  • Page 2: Table Of Contents

    ABLE OF ABOUT THIS GUIDE ...3 INTRODUCTION ...5 EATURES AND NPACKING THE YSTEM EQUIREMENT HYSICAL ESCRIPTION HARDWARE INSTALLATION ...16 TTACHING THE ONNECTING THE TTACHING THE POWER OVER ETHERNET ...18 ONNECT TO TPE-101I...19 ONNECT TO SECURITY ...21 APPLICATION OF THE CAMERA ...22 USING THE UTILITY ...25 NSTALLATION ETUP...
  • Page 3 YSTEM DMINISTRATION – A MAGE – J MAGE IPVIEW PRO...57 NSTALLATION ETTING TARTED SING ONFIGURING THE APPENDIX ...85 A. F REQUENTLY B. PING Y C. T ROUBLESHOOTING D. T E. A DJUST NTERNET F. I/O T ERMINAL G. S PECIFICATION H.

  • Page 4: About This Guide

    BOUT This manual provides instructions and illustrations on how to use your Internet Camera. Chapter 1, Introduction, provides the general information on the camera. Chapter 2, Hardware Installation, describes the hardware installation procedure for the camera. Chapter 3, Power Over Ethernet, explains the Power over Ethernet features.
  • Page 5 values depend on your system and network. If you are not sure about the respective information, please ask your network administrator or MIS staff for help.

  • Page 6: Introduction

    NTRODUCTION Thank you for purchasing the Internet Camera, a camera device that can be connected directly to an Ethernet or Fast Ethernet network. Compared to the conventional PC Camera, the Internet Camera features a built-in CPU and web-based solutions that can provide a cost-effective solution to transmit real-time high-quality video images and sounds for monitoring.

  • Page 7: Features And Benefits

    Features and Benefits Simple to Use The Internet Camera is a standalone system with built-in CPU requiring no special hardware or software such as PC frame grabber cards. The Internet Camera supports both ActiveX mode (for Internet Explorer users) and Java mode (for Internet Explorer and Mozilla Firefox users).
  • Page 8 needs. When the external device is connected, you could configure the settings and control the device from the RS485 window of Web Configuration Utility. Remote Utility The powerful IPView Pro application assigns the administrator with a pre-defined user ID and password, allowing the administrator to modify the Internet Camera settings from the remote site via Intranet or Internet.

  • Page 9: Unpacking The Package

    Unpacking the Package Unpack the package and check all the items carefully. In addition to this User’s Guide, be certain that you have: One TV-IP201P One Utility and User Guide CD-ROM One Quick Installation Guide One AC power adapter suitable for your country’s electric...

  • Page 10: System Requirement

    Networking 10Base-T Ethernet or 100Base-TX Fast Ethernet. Power over Ethernet Switch (e.g. TPE-S88) Injector (e.g. TPE-101I ) Note: The TV-IP201P only supports Power over Ethernet (PoE) devices that follow the IEEE 802.3af standard. Accessing the Camera For Web Browser Users Operating System: Microsoft®...
  • Page 11 Memory Size: 256MB or above / 512MB or above (Windows Vista) Resolution: 800x600 or above A network switch or hub with an available network LAN port A RJ-45 network cable...

  • Page 12: Physical Description

    Physical Description This section describes the externally visible features of the Internet Camera. Front Panel 1. Link LED 3. Internal MIC 2. Power LED 1. Link LED The Link LED is positioned on the right side of the Internet Camera’s lens while facing the Internet Camera. It is located to the left of the Power LED A steady light confirms that the camera has good...

  • Page 13: Power Led

    2. Power LED The Power LED is positioned on the right side of the Internet Camera’s lens while facing the Internet Camera. A steady BLUE light confirms that the Internet Camera is powered on. 3. Internal MIC The built-in omni-directional microphone allows the camera to receive sound and voice.

  • Page 14: Network Cable Connector

    Rear Panel 2. Reset Button 3. I/O Connector 1. Network Cable Connector 4. DC Power Connector 1. Network Cable Connector The Internet Camera’s rear panel features an RJ-45 connector for connections to 10Base-T Ethernet cabling or 100Base-TX Fast Ethernet cabling (which should be Category 5 twisted-pair cable). The port supports Auto-MDIX, allowing the Internet Camera to automatically detect or negotiate the transmission speed of the network.

  • Page 15: Dc Power Connector

    to flash, indicating the Internet Camera is changing to factory reset. When factory reset is completed, the Internet Camera will default to channel 11. This default setting will let the Internet Camera connect to ANY access point on the infrastructure network.

  • Page 16: Screw Hole

    Top/Bottom Panel Top Panel Screw Hole Bottom Panel Screw Hole Screw Hole Located on the top/bottom panel of the camera, the screw hole is used to connect the camera stand onto the camera by attaching the screw head on the camera stand into the screw hole of the camera.

  • Page 17: Hardware Installation

    ARDWARE NSTALLATION Attaching the Camera to the Stand The Internet Camera comes with a camera stand (optional), which is equipped with a swivel ball screw head that can be attached to the Internet Camera's bottom screw hole. Attach the camera stand to the Internet Camera and station it for your application.

  • Page 18: Connecting The Ethernet Cable

    Connecting the Ethernet cable Connect an Ethernet cable to the network cable connector located Camera’s rear panel, and then attach it to the network. Attaching the Power Supply Attach external supply to the DC power input connector located on Internet Camera’s rear panel, and then connect it to your local power supply.

  • Page 19: Power Over Ethernet

    OWER THERNET Connect to Power over Ethernet Switch Step 1: Connect an Ethernet cable to the LAN port located on the Internet Camera’s rear panel.

  • Page 20: Connect To Tpe-101I

    Step 2: Connect the opposite end of the Ethernet cable to the network cable connector on the Power over Ethernet switch Step 3: Verify that the Power and Link LEDs are on. Connect to TPE-101I Step 1: Connect the Power Cord to the Injector.
  • Page 21 Step 3: Connect an Ethernet cable to the LAN port on the Internet Camera’s rear panel. Step 4: Connect the opposite end of the Ethernet cable to the TPE- 101I’s PoE Out port.

  • Page 22: Security

    To ensure the highest security and prevent unauthorized usage of the Internet Camera the Administrator has the exclusive privilege to access the System Administration for settings and control requirements to allow users the level of entry and authorize the privileges for all users. The Internet Camera supports multi-level password protection and access to the Internet Camera is strictly restricted to define the user who has a “User Name”...

  • Page 23: Application Of The Camera

    PPLICATION AMERA The Internet Camera can be applied in wide variety of applications. With the built-in CPU, it can work as a standalone system that provides a web-based solution transmitting high quality video images and sounds for monitoring purposes. It can be managed remotely, accessed and controlled from any PC desktop over the Intranet or Internet via a web browser.
  • Page 24 Applications of the Camera Monitoring of local and remote places and objects such as construction sites, hospitals, amusement parks, schools and day-care centers through the use of a web browser. Capture single frame images from the IPView Pro application. Configure the camera to upload image or send mail messages with a single frame image.

  • Page 26: Using The Utility

    SING THE UTILITY This chapter describes the software utilities for the IP camera, including how to set up your Camera with the utility. The Setup Wizard is designed with a user-friendly interface that allows you to set up the Camera easily. Auto-Run Installation Insert the Installation CD-ROM into your computer’s CD-ROM drive to initiate the Auto-Run program.
  • Page 27 • Xplug Control – click to launch Xplug control. Please refer to Troubleshooting section for more detail installation. • Product Registration– easy and quick register your product at TRENDnet webside • Exit – click to close the Auto-Run program. www.trendnet.com/register...

  • Page 28: Setup Wizard

    Setup Wizard To avoid IP address conflicts in your network, you can use Setup Wizard to change the related settings of your Camera (such as the IP address) after finishing hardware installation. Installing Setup Wizard 1. Click Setup Wizard from the Auto-Run menu screen. The InstallShield Wizard will appear.
  • Page 29 3. Click Browse to choose the desired destination location. By default, the destination location is C:\Program Files\Setup Wizard. Then click Next >. 4. The InstallShield Wizard starts to install the software. A status screen appears indicating the progress of the installation.
  • Page 30 After installing the utility, the application program for the camera is automatically installed to your computer, and creates a folder in Start\Programs\SetupWizard. Using Setup Wizard This section describes the operation of Setup Wizard. To launch the Wizard: 1. Click Start -> Programs -> Setup Wizard, and then click SetupWizard.
  • Page 31 Wizard Select IP Camera, then click Wizard If the Camera’s default IP is different than your network’s IP subnet, the Wizard will help you to search for a proper IP address. Click YES to change the IP address. Use the DHCP assigned IP address or manually set the IP address.
  • Page 32 Note: Please note the IP address. This is the IP address for accessing the browser configuration of your camera from your local area network. Your IP Address might look different than the example above. Assign Admin ID & Password here. By default, there is no Admin ID and Password.
  • Page 33 Setup the Primary DNS or Secondary DNS if necessary. Then click Next (Right Arrow) Review all the setting then click restart. Search This button will search the available camera(s) within the network.
  • Page 34 Link This button links to the web configuration section. About This button displays Setup Wizard information. Exit Exit the Setup Wizard...

  • Page 35: Using The Camera

    SING THE You can access and manage the Internet Camera through: 1) a web browser, and 2) the enclosed software IPView Pro. This chapter describes the Web Configuration Utility, and provides the instructions on using the camera with a web browser. Web Configuration Utility The Internet Camera must be configured through its built-in Web- based Configuration.
  • Page 36 Welcome Screen of the Configuration Utility In the Welcome screen, there are three options to choose to set-up and view your Internet Camera, including: View Image – ActiveX Mode View Image – Java Mode System Administration Enter the default IP address Preview area...

  • Page 37: System Administration

    Click System Administration. A login dialog window will appear. Type the default User name/ Password (admin/admin) in the corresponding boxes. Then, click OK to enter the Configuration Utility. System Administration The Configuration Utility contains eleven options in the left menu bar: Home, System, Date/Time, Video/Audio, Network, Users, Trigger, Upload, RS485, Information and Tools.

  • Page 38: Camera Name

    Camera Name Enter a descriptive name for the device. Location Enter the location of the camera. Date/Time The Date/Time window contains options for setting the date and time on your camera. Date & Time Server’s Time: Display the current date/time settings for the camera.
  • Page 39 Synchronized with Time Server: Select this option and the time will be based on GMT setting. When selecting the option, you have to enter the required information in the following fields: • IP Address - Enter the IP Address of the Time Server in this field.

  • Page 40: Video Resolution

    Light Frequency Select 60HZ or 50HZ. Video Resolution Select the desired video resolution from three formats: 176x144, 320x240, and 640x480. The higher resolution will produce better image quality; however, it will use more resource within your network. Compression Rate Select the desired compression rate from the five levels: Lowest, Low, Medium, High, and Highest.
  • Page 41 Note: PCM and ADPCM are different audio codes. PCM has better audio quality, but requires higher bandwidth (8Kbps). ADPCM has slightly less quality and requires less bandwidth (2Kbps). If you are viewing the camera via Internet, we suggest that you set the audio to ADPCM. In addition, adjust the image settings by clicking Adjust Image: Brightness: Adjust the brightness level ranging from -64 to +64.
  • Page 42 Network The Network window contains options that allow you to set up networking configuration of the camera. IP Assignment Use Static IP Address: Select this option to manually configure the IP address. The default settings are: • IP Address – 192.168.0.30 •...

  • Page 43: Dynamic Dns

    Obtain IP address automatically via DHCP: If your network uses a DHCP server, select this option. The camera will be assigned an IP address from the DHCP server automatically. Obtain IP address automatically via PPPoE: If your application requires a direct connection from an ADSL modem through the camera’s RJ-45 LAN port, click this option and enter the User ID and Password into the respective boxes.

  • Page 44: Add User

    Users The Users window contains commands that allow the system administrator to assign legal users who are permitted to monitor the camera from the remote site. Administrator Enter the password in the Admin Password box, enter the same password in the Confirm Password box to confirm the password, and then click Apply.

  • Page 45: Delete User

    a group given the password. For example, if the User Name is “Guest” and the User Password is “Guest”, anyone can access the camera with these details used as a group of users under the User Name “Guest”. Delete User Select the user you want to delete from the dropdown menu, and then click Delete.

  • Page 46: Access Control

    Enable Trigger Email SMTP Server Address: To use the e-mail alert function, you must enter the mail server address in the field. Sender e-mail Address: Enter the e-mail address of sender. Receiver e-mail Address 1/2: Enter the e-mail address of receiver(s).

  • Page 47: Ftp Server

    Upload To upload the image to FTP server, you need to configure the related settings in the Upload window. FTP Server This field contains the following five basic settings for your FTP server. Host Address: The IP Address of the FTP server. Port Number: The standard port number for the FTP server is Port 21.
  • Page 48 User Name: Enter the user name in this field. Password: Enter the password in this field to login to the FTP server. Directory Path: Enter an existing folder name in this field, The images will be uploaded to the given folder. Operation To enable the FTP upload function, check Upload image to FTP server and then select the desired options:...
  • Page 49 Check the Enable item to enable this function on your camera, and configure the related settings in the following fields. NOTE: When RS485 is enabled, the system will provide the additional control buttons on the View Image screen (ActiveX mode and Java mode).
  • Page 50 Click the Preset Position button to bring up a control window, which allows you to control the camera with more options. • Arrow buttons: Use these buttons to move the camera’s lens to your desired position. Click the center button to return to the default home position.

  • Page 51: Firmware Version

    Custom protocol setting: Selecting this field allows you to configure the commands protocol manually. You can click Test to test each command that you have assigned. In the Name and Command String boxes, you can customize more buttons for your needs. Please note that the setting values in the Command String boxes should be from the connected external device (please refer to the manual of connected device).

  • Page 52: Factory Reset

    Tools The Tools window contains commands for restarting the camera and upgrading firmware. Reboot Do you really want to reboot this device? Click YES from this option, and you can restart the camera just like turning the device off and on and saved settings are retained. Factory Reset Do you really want to factory reset this device? Click YES from this option, and you can resume all factory default settings for the...

  • Page 53: View Image - Activex Mode

    Update Firmware This option allows you to update the firmware of the camera once you obtained a latest version of firmware. Click Browse to find the firmware file saved in your computer, and then click Update. NOTE: It will take a few minutes to update firmware. Please wait to complete the procedure;...
  • Page 54 Camera Name/Location: The Camera name and location will be displayed when the Camera Name/Location fields are entered in the Web Configuration Utility. Video/Audio: You can enable/disable the video and audio function by clicking the desired selection. Trigger Out: you can turn on/off the output device manually by clicking the OFF button.
  • Page 55 When you enable RS485 on the camera, the system will provide additional control buttons on the screen (as show below). You can use the Up, Down, Left, and Right buttons to move the camera’s lens to your desired position. Click the Home button to return to the default home position.

  • Page 56: View Image - Java Mode

    NOTE: In the View Image screen (ActiveX mode and Java mode), Preset Position will be unavailable when you select Custom Command. View Image – Java Mode To view video images from the browser, click View Image – Java Mode from the Welcome screen to access the video images from your browser as illustrated below: Camera Name/Location: The Camera name and location will be displayed when the Camera Name/Location fields are entered in...
  • Page 57 Video/Audio: You can enable/disable the video and audio function by clicking the desired selection. Trigger: you can turn on/off the output device manually by clicking the OFF button. Browse/Capture: Allow you to capture and save the video image. In Java mode, you can select the path by clicking “Browse”. To capture and save an image to the selected path, click "Capture"...

  • Page 58: Ipview Pro

    This chapter describes IPView Pro, which is a powerful software application designed with a user-friendly interface for ease of control and navigation requirements. Installation Step 1 Insert the CD-ROM into the CD-ROM drive to initiate the auto- run program. The menu screen will appear as below:...
  • Page 59 Step 2 Click the IPView Pro item to activate the InstallShield Wizard. Click Next in the welcome screen. Step 3 Read and accept the License Agreement; then, click Yes.
  • Page 60 Step 4 Choose the destination location. If no specific requirement, leave the default setting and click Next. Step 5 The InstallShield Wizard starts to install the software, and the progress bar indicates the installation is proceeding.
  • Page 61 Step 6 If you use Windows® 2000/XP, it will appear a Digital Signature warning screen. Click Continue Anyway (Windows® XP) or Yes (Windows® 2000). Windows® XP Windows® 2000 Step 7 Click Finish to complete the installation.

  • Page 62: Getting Started

    Getting Started This section describes the User Interface of IPView Pro, with detailed procedures for using the application. To launch IPView Pro, click Start > Programs > IPView Pro > IPView Pro. The main screen will appear as below: NOTE: IPView Pro requires the system’s resolution setting up to 1024x768.
  • Page 63 Item Feature Item Date/Time Status Mode Window View Window Connect/ Disconnect Rotate image angle Snapshot Audio ON/OFF Click to turn on/off the camera’s audio. Zoom Mode View Mode Buttons Description Show current date/time. Show the camera’s status in this window. Click the Change Status Mode button ( the right lower corner of the window to change the display mode:...
  • Page 64 10 Key Lock Button 11 Power Button 12 Record Button Record video clip of the selected camera and 13 Play Button 14 System Configuration Show six cameras in View Window with the first one as the major view. Show eight cameras in View Window with the first one as the major view.

  • Page 65: Using Ipview Pro

    Using IPView Pro Adding a Camera To add a camera: 1. Click the System Configuration button to enter the System Configuration. If you are not sure of the camera’s IP address, you can click Search to search the available camera(s) within the network.
  • Page 66 2. Select the camera you want by highlighting it, and then click Add Camera. Click the Add Camera button. 3. Click Save, and then click the System Configuration button to return to View Window. The selected camera’s video will be displayed now.
  • Page 67 Alternately, you can add a camera by entering the its IP address directly: 4. Select the Input IP tab. Click the Add Camera button. 5. Enter the camera’s IP address (default: 192.168.0.30) and Port (default: 80), and then click Add Camera. 6.
  • Page 68 Removing a Camera To remove the camera from the list: camera elect the you want to remove. 2. Click Delete Camera.
  • Page 69 Viewing a Camera From the View Modes of the panel, you can select one-camera mode or other modes to display your video. IPView Pro allows a maximum of 16 cameras for viewing. For example, if you use only one camera, select one-camera mode ( ), and the View Window will display the view as figure 1.
  • Page 70 When you click the Record button and select Manual Record, it will start recording. Click the button again to stop. If you select Schedule Record or Motion Record, the system will record the video clip according to the settings in System Configuration. Playing Recorded Video The recorded video clips are saved in your computer, and can be played using Windows Media Player.

  • Page 71: Configuring The System

    Configuring the System Clicking the System Configuration button on the panel allows you to configure the system settings, and the System Configuration Screen will appear in the View Window as shown below. Once configured, click Save to save the settings, and then click the System Configuration button again to exit configuration.

  • Page 72: Web Configuration

    Camera Configuration In this field, you can add/delete the camera (as described in the previous section). Also, you can configure the following settings: Web Configuration In the left column, selecting the Web Configuration item will launch the Web Configuration Utility in View Window. You can configure these settings according to the description in Chapter 5, Using the Camera.
  • Page 73 Motion Configuration-1 The Motion Configuration-1 item provides the commands for motion detection control. Before configuring, you should select one camera from the pull-down menu. Select Custom region. Detect Region: • Full picture – When you select this option, the camera will monitor the whole area.
  • Page 74 • Custom region – Click Add Region, and then use mouse to draw an area in the view screen; when some motion detected within the area, the camera starts recording automatically. You can set multiple areas in the view screen. Click Delete Region to remove the area selected.
  • Page 75 Invoke Alarm: Select this option to enable alarm when some motion detected by the system. Send e-mail: When this option is checked, click the Mailing Configuration in the left column to enter the required information (see the following section). Play music: You can use the music file to alert the event. Click Browse music file to select the desired music, and set the Interval time.
  • Page 76 Reset: Restore the original setting of your camera. Do you really want to reset this device? Click Yes in the pop-up dialog box to confirm. Factory Reset: Restore the factory default settings of the camera. Do you really want to factory reset this device? Click Yes in the pop-up dialog box to confirm.
  • Page 77 Mailing Configuration When Motion Detection function is enabled and the Send e-mail option is checked, you should enter the required information in the respective fields. Mail Server: Enter the mail server address that is used to send your e-mail. Mail From/To: Enter the sender’s/receiver’s e-mail address. Subject: Enter the title of the e-mail.
  • Page 78 Proxy Server Check the Proxy Server option and enter the required settings in the Address and Port boxes to enable and use the Proxy Server function.
  • Page 79 Recording Configuration In this field, you can configure the storage settings. Log Storage: • Reserved HDD Space For MS-Windows OS – You can reserve 500 MB to 10000 MB hard disk space for the program. • Each Recording File Size – If the recorded video files reach the file size limit, video images will be recorded into another file automatically.
  • Page 80 setting. Please note that you are not allowed to delete a path setting if there is only one setting in the list. Recycle: You can check this option to clear the files when the unreserved space of your hard disk is filled. The available settings are from 200 MB to 50000 MB.
  • Page 81 Date Mode: First, select the camera desired from the pull- down menu. Then, setup the time in the Start/Stop fields. Click Add to add the recording schedule to the list. Click Save to save the settings. Week Mode: First, select the camera desired from the pull- down menu.
  • Page 82 Others When multiple cameras connected, this option allows the system to display these views as the main view in circles according to your time settings. The range of Time interval of scan is from 1 to 20 seconds.
  • Page 83 Log List This filed displays the user(s) information, which include the Date, MAC address, and the brief description of events.
  • Page 84 Account This filed allows you to set the Admin ID and Admin Password. You can also check the Login password check option to secure your camera by checking the login password.
  • Page 85 About This section provides information of the software application.

  • Page 86: Appendix

    PPENDIX A. Frequently Asked Questions Internet Camera Features Q: What is an Internet Camera? A: The Internet Camera is a standalone system connecting directly to an Ethernet or Fast Ethernet network. It is different from the conventional PC camera, the Internet Camera is an all- in-one system with built-in CPU and web-based solutions providing a low cost solution that can transmit high quality video images for monitoring.

  • Page 87: Internet Camera Installation

    Q: What algorithm is used to compress the digital image? A: The Internet Camera utilizes the M-JPEG image compression technology providing high quality images for users. Internet Camera Installation Q: Can the Internet Camera be used out-doors? A: The Internet Camera is not weatherproof. It needs to be installed in an outdoor housing such as the 15-AH25B or the 15- AH28B.

  • Page 88: Ping Your Ip Address

    B. PING Your IP Address The PING (Packet Internet Groper) command can determine whether a specific IP address is accessible by sending a packet to the specific address and waiting for a reply. It can also provide a very useful tool to confirm if the IP address conflicts with the Internet Camera over the network.

  • Page 89: Troubleshooting

    C. Troubleshooting Q: I cannot access the Internet Camera from a web browser. A1: The possible cause might be the IP Address for the Internet Camera is already being used by another device. To correct the possible problem, you need to first disconnect the Internet Camera from the network.
  • Page 90 A1: Make sure that the network cable is properly connected to the camera and to the switch or hub on your network. If the Link LED is still not lit, try using a different network cable. A2: The network switch or hub may not be functioning properly. Confirm that power for the switch or hub is connected and is working properly.
  • Page 91 A1: A probable cause might be the incorrect display properties configuration for your desktop. You need to open the Display Properties on your desktop and configure your display to show at least 65’000 colors for example at least 16-bit. NOTE: Applying only 16 or 256 colors on your computer will produce dithering artifacts in the image.

  • Page 92: Time Zone Table

    D. Time Zone Table...

  • Page 94: Adjust Internet Camera Focus

    E. Adjust Internet Camera Focus To adjust the focus of the lens, you need to turn the lens slowly in either clockwise or anti-clockwise direction until the desired image appears. DO NOT over turn the lens in either of the directions, as it will be out of focus.

  • Page 95: I/O Terminal Application

    F. I/O Terminal Application Typically used in association with programming scripts for developing applications for motion detection, event triggering, alarm notification via e-mail, and a variety of external control functions. The 6-pin I/O Terminal Block is located on the rear panel and provides the interface to: a photo-coupled switch output, a photo-coupled input, and RS-485 interface.
  • Page 96 Interface Schematic device (active control device) has independent 1. Input power supply. Output device (load) is driven by external power supply. RS485 Interface Load PTZ Camera...

  • Page 97: Specification

    G. Specification Video specification Resolution: Sensor: Lens: Gain control: Exposure: White Balance: Image (Video Setting) Compression: Image frame rate: Compression rate: Frame rate: Video resolution: Audio MIC Input: Compression: 640 x 480 pixel Color CMOS sensor f: 6.0 mm, F: 1.8 Automatic Automatic Automatic...

  • Page 98: Hardware Interface

    Hardware Interface LAN Connector: Communication protocol: CPU: RAM: Flash ROM: Power Supply: Power consumption: LED Indicator: I/O port pin assignment: Input: Output: RS-485: Software Browser: Application Software: One RJ-45 port, 10/100M auto- sensed, Auto-MDIX HTTP, FTP, TCP/IP, UDP, ARP, ICMP, DHCP, PPPoE, DDNS, SMTP, UPnP ADMtek 5120 16MB...

  • Page 99: Operating Environment

    OS supported: Operating environment Operating temperature: Storage temperature: Humidity: FCC Class B, CE Class B, VCCI Class B Microsoft Windows 98SE/ME/ 2000/XP/Vista C ~ 40 C ~ 50 5% ~ 95%, non-condensing...

  • Page 100: Glossary Of Terms

    H. Glossary of Terms NUMBERS 10BASE-T is Ethernet over UTP Category III, IV, or V 10BASE-T unshielded twisted-pair media. 100BASE-TX 100BASE-T is called 100BASE-TX. Applet Applets are small Java programs that can be embedded in an HTML page. The rule at the moment is that an applet can only make an Internet connection to the computer form that the applet was sent.
  • Page 101 BOOTP Bootstrap Protocol is an Internet protocol that can automatically configure a network device in a diskless workstation to give its own IP address. Communication Communication has four components: sender, receiver, message, and medium. In networks, devices and application tasks and processes communicate messages to each other over media.
  • Page 102 of manually assigning it a unique IP address. DHCP allows the specification for the service provided by a router, gateway, or other network device that automatically assigns an IP address to any device that requests one Domain Name System is an Internet service that translates domain names into IP addresses.
  • Page 103 Fast Ethernet Fast Ethernet, also called 100BASE-T, operates at 10 or 100Mbps per second over UTP, STP, or fiber-optic media. Firewall is considered the first line of defense in Firewall protecting private information. For better security, data can be encrypted. A system designed to prevent unauthorized access to or from a private network.
  • Page 104 system is useful because it can represent every byte (8 bits) as two consecutive hexadecimal digits. It is easier for humans to read hexadecimal numbers than binary numbers. IEEE Institute of Electrical and Electronic Engineers. Intranet This is a private network, inside an organization or company, that uses the same software you will find on the public Internet.
  • Page 105 IP address IP address is a 32-binary digit number that identifies each sender or receiver of information that is sent in packets across the Internet. For example 80.80.80.69 is an IP address, it is the closet thing the Internet has to telephone numbers.
  • Page 106 Network Address Translator generally applied by a router, that makes many different IP addresses on an internal network appear to the Internet as a single address. For routing messages properly within your network, each device requires a unique IP address. But the addresses may not be valid outside your network.
  • Page 107 by sending a packet to the specified address and waits for a reply. It is primarily used to troubleshoot Internet connections. Point-to-Point Protocol over Ethernet. PPPoE is a PPPoE specification for connecting the users on an Ethernet to the Internet through a common broadband medium, such as DSL or cable modem.
  • Page 108 RARP Reverse Address Resolution Protocol, a TCP/IP protocol that allows a physical address, such as an Ethernet address, to be translated into an IP address. RJ-45 connector is used for Ethernet cable connections. RJ-45 A router is the network software or hardware entity Router charged with routing packets between networks.
  • Page 109 (TCP/IP) Transmission Control Protocol/Internet Protocol is a widely used transport protocol that connects diverse computers of various transmission methods. It was developed y the Department of Defense to connect different computer types and led to the development of the Internet. Transceiver A transceiver joins two network segments together.
  • Page 110 Wide-Area Network. A wide-area network consists of groups of interconnected computers that are separated by a wide distance and communicate with each other via common carrier telecommunication techniques. Windows Windows is a graphical user interface for workstations that use DOS. Workgroup A workgroup is a group of users who are physically located together and connected to the same LAN, or a...

  • Page 111: Limited Warranty

    TV-IP201P – 3 Years Warranty If a product does not operate as warranted above during the applicable warranty period, TRENDware shall, at its option and expense, repair the defective product or part, deliver to customer an equivalent product or part to replace the defective item, or refund to customer the purchase price paid for the defective product.
  • Page 112 TRENDWARE SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS TESTING AND EXAMINATION DISCLOSE THAT THE ALLEGED DEFECT IN THE PRODUCT DOES NOT EXIST OR WAS CAUSED BY CUSTOMER’S OR ANY THIRD PERSON’S MISUSE, NEGLECT, IMPROPER INSTALLATION OR TESTING, UNAUTHORIZED ATTEMPTS TO REPAIR OR MODIFY, OR ANY OTHER CAUSE BEYOND THE RANGE OF THE INTENDED USE, OR BY ACCIDENT, FIRE, LIGHTNING, OR OTHER HAZARD.
