Dynamic Water Pressure
Max: 5.0 bar
Min: 0.2bar
3.0
2.0
4.0
1.0
5.0
0.
Pressure
BAR
Maximum Static Pressure: 10.0 bar

Pack Contents

Pack Contents
x1
Hourglass Tap
x2
Rubber Washer
Backnut

Tools Required for Installation/ Maintenance

Tools Required for Installation/ Maintenance
ø6mm
Drill
Safety Glasses
All products manufactured and supplied by Bristan are safe to use provided that they are installed, operated and
receive regular maintenance in accordance with these instructions.
This product needs to be installed in accordance with, and meet the requirements of The Water Supply (Water
Fittings) Regulations (Northern Ireland) 2009 and The Water Supply (Water Fittings) (Scotland) Byelaws 2014.
For full Installation Requirements & Notes (IRN) please visit www.wrasapprovals.co.uk/approvals-directory
Isolation valves must be fitted to the inlet water supplies to ensure ease of future maintenance.
Before installing this product the water supply must be thoroughly flushed in order to remove any swarf, solder etc.
Full access must be made available for future maintenance/servicing purposes.
This product must not be modified in any way as this will invalidate the guarantee.

Specifications

Inlet Water Temperature
Maximum Hot 60°C
x1
Hose
x1
Handset
x1
Bracket
Pencil
Adjustable Spanner Hexagonal Key

Prior to Installation

Installation Instructions
Please leave these instructions
Inlet Connections
60°C
3/4" BSP
Operation
Operation
Pull up to divert to handset
On
Hot
10mm
2.5mm
Hexagonal Key
(Grub Screws)
(Diverter)
& User Guide
with the end user
HOU BSM C (D6)
M24 Male Flow
Straightener
Push down the diverter to divert
back to bath fill
32mm
17mm
Box Spanner
Box Spanner
(Inlets)
(Cartridge)

Spare Parts

To replace any spare parts
for your tap, why not
scan the QR Code or
visit www.bristan.com
and search for your
Outlet
On
Cold
Size 1
Philips Head
Screwdriver
product.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HOU BSM C and is the answer not in the manual?

Questions and answers

Summary of Contents for Bristan HOU BSM C

  • Page 1 Prior to Installation Spare Parts All products manufactured and supplied by Bristan are safe to use provided that they are installed, operated and receive regular maintenance in accordance with these instructions. This product needs to be installed in accordance with, and meet the requirements of The Water Supply (Water Fittings) Regulations (Northern Ireland) 2009 and The Water Supply (Water Fittings) (Scotland) Byelaws 2014.
  • Page 2 Installation - Wall Bracket Position the wall bracket where you want it and mark out where Remove the bracket to drill. Make sure the hose and lid to reveal the handset can reach. screw holes On most Observe screw models, the holes inside of screw holes are the bracket...
