Starting
TI.GRAPH LINK
and Testing the
Connection
Exiting the
Program
1. Open the TI-GRAPH LINK group on the PC, and then
double-click on a TI-73 program icon to start the
application. The TI-73 Menu Bar, Keypad, and Edit
window are displayed.
2. On the PC, open the
communication serial port (Com Port 1, Com Port 2,
Com Port 3, or Com Port 4) to which the cable from a
TI-73 is connected.
3. Open the Link
Windows/Macintosh
(Black Cable).
4. Open the Link
5. Click on Get Screen
The contents of a TI-73 display appear in the window
indicating that the communication link between a TI-73
and the PC is OK.
Note: If you obtain an error message when you click on
, there is a communications problem
Get Screen
between the TI-73 and the PC.
¦
Make sure the TI-GRAPH LINK cable is connected to
the correct serial communications port on the PC.
¦
Make sure the correct cable type is selected in the
Link menu.
¦
Make sure all cable connectors are firmly inserted.
6. Click on
Done
You can close TI-GRAPH LINK in any of the following
ways:
¦
Open the File
¦
Press Alt + F and then
¦
Double-click on the
of the screen.
TI.GRAPH LINK for the TI.73 (Windows) ENG.5
Link menu and select the
menu to select the cable type: select
(Gray Cable) or
menu. Select Get Screen...
. Ensure that the TI-73 is on.
to close the window.
menu and select
X on the PC keyboard.
box in the upper-left corner
Close
Windows Only
.
Exit .
