Quick Installation Guide
TV-IP252P
1.01

Advertisement

loading
Need help?

Need help?

Do you have a question about the TV-IP252P and is the answer not in the manual?

Questions and answers

Related Manuals for TRENDnet TV-IP252P

Summary of Contents for TRENDnet TV-IP252P

  • Page 1 Quick Installation Guide TV-IP252P 1.01...

  • Page 2: Table Of Contents

    Table of Contents English 1. Before You Start 2. Hardware Installation 3. Configure the IP Camera 4. Power over Ethernet (PoE) Installation Troubleshooting Version 07.18.2009...

  • Page 3: English

    1. Before You Start Package Contents TV-IP252P Multi-Language Quick Installation Guide Utility CD-ROM RJ-45 cable Mounting Kit AC Power Adapter (12V, 1.5A) System Requirements 10/100Mbps Ethernet Adapter CPU: 350MHz or above / 800MHz (Windows Vista) Memory: 256MB RAM or above / 512MB RAM or above (Windows Vista) Windows 2000/XP/Vista VGA Resolution: 800 x 600 or above Web Browser: Internet Explorer (6.0 or higher)

  • Page 4: Hardware Installation

    2. Hardware Installation 1. Connect the provided RJ-45 network cable from a Switch/Router to the Ethernet port on the IP Camera. 2. Connect the AC Power Adapter to the IP Camera and then to a power outlet.

  • Page 5: Configure The Ip Camera

    1. Insert the Utility CD-ROM into your CD-ROM drive and then click IP Setup. 2. Follow the IPSetup Setup Wizard instructions and then click Next. 3. Click Close. 4. Go to Start -> Programs -> TRENDnet -> IPSetup and click IPSetup.
  • Page 6 Note: By default, the IP setting on the TV-IP252P is set to DHCP. Please skip to step 9. If you want to give the TV-IP252P a static IP address, continue on to step 5. 5. Select the IP camera and click Change IP. 6.
  • Page 7 9. Double click the IP camera to access the browser configuration. 10. Enter the User name and Password, and then click OK. By default: User Name: admin Password: admin 11. Right click on the Internet Explorer Information Bar and select Install ActiveX Control. 12.
  • Page 8 Troubleshooting section, User's Guide on the Utility CD-ROM, or TRENDnet's website at http://www.trendnet.com. Register Your Product To ensure the highest level of customer service and support, please take a moment to www.trendnet.com/register register your product Online at: Thank you for choosing TRENDnet...

  • Page 9: Power Over Ethernet (Poe) Installation

    4. Power over Ethernet (PoE) Installation Using the TV-IP252P with a PoE switch 1. Connect a RJ-45 cable from the Power Over Ethernet switch (e.g. TPE-80WS) to the LAN port on the IP Camera. 2. Verify that the LEDs are on. Please refer to step 4 in the Hardware Installation section.
  • Page 10 Using the TV-IP252P with an Injector (TPE-111GI) 1. Connect the Power Cord to the Injector. Then connect the Power Cord to an outlet. 2. Connect a CAT-5e/6 cable from a switch to the TPE-111GI's DATA IN port. 3. Connect a CAT-5e/6 cable from the TV-IP252P to the TPE-111GI's DATA OUT port.

  • Page 11: Troubleshooting

    Troubleshooting IP Setup is unable to detect my camera. What should I do? 1. Verify that you have followed all the steps in the Section Hardware Installation. 2. Disable any software firewall programs such as ZoneAlarm or Norton Internet Security. If you are using Windows XP or Windows Vista, disable the built in firewall.
  • Page 12 2. Second, make sure that you added ActiveX. See step 11 and 12 in Section 2: Configure the IP Camera. Can I use the TV-IP252P outdoors? The TV-IP252P was designed for indoor use only. If you still encounter problems or have any questions regarding the TV-IP252P, please contact TRENDnet's Technical Support Department.
  • Page 13 The source codes are available for download from TRENDnet's web site (http://trendnet.com/downloads/list_gpl.asp) for at least three years from the product shipping date. You could also request the source codes by contacting TRENDnet. 20675 Manhattan Place, Torrance, CA 90501, USA. Tel: +1-310-961-5500 Fax: +1-310-961-5511.
  • Page 14 GPL/LGPL informações Gerais Este produto TRENDnet inclui software gratuito desenvolvido por terceiros. Estes códigos estão sujeitos ao GPL (GNU General Public License) ou ao LGPL (GNU Lesser General Public License). Estes códigos são distribuídos SEM GARANTIA e estão sujeitos aos direitos autorais dos desenvolvedores. TRENDnet não presta suporte técnico a estes códigos.
  • Page 15 Product Warranty Registration Please take a moment to register your product online. Go to TRENDnet’s website at http://www.trendnet.com/register Copyright ©2009. All Rights Reserved. TRENDnet.
