CONTACT US FIRST
CONTACT US FIRST
sauder.com
sauder.com
sauder.com
BEFORE MAKING ANY RETURNS TO THE STORE.
BEFORE MAKING ANY RETURNS TO THE RETAILER.
sauder.com/service
Visit
Prefer the phone? Give us a ring at
Customer Service is available Monday-Friday - 9 a.m. to 5:30 p.m. EST (except holidays)
Credenza
Clifford Place Collection | Model 429508
Sauder.com
Share your journey!
to order replacement parts, view video assembly tips, or chat with a live rep.
1-800-445-1527
.
Get all organized
and stuff.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-28
Français pg 29-32
Español pg 33-36
Lot # 557409
Purchased: __________________
12/07/20

Advertisement

loading
Need help?

Need help?

Do you have a question about the Clifford Place 429508 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Sauder Clifford Place 429508

  • Page 1 CONTACT US FIRST CONTACT US FIRST sauder.com sauder.com sauder.com BEFORE MAKING ANY RETURNS TO THE STORE. BEFORE MAKING ANY RETURNS TO THE RETAILER. sauder.com/service Visit to order replacement parts, view video assembly tips, or chat with a live rep. 1-800-445-1527 Prefer the phone? Give us a ring at Customer Service is available Monday-Friday - 9 a.m.
  • Page 2 • Check the size and weight of your TV. Compare it to the diagram below – before you begin assembly! • This Sauder unit is designed for use with televisions weighing less than 50 pounds. Never use with a TV that weighs more.
  • Page 3 W FOOT (6) ADJUSTABLE SHELF (1) LEFT DRAWER SIDE (1) Hardware Identification ANGLED HEAD LARGE HIDDEN EXTENSION SLIDE - 2 EXTENSION RAIL - 2 CAM - 30 CAM SCREW - 30 (EXTENSION SET SHOWN SEPARATED) Angled head 429508 www.sauder.com/service Page 3...
  • Page 4 BLACK 1-1/8" FLAT HEAD SCREW - 12 BLACK 1-1/2" FLAT HEAD SCREW - 14 BLACK 1/2" PAN HEAD SCREW - 18 SILVER 1/2" FLAT HEAD SCREW - 4 BLACK 1/2" FLAT HEAD SCREW - 4 Page 4 www.sauder.com/service 429508...
  • Page 5 Step 1 Look for this icon. It means a video assembly tip is available at www.sauder.com/service/tips Find the numbered video or scan the QR code. å Assemble your unit on a carpeted floor or on the empty carton to avoid scratching your unit or the floor.
  • Page 6 ENDS (A and B), UPRIGHT (C), and TOP (D). å NOTE: The UPRIGHT (C) will have four ANGLED HEAD SCREWS on one surface and six on the opposite surface. Angled head (30 used) Remember: Righty tighty. Lefty loosey. Page 6 www.sauder.com/service 429508...
  • Page 7 NOTE: The EXTENSION SLIDES (Y) will be used later for the DRAWERS. Pull down on the black release lever and pull the SLIDE from the RAIL. Use these holes. Open end BLACK 1/2" PAN HEAD SCREW (6 used in this step) Open end 429508 www.sauder.com/service Page 7...
  • Page 8 Flip the BOTTOMS (I and J) over. å Turn and tighten six FEET (W) into the threaded holes in the BOTTOMS (I and J). å Turn four ADJUSTABLE GLIDES (10) into the threaded holes in the FEET (W). Page 8 www.sauder.com/service 429508...
  • Page 9 SMALL BOTTOM (J). Use four BLACK 1-1/8" FLAT HEAD SCREWS (22). å NOTE: Be sure the SHORT WOODEN DOWELS insert into the holes in the BOTTOM MOLDINGS. BLACK 1-1/8" FLAT HEAD SCREW (8 used in this step) Curved edge BLACK 1-1/8" FLAT HEAD SCREW 429508 www.sauder.com/service Page 9...
  • Page 10 H I D f a c D E N i t h o S u r D E N H I D BLACK 1-1/2" FLAT HEAD SCREW (2 used in this step) Page 10 www.sauder.com/service 429508...
  • Page 11 NOTE: Be sure the WOOD DOWELS in the LOWER BACK insert into the holes in the BOTTOM. S u r f a c H I D D E N i t h o BLACK 1-1/2" FLAT HEAD SCREW (2 used in this step) 429508 www.sauder.com/service Page 11...
  • Page 12 Fasten the UPPER BACK (E) to the LOWER BACK (O), by pushing it onto the WOOD DOWELS in the LOWER BACK. å Lay your unit onto the BACKS (E and O) to prepare for the next step. Page 12 www.sauder.com/service 429508...
  • Page 13 BOTTOM (I). Tighten six HIDDEN CAMS. It's going to be ok. å NOTE: Be sure the WOOD DOWELS in the LEFT END insert into the holes in the SHELF, BACKS, and BOTTOM. Open end of EXTENSION RAIL 429508 www.sauder.com/service Page 13...
  • Page 14 Fasten the UPRIGHT (C) to the SHELF (G), BACKS (E and O), and BOTTOM (I). Tighten six HIDDEN CAMS. å NOTE: Be sure the WOOD DOWELS in the UPRIGHT insert into the holes in the SHELF, BACKS, and BOTTOM. Page 14 www.sauder.com/service 429508...
  • Page 15 Lay the BACK (F) onto the floor to prepare for the next step. S u r f a c H I D D E N i t h o This hole must be here. BLACK 1-1/2" FLAT HEAD SCREW (2 used in this step) 429508 www.sauder.com/service Page 15...
  • Page 16 Insert four WOOD DOWELS (6) into the UPRIGHT (C). å Fasten the BACK (F) and SMALL BOTTOM (J) to the UPRIGHT (C). Tighten four HIDDEN CAMS. å NOTE: Be sure the WOOD DOWELS in the UPRIGHT insert into the BACK and SMALL BOTTOM. Page 16 www.sauder.com/service 429508...
  • Page 17 Fasten the RIGHT END (A) to the BACK (F) and SMALL BOTTOM (J). Tighten four HIDDEN CAMS. å NOTE: Be sure the WOOD DOWELS in the RIGHT END insert into the holes in the BACK and SMALL BOTTOM. 429508 www.sauder.com/service Page 17...
  • Page 18 Use four BLACK 1-1/8" FLAT HEAD SCREWS (22). your drink. å NOTE: Be sure the SHORT WOOD DOWELS in the TOP insert into the holes in the TOP MOLDINGS. BLACK 1-1/8" FLAT HEAD SCREW (4 used in this step) Rounded edge Page 18 www.sauder.com/service 429508...
  • Page 19 Fasten the TOP (D) to the ENDS (A and B), UPRIGHT (C), and BACKS (E and F). Tighten ten HIDDEN CAMS. å NOTE: Be sure the WOOD DOWELS in the ENDS, UPRIGHT, and BACKS insert into the holes in the TOP. (9 used) 429508 www.sauder.com/service Page 19...
  • Page 20 Step 16 å Fasten the NOTCHED FILE GLIDE (19) to the DRAWER FRONT (U). Use six BLACK 1/2" PAN HEAD SCREWS (23). BLACK 1/2" PAN HEAD SCREW (6 used in this step) Notch Page 20 www.sauder.com/service 429508...
  • Page 21 DRAWER SIDES (P and R) and DRAWER BRACES (T). Straight head (8 used) Arrow Arrow Hole (8 used) The arrow in the HIDDEN CAM must point toward the hole in the edge of the board. 429508 www.sauder.com/service Page 21...
  • Page 22 Fasten the DRAWER BACK (Q) to the DRAWER SIDES (P and R) and DRAWER BRACES (T). Use eight BLACK 1-1/2" FLAT HEAD SCREWS (21). å NOTE: Be sure the DRAWER BOTTOM (S) inserts into the groove of the DRAWER BACK (Q). Page 22 www.sauder.com/service 429508...
  • Page 23 Fasten a PULL (8) to the DRAWER FRONT (U). Use two BLACK 1/2" FLAT HEAD SCREWS (26). Open end Use these holes. Open end BLACK 1/2" FLAT HEAD SCREW (2 used for PULL) Open end BLACK 1/2" PAN HEAD SCREW (6 used for the EXTENSION SLIDES) 429508 www.sauder.com/service Page 23...
  • Page 24 Push the LONG FILE GLIDE (18) onto the top edge of the leave without a bite. DRAWER BACK (Q). å Push two FILE HANGERS (20) onto the NOTCHED FILE GLIDE (19) and LONG FILE GLIDE (18). Page 24 www.sauder.com/service 429508...
  • Page 25 BLACK 1/2" FLAT HEAD SCREW (2 used for PULL) Mounting screw The screw on the back side of the HINGE will fit into this slot. This screw will fit into this slot. Then tighten the screw. 429508 www.sauder.com/service Page 25...
  • Page 26 Tighten the screws after making adjustments. å To adjust the DOORS in or out (depth), loosen the mounting screw one turn and move the DOORS in or out, as needed. Tighten the mounting screw after making adjustments. Page 26 www.sauder.com/service 429508...
  • Page 27 50 lbs. 22,68 kg 22,68 kg 22,68 22,68 å NOTE: This is a permanent label intended to last for the life of the product. Once applied, do not try to remove it. 429508 www.sauder.com/service Page 27...
  • Page 28 NOTE: Please read the back pages of the instruction booklet for important safety information. å This completes assembly. Clean with a damp cloth. Wipe dry. And to celebrate, why not share your success story at sauder.com or 50 lbs. 20 lbs.
  • Page 29 QUANTITÉ REFERENCE DESCRIPTION QUANTITÉ conserver le livret pour future référence. Pour EXTRÉMITÉ DROITE ..........1 GRANDE EXCENTRIQUE contacter Sauder en ESCAMOTABLE ............30 ce qui concerne cet EXTRÉMITÉ GAUCHE ..........1 VIS D'EXCENTRIQUE AVEC TÊTE élément, faire référence MONTANT................1 EN ANGLE ..............30 au numéro de lot et DESSUS ................1...
  • Page 30 ! Faire tourner quatre PATINS RÉGLABLES (10) dans les trous • Cette unité Sauder est conçue pour les téléviseurs pesant moins filetés des PIEDS (W). de 22 kg. Ne jamais utiliser avec des téléviseurs plus lourds.
  • Page 31 REMARQUE : S'assurer que le FOND DE TIROIR (S) s'encastre dans REMARQUE : S'assurer de bien insérer les CHEVILLES EN BOIS la rainure de l'ARRIÈRE DE TIROIR (Q). situées sur l’EXTRÉMITÉ DROITE dans les trous de l'ARRIÈRE et du PETIT DESSOUS. 429508 www.sauder.com/service Page 31...
  • Page 32 Serrer les vis après avoir ajusté. Pour ajuster les PORTES vers l'intérieur où vers l'extérieur (profondeur), desserrer la vis de montage un tour et déplacer les PORTES vers l'intérieur ou vers l'extérieur. Serrer la vis de montage après avoir ajusté. Page 32 www.sauder.com/service 429508...
  • Page 33 Si EXTREMO DERECHO ..........1 EXCÉNTRICO ESCONDIDO PEQUEÑO ...8 necesita ponerse en EXTREMO IZQUIERDO ..........1 BIELA DE EXCÉNTRICO CON contacto con Sauder en CABEZA RECTA ............8 PARAL ...................1 cuanto a esta unidad, PASADOR DE MADERA LARGO ....4 PANEL SUPERIOR ............1 refiérase al número...
  • Page 34 - antes de comenzar el ensamblaje! los agujeros roscados de la PATA (W). • Esta unidad Sauder está diseñada para ser usada con televisores cuyo peso sea inferior a 22 Kg. Nunca la use para un televisor de mayor peso.
  • Page 35 NOTA: Asegúrese de que el FONDO DE CAJÓN (S) ajuste dentro NOTA: Asegúrese de que los PASADORES DE MADERA en el de la ranura del DORSO DE CAJÓN (Q). EXTREMO DERECHO se inserten dentro de los agujeros del DORSO y del FONDO PEQUEÑO. 429508 www.sauder.com/service Page 35...
  • Page 36 Para ajustar las PUERTAS hacia atrás o hacia adelante (profundidad), afloje el tornillo de montaje una vuelta y mueva las PUERTAS hacia el interior o hacia el exterior según sea necesario. Apriete el tornillo de montaje después de hacer los ajustes. Page 36 www.sauder.com/service 429508...
  • Page 37 TOUJOURS décharger les tablettes et les tiroirs, en commençant par les surface supérieures, avant de déplacer le meuble. NE JAMAIS pousser ou tirer un meuble sur de la moquette. Demander à une autre personne de le soulever correctement pour le déplacer et/ou le repositionner. 429508 www.sauder.com/service Page 37...
  • Page 38 SIEMPRE descargue los estantes y cajones, empezando con las superficies superiores, antes de moverlo. NUNCA empuje ni tire de los muebles sobre una alfombra. Obtenga que un amigo le ayude a levantarlo correctamente para moverlo y/o reposicionarlo. Page 38 www.sauder.com/service 429508...
  • Page 39 à compter de la date d'achat la première fois et qui sont signalés à Sauder dans les limites de couverture de la contre tout défaut de matériaux ou de fabrication des composantes de mobilier Sauder.
  • Page 40 BEFORE MAKING ANY RETURNS TO THE RETAILER. So, how did it go? Dear Valued Customer: Thanks so much for choosing Sauder® furniture. I hope the Set a world record for speed? purchase and assembly process was a positive experience Feeling good about yourself? and you feel good about the furniture you just built.
