Page 1: Mda-35S
Operators manual V 1.0 English | September 2020 Magnetic drilling machine MDA-35S Serial number: Date of purchase:... - Page 2 Congratulations on your purchase of the MDA-35S portable magnetic drilling machine. Your model is designed to produce superior holes quickly and efficiently. Before operating your new magnetic drilling machine, please read all instructions first. These include the Operators Manual and warning label on the unit itself. With proper use, care and maintenance your model will provide you with years of effective hole drilling performance.
-
Page 3: Table Of Contents
Table of contents MDA-35S ..........................1 Table of contents ........................3 1. Safety ..........................4 1.1 General safety instructions 1.2 Specific safety information 2. Description ........................8 2.1 Intended use 2.2 Description and features 2.3 Case content 2.4 Serial number 2.5 Technical data 2.6 Symbols 2.7 Environmental... -
Page 4: Safety
1. Safety 1.1 General safety instructions Do not use this power tool before you have thoroughly read and completely understood this Instruction Manual and the “General Safety Instructions”, including the figures, specifications, safety regulations and the signs indicating DANGER, WARNING and CAUTION. WARNING: When using electrical tools basic safety precautions should always be followed to reduce the risk of fire, electrical shock and personal injury including following. - Page 5 PERSONAL SAFETY 1. Stay alert, watch what you are doing and use common sense when using a magnetic drilling machine. Do not use machine while tired or under the influence of drugs, alcohol, or medication. A moment of inattention while operating magnetic drilling machines may result in serious personal injury.
-
Page 6: Specific Safety Information
SERVICE 1. Tool service must be performed only by qualified repair personnel. Service or maintenance performed by unqualified personnel could result in a risk of injury. 2. When servicing a tool, use only identical replacement parts. Follow instructions in the maintenance section of this manual. - Page 7 RESIDUAL RISKS In spite of the application of the relevant safety regulations and the implementation of safety devices, certain residual risks cannot be avoided. These are: Impairment of hearing; • Risk of personal injury from flying particles; • Risk of burns due to accessories becoming hot during operation; •...
-
Page 8: Description
Feed handle Motor switch Magnet switch [image 2-1] 2.3 Case content 1 x MDA-35S Magnetic drilling machine 1 x safety guard 3 x handles 1 x hex key 2.5 mm 1 x hex key 3 mm 1 x hex key 4 mm... -
Page 9: Serial Number
2.4 Serial number The serial number is mentioned on the machine 3 times: engraved on the frame and magnet, plus on the serial no. sticker on the motor housing. Additional serial no. stickers are provided with the machine for your administration. The serial number will help you and your sales point validate and identify the machine. -
Page 10: Symbols
2.6 Symbols Symbol Term, meaning Explanation Be sure to read the enclosed documentation Read documentation such as the Instruction Manual and the General Safety Instructions Wear ear protection Use ear protection during operation Wear eye protection Use eye-protection during operation Danger/warning/caution Observe the information in the adjacent text! European conformity symbol... -
Page 11: Environmental
2.7 Environmental Separate collection. This product must not be disposed of with normal household waste. Separate collection of used products and packaging allows materials to be recycled and used again. Re-use of recycled materials helps prevent environmental pollution and reduces the demand for raw materials. Local regulations may provide for separate collection of electrical products from the household, at municipal waste sites or by the retailer when you purchase a new product. -
Page 12: Preparation & Adjustment
3. Preparation & adjustment 3.1 Assembly WARNING: To reduce the risk of injury, turn unit off and disconnect machine from power source before installing and removing accessories, before adjusting or changing set- ups or when making repairs. Be sure all switches are in the OFF position. -
Page 13: Prior To Use
3.2 Prior to use Please make sure that the contacting surface for the magnet is level, clean and rust-free. Remove any varnish or primer. When working on materials that are not magnetisable, suitable fixation devices, obtainable as accessories, e.g. suction plate, vacuum plate or pipe- drilling device must be used. -
Page 14: Using The Machine
4. Using the machine WARNING: Always observe the safety instructions and applicable regulations. WARNING: To reduce the risk of serious personal injury, turn tool off and disconnect tool from power source before making any adjustments or removing/installing attachments or accessories. 4.1 Control panel The control panel on your magnetic drilling machine is designed for maximum operating facility and safety. -
Page 15: Electromagnet
4.2 Electromagnet Make sure the magnetic drilling machine is placed on a smooth, clean, level and solid surface without any objects or debris in between to guarantee maximum adhesion. The workpiece must be at least 6 mm (1/4") thick for the magnet to stick, but minimal 3 mm (1/8") thick to hold the weight of the machine and to drill safely. -
Page 16: Switching Motor On And Off
Make sure that the magnet attaches tightly to the work piece before turning on the motor unit of the magnetic drilling machine. Our magnets have 2 coils; make sure that both coils are in contact with the material. Do not connect any other machines to the electrical outlet the magnetic drilling machine is plugged into, as it may result in the loss of magnetic force. -
Page 17: Working With Operation Tools
5. Working with operation tools 5.1 Annular cutters Annular cutters only cut material at the periphery of the hole, rather than converting the entire hole to shavings. As a result, the energy required to make a hole is lower than for a twist drill. When drilling with an annular cutter, it is not necessary to drill a pilot hole. -
Page 18: Twist Drills
5. If your machine is equipped with a lubrication system, put open the valve to release the oil. If your machine does not have such a system, fill the holes of the spindle with oil; 6. Switch the motor on at and allow it to run at the required speed; 7. -
Page 19: Maintenance
6. Maintenance Your power tool has been designed to operate over a long period of time with a minimum of maintenance. Continuous satisfactory operation depends upon proper tool care and regular cleaning. CAUTION: To reduce the risk of injury, turn unit off and disconnect machine from power source before installing and removing accessories, before adjusting or changing set- ups or when making repairs. - Page 20 CHECK ARMATURE This should be checked at least 1 per month to check that there are visual signs of damage to the body or to the commutator. Some signs of wear will be seen on the commutator over a period of time this is normal as this is the part that comes in contact with the brushes but any signs of abnormal damage and the part should be replaced.
-
Page 21: Trouble Shooting
7. Trouble shooting Magnet and motor do not - The magnet switch is not connected to the power supply function - Damaged or defective wiring - Defective fuse - Defective magnet switch - Defective control unit - Defective power supply Magnet does function, the - Damaged or defective wiring motor does not work... - Page 22 Frame under voltage - Damaged / defective wiring - Defective magnet - Motor seriously dirty Fuse blows when magnet - Damaged or defective wiring switch is turned on - Wrong value fuse - Defective magnet switch - Defective control unit - Defective magnet Fuse blows when motor is - Damaged or defective wiring...
-
Page 23: Exploded Views & Spare Parts List
8. Exploded views & spare parts list 8.1 Exploded views... -
Page 26: Spare Parts List
032.0111 End Cover 032.0136 Screw for spring Panel screw BKVZ 45 020.0101 M4 x 8 032.0141 Spring Rear panel ProMac Housing incl. carbon 032.0241 brush holder 47 020.0063 Screw M5 x 20 032.0146-1 Carbon brush 220V 48 KSP.M/4 Tank holder 032.0116... - Page 27 No. Part no. Description No. Part no. Description 204 IMB.US2.5 Allen key 2.5 mm 208 SAF.MDMS Safety guard small 205 IMB.US3 Allen key 3.0 mm 209 020.0511 Bolt M5 x 10 206 IMB.US4 Allen key 4.0 mm 207 IMB.US5 Allen key 5.0 mm...
-
Page 28: Wiring Diagram
8.3 Wiring diagram...
