OPERATION MANUAL
MODEL:
* Please write down the model name.
(Refer to the rating label.)
* Bitte schreiben Sie den Modellnamen auf.
(Siehe Typenschild)
* Veuillez écrire le nom du modèle.
(Consultez l'étiquette des spécifi cations.)
* Anote el nombre de modelo.
(Consulte la etiqueta de califi cación).
* Annotare il nome del modello.
(Fare riferimento all'etichetta delle specifi che).
* Καταγράψτε το όνομα μοντέλου.
(Ανατρέξτε στην ετικέτα τεχνικών στοιχείων.)
* Registe o nome de modelo.
(Consulte a etiqueta de classifi cação.)
* Запишите название модели.
(См. на паспортной табличке.)
* Lütfen model adını not ediniz.
(Derece etiketine bakınız.)
PART No. 9387858099-01
AIR CONDITIONER (Wall Mounted type)
Before using this product, read these instructions thoroughly
and keep this manual for future reference.
BEDIENUNGSANLEITUNG
KLIMAANLAGE (Wandmontierter Typ)
Bevor Sie dieses Produkt verwenden, lesen Sie diese
Anweisungen sorgfältig durch und bewahren Sie diese
Anleitung für späteres Nachschlagen auf.
CLIMATISEUR (Type à montage mural)
Avant d'utiliser ce produit, veuillez lire attentivement ces
instructions. Conservez ce manuel pour référence future.
MANUAL DE FUNCIONAMIENTO
ACONDICIONADOR DE AIRE (Tipo montado en pared)
Antes de utilizar el producto, lea estas instrucciones detenida-
mente y conserve este manual para consultarlo en el futuro.
CONDIZIONATORE D'ARIA (Tipo montato a parete)
Prima di utilizzare l'apparecchio, leggere attentamente
le presenti istruzioni e conservare il manuale per poterlo
ΚΛΙΜΑΤΙΣΤΙΚΟ (Επιτοίχιος τύπος)
Προτού χρησιμοποιήσετε το προϊόν, διαβάστε προσεκτικά τις
παρούσες οδηγίες και φυλάξτε το παρόν εγχειρίδιο, ώστε να
μπορείτε να ανατρέχετε σε αυτό στο μέλλον.
MANUAL DE FUNCIONAMENTO
AR CONDICIONADO (Tipo mural)
Antes de utilizar este produto, leia atentamente estas instruções
e guarde este manual para referência futura.
РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ
КОНДИЦИОНЕР ВОЗДУХА (Настенного типа)
Перед эксплуатацией устройства внимательно
ознакомьтесь с данным руководством и сохраняйте его для
Bu ürünü kullanmadan önce verilen talimatları dikkatlice okuyun
ve daha sonra tekrar faydalanmak üzere saklayın.
OPERATION MANUAL
MODE D'EMPLOI
MANUALE DI ISTRUZIONI
consultare il futuro.
ΕΓΧΕΙΡΙΔΙΟ ΛΕΙΤΟΥΡΓΙΑΣ
использования в будущем.
KULLANIM KILAVUZU
KLİMA (Duvara Monte tip)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ASYG07KETEB and is the answer not in the manual?

Questions and answers

Related Manuals for Fujitsu ASYG07KETEB

Summary of Contents for Fujitsu ASYG07KETEB

  • Page 1 OPERATION MANUAL OPERATION MANUAL AIR CONDITIONER (Wall Mounted type) Before using this product, read these instructions thoroughly and keep this manual for future reference. BEDIENUNGSANLEITUNG KLIMAANLAGE (Wandmontierter Typ) Bevor Sie dieses Produkt verwenden, lesen Sie diese Anweisungen sorgfältig durch und bewahren Sie diese Anleitung für späteres Nachschlagen auf.

  • Page 2: Table Of Contents

    [Original Instructions] Contents CAUTION This symbol shows that the operating manual should 1. SAFETY PRECAUTIONS .......... 1 be read carefully. CAUTION 2. PREPARATION ............2 This symbol shows that a service personnel should 3. NAME OF PARTS ............. 3 be handling this equipment with reference to the 3.1.

  • Page 3: Preparation

    WARNING CAUTION • This product is not intended for use by persons • Do not touch the aluminum fi ns of heat exchanger (including children) with reduced physical, sensory built-in this product to avoid personal injury when you or mental capabilities, or lack of experience and maintain the unit.

  • Page 4: Name Of Parts

    Battery loading and remote controller preparation Color Operation or condition Name (R03/LR03/AAA x 2) Operation Green Normal operation Timer Orange Timer operation Economy Green Economy operation 10 °C Heat operation WLAN Orange WLAN control is active. Put batteries as shown in the fi gure above. (optional) Press to start clock setting.
  • Page 5 CAUTION • To prevent malfunction or damage of the remote controller: - Place remote controller at where will not be exposed to direct sunlight or excessive heat. - Remove batteries if the product is not going to be used for an extended period. •...

  • Page 6: Basic Operations

     Horizontal airfl ow direction setting 4. BASIC OPERATIONS CAUTION  3 steps to start operation Before you adjust the horizontal airfl ow direction, make 1. Press to start or stop the operation. sure that the vertical airfl ow direction louver has been stopped completely.

  • Page 7: Weekly Timer

    • You cannot the Weekly timer and the other timers simultaneously. 5. Press to complete the timer setting. If you use the On/Off timer, the Program timer, or the Sleep timer Be close to the indoor unit. while the Weekly timer is activated, the Weekly timer will be deactivated.

  • Page 8: Energy Saving Operation

    During the Sleep timer operation, the setting temperature changes as 8.2. Outdoor Unit Low Noise operation the following fi gure. In Heating mode In Cooling or Dry mode The Outdoor Unit Low Noise operation lowers noise from the outdoor 1 °C 2 °C 3 °C 4 °C unit.

  • Page 9: Cleaning And Care

    • To change the air conditioner custom code, contact an authorized Cleaning air fi lter service personnel (initially set to A). • If you do not press any buttons for 30 seconds after the custom 1. Open the intake grille until it snaps. code is displayed, the display returns to the clock display.

  • Page 10: General Information

    7. Set the new or washed air cleaning fi lters into the air After extended non-use of the unit cleaning fi lter holders. If you have shut down the indoor unit for 1 month or more, perform the NOTES: Use the Apple-catechin fi lter as soon as possible after opening Fan mode operation for half a day to dry the internal parts thoroughly the package.

  • Page 11: Optional Parts

     Indoor unit temperature and humidity range Google Play is a registered trademark of Google Inc. App Store is a service mark of Apple Inc., registered in the U.S. and Permissible ranges of temperature and humidity are as follows: other countries. Indoor temperature Cooling/Dry [°C]...
  • Page 12 Step 4. Air conditioner registration (pairing of WLAN Temporary deactivation of WLAN adapter) NOTES: If you do not press any buttons of the remote controller for 60 NOTES: seconds, the remote controller display will return to the original • Before starting this setting, reconnect the power supply of the air display.

  • Page 13: Multi-Split Type Air Conditioner

    12.4. Multi-split type air conditioner Does not operate at all. □ Has there been a power outage? This indoor unit can be connected to a multi-split type outdoor In this case, the unit restarts automatically after the power supply unit. The multi-split type air conditioner allows multiple indoor is resumed.
  • Page 14  State of indicator lamps Mist or steam is emitted from the unit. : The instruction is relating to the WLAN control (optional). □ <In the Cooling or Dry mode> A thin mist may be generated by condensation formed with sudden cooling process. Lighting pattern: Blinking, Any state...
