Checking the stabilizer bushes The stabilizer bushes must be checked for cracks or damage at the intervals specified in the periodic maintenance chart. Have a Yamaha dealer replace the stabilizer bushes if necessary. Front EBU32590 Rear knuckle upper and lower pivot lu-...

  • Page 159: Steering Shaft Lubrication

    EBU32610 Recommended lubricant: Wheel removal Lithium-soap-based grease 1. Loosen the wheel nuts. 2. Elevate the vehicle and place a suitable EBU32600 Steering shaft lubrication stand under the frame. Lubricate the pivot points. 3. Remove the nuts from the wheel. 4. Remove the wheel. Recommended lubricant: Lithium-soap-based grease 9-46...

  • Page 160: Tire Replacement

    Tire replacement Always use the same size and type of tires recommended in this owner’s manual. The tires that came with your Yamaha Wolverine RMAX4 were designed to match the perfor- mance capabilities and to provide the best combination of handling, braking, and com- fort.

  • Page 161: Wheel Installation

    EWB03400 Front tire: WARNING Size: Do not reverse the rims on your Yamaha 29x9.00R14 NHS Wolverine RMAX4 to widen the track Manufacturer/model: width. Installing wheels improperly in- GBC/DIRT COMMANDER (YXF10WPAM) MAXXIS/ML19A/CARNAGE creases the risk of wheel failure and acci- (YXF10WPZM) dents.
  • Page 162 EWB03410 EWB03420 WARNING WARNING Avoid battery contact with skin, eyes, or Batteries may produce explosive gases. clothing. Shield eyes when working near Ventilate when charging or using in a batteries. Keep out of reach of children. closed space. Keep batteries away from You could be poisoned or severely burned sparks, flames, cigarettes, or other sourc- by the sulfuric acid in battery electrolyte.
  • Page 163  Select a suitable charger and follow the manufacturer’s instructions, or have a Yamaha dealer charge it for you.  Keep in mind that the battery tends to dis- charge more quickly if the vehicle is equipped with optional electrical accesso- 1.
  • Page 164  If the battery will be stored for more than the battery, the main switch must be two months, check it at least once a month off, and the positive lead must be con- and fully charge it if necessary. nected before the negative lead.

  • Page 165: Jump-Starting

    vehicle and the other end of the positive EBU32651 Jump-starting lead to the positive terminal of the Jump-starting the vehicle should be avoided. charged battery. The battery should be removed and charged instead. 1 1 1 However, if the vehicle must be jump-started, proceed as follows.

  • Page 166: Fuse Replacement

    EBU32664 Fuse replacement The fuses are located under the hood. If an electrical problem is suspected, check the fuses and replace if necessary. 1 1 1 1. Jumper cable negative lead 5. Start the engine. (See page 7-2.) 6. After the engine starts, disconnect the negative lead of the jumper cable from the frame and charged battery, and then disconnect the positive lead of the jump-...
  • Page 167 ECB00641 NOTICE To prevent accidental short-circuiting, turn off the main switch when checking or 6 7 8 replacing a fuse. 1. Turn off all electrical systems. (See page 5-1.) 2. Remove the hood. (See page 9-10.) 9 10 11 12 13 14 3.

  • Page 168: Headlights

    Four-wheel-drive motor fuse: loose connection, check the headlight fuse, 7.5 A Radiator fan motor fuse: and then have a Yamaha dealer check the ve- 30.0 A hicle. ETV fuse: 10.0 A ...

  • Page 169: Headlight Beam Adjustment

    EBU39611 Headlight beam adjustment ECB00691 NOTICE It is advisable to have a Yamaha dealer make this adjustment. To adjust the headlight beam 1. Remove the hood. (See page 9-10.) 2. Remove the headlight cover by removing the quick fastener screws.

  • Page 170: Auxiliary Lights

    If one or more interior lights do not come on, EBU39560 check for a loose connection, check the fus- Auxiliary lights es, and then have a Yamaha dealer check the This model is equipped with LED auxiliary vehicle. lights, there are no replaceable bulbs.

  • Page 171: Troubleshooting

    If your vehicle damage. requires any repair, take it to a Yamaha deal- The skilled technicians at a Yamaha dealer- ship have the tools, experience, and know- how to properly service your vehicle. Use only genuine Yamaha parts on your vehicle.

  • Page 172: Troubleshooting Charts

    Remove the spark plugs and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the compression. 4. Compression The engine does not start. There is compression.
  • Page 173 Restart the engine. If the engine overheats again, ask a Level is OK. Yamaha dealer to inspect and/or repair the cooling system.  Tap water can be used in an emergency. Change to the recommended coolant as soon as possible.

  • Page 174: Cleaning And Storage

    may have reduced stopping ability, in- EBU32720 CLEANING AND STORAGE creasing the chance of an accident. NOTICE: Excessive water pres- EBU35920 [EWB03471] Cleaning sure may cause water seepage and Frequent, thorough cleaning of your vehicle deterioration wheel bearings, will not only enhance its appearance but will brakes, transmission seals and electri- improve its general performance and extend cal devices.

  • Page 175: Storage

    1. Fill the fuel tank with fresh fuel and add with a light film of oil. Do not apply oil to the specified amount of Fuel Med Rx, any rubber parts or the seat covers. available from your Yamaha dealer, or equivalent product. Follow the instruc- 10-2...
  • Page 176 30 °C [90 °F] or less than 0 °C [32 °F]). Use of Fuel Med Rx or another high-quality fuel stabilizer eliminates the need to drain the fuel system. Consult a Yamaha dealer if the fuel system needs to be drained. 10-3...

  • Page 177: Specifications

    EBU32751 SPECIFICATIONS Dimensions: Cylinder arrangement: Inline Overall length: Number of cylinders: 3255 mm (128.1 in) 2-cylinder Overall width: Displacement: 1677 mm (66.0 in) 999 cm³ Overall height: Bore × stroke: 2110 mm (83.1 in) 93.0 × 73.5 mm (3.66 × 2.89 in) Seat height: Compression ratio: 872/977 mm (34.3/38.5 in)
  • Page 178 Recommended engine oil grade: Differential gear oil: API service SG type or higher, JASO standard MA Type: SAE 80W-90 API GL-5 Hypoid gear oil 130 °F Quantity: 0.31 L (0.33 US qt, 0.27 Imp.qt) Coolant quantity: SAE 0W-30 Coolant reservoir (up to the maximum level mark): 0.45 L (0.48 US qt, 0.40 Imp.qt) Radiator (including all routes): SAE 10W-30...
  • Page 179 Spark plug (s): Manufacturer/model: GBC/DIRT COMMANDER (YXF10WPAM) Manufacturer/model: MAXXIS/ML19A/CARNAGE (YXF10WPZM) NGK/LMAR8GI-8 Rear tire: Spark plug gap: 0.7–0.8 mm (0.028–0.031 in) Size: Clutch: 29x11.00R14 NHS Manufacturer/model: Clutch type: GBC/DIRT COMMANDER (YXF10WPAM) Wet, centrifugal, shoe MAXXIS/ML19A/CARNAGE (YXF10WPZM) Drivetrain: Loading: Primary reduction ratio: Maximum load: 1.000 510.0 kg (1124 lb)
  • Page 180 Rear: Rear suspension: 200.0 kPa (2.000 kgf/cm², 29.0 psi) Type: Minimum: Double wishbone Front: Spring: 110.0 kPa (1.100 kgf/cm², 16.0 psi) Coil spring Rear: Shock absorber: 193.0 kPa (1.930 kgf/cm², 28.0 psi) Gas-hydraulic damper Front wheel: Wheel travel: Rim size: 337 mm (13.3 in) 14x6.5AT Electrical system:...
  • Page 181 Meter lighting: Fuel injection system fuse: 10.0 A Neutral indicator light: EPS fuse: 40.0 A High beam indicator light: Headlight fuse: 7.5 A Reverse indicator light: Signaling system fuse: 7.5 A Coolant temperature warning light: Ignition fuse: 15.0 A Engine trouble warning light: Auxiliary DC jack fuse: 10.0 A Parking brake indicator light:...

  • Page 182: Consumer Information

    EBU32775 CONSUMER INFORMATION EBU32820 EBU38940 Vehicle Emission Control Information Emission Regulation (California) label An add-on or modified part must be compli- The Vehicle Emission Control Information la- ant with applicable ARB evaporative emission bel is affixed at the location in the illustration. control standards.
  • Page 183 Privacy Policy. Privacy Policy https://yamaha-motor.com/privacy-policy Yamaha will not disclose this data to a third party except in the following cases. In addi- tion, Yamaha may provide vehicle data to a contractor in order to outsource services re- lated to the handling of vehicle data.

  • Page 184: Noise Regulation

    EBU32830 NOISE REGULATION TAMPERING WITH NOISE CONTROL SYSTEM PROHIBITED: Federal law prohibits the following acts or the causing thereof: (1) The removal or rendering in- operative by any person other than for purposes of maintenance, repair, or replacement of any device or element of design incorporated into any new vehicle for the purpose of noise control prior to its sale or delivery to the ultimate purchaser or while it is in use or (2) the use of the vehicle after such device or element of design has been removed or rendered inoperative by any person.

  • Page 185: Maintenance Record

    EBU35842 MAINTENANCE RECORD Copies of work orders and/or receipts for parts you purchase and install will be required to do- cument maintenance done in accordance with the warranty. The chart below is printed only as a reminder to you that the maintenance work is required. It is not acceptable proof of mainte- nance work.

  • Page 186: Yamaha Motor Corporation, U.s.a. 2020 And Later Model Side-By-Side Limited Warranty

    EBU32855 YAMAHA MOTOR CORPORATION, U.S.A. 2020 AND LATER MODEL SIDE-BY- SIDE LIMITED WARRANTY Yamaha Motor Corporation, U.S.A. hereby warrants THE CUSTOMER’S RESPONSIBILITY under this YAMAHA MOTOR CORPORATION, U.S.A. MAKES that new Yamaha Side-by-Side models purchased warranty shall be to: OTHER WARRANTY...
  • Page 187 Attention: Warranty Department 3. Each Yamaha Side x Side dealer is held responsible for his setup, service and war-ranty repair work. This will ensure that Yamaha Motor Corporation, U.S.A. has an up-to-date registration record in accordance with federal law.

  • Page 188: Yamaha Extended Service (Y.e.s.)

    This excellent Y.E.S. plan coverage is only available to dealer to see how comfor ting uninterr upted factor y- Yamaha owners like you, and only while your Yamaha is still backed protection can be. within the Yamaha Limited Warranty period. So visit your authorized Yamaha dealer to get all the facts.
  • Page 189 Yamaha. See your dealer today! A special note: YAMAHA EXTENDED SERVICE If visiting your dealer isn’t convenient, contact Yamaha with your Vehicle Identification Number. We’ll be happy to help you get the Y.E.S. coverage you need. Yamaha Service Marketing P.O. Box 6555...

  • Page 190: Index

    INDEX Coolant, Pre-operation check ........6-6 Coolant temperature warning light ........ 5-4 Cup holders ..............5-27 Accelerator pedal ............5-18 Data recording, vehicle ..........12-1 Accelerator pedal, checking ........9-42 Differential gear lock indicator light ....... 5-3 Accelerator pedal, Pre-operation check ......6-6 Differential gear oil, Periodic maintenance ....
  • Page 191 Multi-function meter unit ..........5-6 Glove compartment ............. 5-26 Neutral indicator light ............ 5-2 Noise regulation ............12-3 Headlight beam, adjusting ........... 9-56 Headlights ..............9-55 Helmet reminder light ............ 5-6 On-Command drive knob, operation ......7-6 High beam indicator light ..........5-3 Owner’s Manuals and Tool kit ........
  • Page 192 V-belt case drain plug ..........9-36 Vehicle Emission Control Information label ....12-1 Vehicle identification number .........1-1 Warranty, extended ............12-7 Warranty, limited ............12-5 Wheel installation ............9-48 Wheel removal .............9-46 Winch switch (YXF10WPZM) ........5-15 Winch (YXF10WPZM) ...........5-36 Yamaha Adventure Pro powered by Magellan® ..5-40 Yamalube ..............9-19 13-3...
  • Page 193 EBU32880 For your best ownership experience, think Genuine Yamaha! Genuine Yamaha Parts – Genuine Yamaha replacement parts are the exact same parts as the ones originally equipped on your vehicle, providing you with the performance and durability you have come to expect.
  • Page 194 PRINTED IN USA 2020.04-1.6×1 CR (E)

This manual is also suitable for:

Yxf10wpzmYxf10wpam

Table of Contents
