- Page 1 AXIS Q86 Series AXIS Q8641–E PT Thermal Network Camera AXIS Q8642–E PT Thermal Network Camera Installation Guide Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
-
Page 2: Table Of Contents
Installation Guide Table of Contents Safety information ......... . Hazard levels . - Page 3 Low Voltage (LVD) Directive 2014/35/EU. See Safety Every care has been taken in the preparation of this on page 4 . document. Please inform your local Axis office of any • Restrictions of Hazardous Substances (RoHS) Directive inaccuracies or omissions. Axis Communications AB cannot 2011/65/EU.
- Page 4 Search by product, category, or phrase and the environment, the product must be disposed of in • report problems to Axis support staff by logging in to an approved and environmentally safe recycling process. your private support area For information about your nearest designated collection •...
-
Page 5: Safety Information
AXIS Q86 Series Safety information Hazard levels DANGER Indicates a hazardous situation which, if not avoided, will result in death or serious injury. WARNING Indicates a hazardous situation which, if not avoided, could result in death or serious injury. CAUTION Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury. -
Page 6: Safety Instructions
• Use only spare parts provided by or recommended by Axis. • Do not attempt to repair the product yourself. Contact Axis support or your Axis reseller for service matters. • Do not point the camera lens toward the sun or other high-intensity radiation sources because this could cause damage to the camera. -
Page 7: Transportation
Battery The Axis product uses a 3.0 V BR2032 lithium battery as the power supply for its internal real-time clock (RTC). Under normal conditions this battery will last for a minimum of five years. Low battery power affects the operation of the RTC, causing it to reset at every power-up. When the battery needs replacing, a log message will appear in the product’s server report. - Page 8 Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
-
Page 9: Package Contents
AXIS Q86 Series Package contents • AXIS Q8641–E or AXIS Q8642–E PT Thermal Network Camera • Power connector • I/O connector • Torx® bit T20 and T30 • Printed materials Installation Guide (this document) Extra serial number label (2x) AVHS Authentication key Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com... -
Page 10: Product Overview
AXIS Q86 Series Product overview For specifications of the hardware components, see Specifications on page 26 Sunshield Positioning camera Base unit Base unit screws Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com... - Page 11 AXIS Q86 Series Back lid SD card lid SD card slot Control button Input power connector I/O connector RJ45 connector SFP slot for SFP module (SFP module not included) Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
-
Page 12: How To Install The Product
AXIS Q86 Series How to install the product DANGER Risk of electric shock. All cables shall be de-energized before installing the product. CAUTION The electrical connections and conduit installations shall be made by a certified electrician and in compliance with local regulations. -
Page 13: Mount The Base Unit
AXIS Q86 Series Mount the base unit Base unit 1. Remove the four base unit screws (T30). 2. Simultaneously pull and turn the base unit counterclockwise until the arrows on the base unit and the rest of the unit are aligned. - Page 14 AXIS Q86 Series NO TICE TICE TICE Do not use sharp tools when removing the transparent base unit cover. 4. Remove the transparent base unit cover. Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
-
Page 15: Route The Cables
AXIS Q86 Series Conduit cover clip Conduit cover Screw hole (x4) 5. For conduit installations only: remove the two conduit cover clips followed by the conduit cover. 6. Attach the base unit to the mounting surface using the appropriate fasteners in the four screw holes. - Page 16 AXIS Q86 Series Power cable (not included) Strain relief Grounding screw Grounding braid (not included) Bottom cable hole 1. Install the optional conduit adapters (not included). 2. Connect the grounding braid to the grounding screw. 3. Insert the power cable, I/O cable and network cable through the hole in the base unit as shown in the illustration above.
- Page 17 AXIS Q86 Series I/O cable (optional, not included) Network cable (not included) 5. Insert the I/O cable (optional) through the strain relief with a distance of 420 mm (16½ in) from the strain relief to the end of the cable.
- Page 18 AXIS Q86 Series Power cable (not included) I/O cable (optional, not included) Network cable (not included) Cable gasket Transparent base unit cover 8. Fit cable gaskets on the cables. See Cable thickness on page 29. 9. Insert the power, I/O and network cables including the cable gaskets through the holes in the transparent base unit cover and arrange the cables as shown in the illustration above.
- Page 19 AXIS Q86 Series I/O connector Power connector O-ring NO TICE TICE TICE Make sure the protective earth wire is about 10 mm (3/8 in) longer than the other two wires (in the power cable), so that it will not be disconnected accidentally if pulled.
- Page 20 AXIS Q86 Series 13. Replace the positioning unit on the base unit making sure that the arrows on the two units are aligned. 14. Turn the positioning unit clockwise back to its original position and tighten the four base unit screws (torque 3.0 Nm).
-
Page 21: Install The Network Link
AXIS Q86 Series Install the network link You have different options for installing the network link: • A: via an optical fiber or RJ45 cable connected to the SFP module (with a respective connector) in the SFP slot. • B: via an RJ45 cable connected to the fixed RJ45 connector. -
Page 22: Connect The Cables
AXIS Q86 Series Connect the cables 1. Loosen the four lid screws (T20) and remove the lid. Input power connector I/O connector RJ45 connector SFP slot for SFP module (SFP module not included) 2. Connect the network (optical fibre and/or RJ45), I/O and power cables. For more information on different network connectivity options, see Install the network link on page 21. -
Page 23: How To Install An Sd Card (Optional)
7. Reconnect power to the product. How to access the product AXIS IP Utility and AXIS Camera Management are recommended methods for finding Axis products on the network and assigning them IP addresses in Windows®. Both applications are free and can be downloaded from axis.com/support... -
Page 24: How To Reset To Factory Default Settings
AXIS Q86 Series How to reset to factory default settings CAUTION Risk of injury. Moving parts. Keep your body parts away from the product when in operation. Disconnect from power supply before installing or performing maintenance on the product. CAUTION Risk of injury. -
Page 25: Further Information
• For useful online trainings and webinars, see axis.com/academy Optional accessories For a complete list of available accessories for this product, go to the product’s page on axis.com and select Software & Accessories. Warranty information For information about Axis’ product warranty and thereto related information, go to axis.com/warranty... -
Page 26: Specifications
AXIS Q86 Series Specifications To find the latest version of the product’s datasheet, go to axis.com > [product] > Support & Documentation. LED Indicators Status LED Indication Unlit Connection and normal operation. Green Connection and normal operation. Amber Steady during startup. Flashes during firmware upgrade or reset to factory default. -
Page 27: Buttons
For location of the control button, see Product overview on page 10. The control button is used for: • Resetting the product to factory default settings. See page 24. • Connecting to an AXIS Video Hosting System service. To find out more about this service, see axis.com Connectors Network connector RJ45 Ethernet connector. - Page 28 AXIS Q86 Series Function Notes Specifications DC ground 0 V DC 0 V DC (-) DC output Can be used to power auxiliary equipment. 12 V DC Note: This pin can only be used as power out. Max load = 50 mA 3–...
-
Page 29: Cables
• Use cable gaskets or cable glands that match both the cable hole and the cable area For information about accessories, such as cable gaskets and cable glands that allow for other cable areas, see www.axis.com Operating conditions The Axis product is intended for indoor and outdoor use. Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com... -
Page 30: Power Consumption
AXIS Q8642–E 24 V AC/DC* Important *When using the 22 m (72 ft) AXIS Cable 24 V DC/24–240 V AC, a power supply capable of delivering 220 W is required to compensate for the power loss in the cable. NO TICE... - Page 31 Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
- Page 32 Installation Guide Ver. M2.2 AXIS Q86 Series Date: July 2017 © Axis Communications AB, 2017 Part No. 1761127 Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
