  • Page 1 LEGO HOCUS POCUS THE SANDERSON ® SISTERS’ COTTAGE #21341 LIGHT KIT INSTALLATION GUIDE...
  • Page 2 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® Light My Bricks LEGO HOCUS POCUS THE SANDERSON ® SISTERS’ COTTAGE 21341 INSTALLATION GUIDE Hi There! We’re here to help you get started on the LEGO ®...
  • Page 3 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® PACKAGE CONTENTS: Individual Bags Mixed Components 1 • 3 x White 15cm Bit Light 5 x Micro 4-Port Expansion Board * • 2 x White 30cm Bit Light 3 x 6-Port Expansion Board 1 x Scary Effects Board •...

  • Page 4: Table Of Contents

    LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® Contents Before You Begin Blueprint Instructions Final Product Troubleshooting Contact CONTENTS...

  • Page 5: Before You Begin

    LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® Before You Begin Laying cables in between Connecting Cable and underneath bricks Connectors To Expansion Boards Cables can fit in between and underneath LEGO bricks, plates, and tiles providing ®...
  • Page 6 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® Before You Begin Connecting Cable Connecting Micro Cable Connectors To Strip Lights Connectors To Micro Expansion Board Ports Take extra care when inserting connectors to ports on the Strip Lights. Connectors Take extra care when inserting the can be inserted only one way.
  • Page 7 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® Before You Begin Installing Bit Lights Under Lego® Bricks And Plates When installing Bit Lights under LEGO ® pieces, ensure they are placed the correct way up (Yellow LED component exposed). You can either place them directly on top of LEGO studs or in between.
  • Page 8 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® Before You Begin The Symbols Used In This Guide Connect Turn/ Flip When going through the following guide you will Used when you need to Will be found in the top left come across symbols and formats that will assist connect a LEGO piece or LMB corner when the set needs to...
  • Page 9 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® Before You Begin General Note Repeat Step NOTE This is a sample note that is Repeat the previous step eg. used anywhere in this guide. It Make a spotlight, then make a Take the 5cm Connecting Cable will explain a difficult section from the 4-Port Micro Expansion...

  • Page 10: Blueprint

    LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® BLUEPRINT BLUEPRINT...

  • Page 11: Instructions

    LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® INSTRUCTIONS To ensure a smooth installation of your light kit, please read and follow each step carefully. If you run into any issues, please refer to the online troubleshooting guide.
  • Page 12 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® NOTE Ensure at least one Technic Pin is connected to to the main cottage building INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 13 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 14 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 15 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 16 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® Orange 30cm Large Bit Light INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 17 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® 6-Port Expansion Board 5cm Connecting Cable NOTE Connect the Orange 30cm Large Bit Light into the “OUT” port of the Flicker Effects Board Flicker Effects Board NOTE Connect the 5cm Connecting Cable from the 6-Port Expansion Board into the “IN”...
  • Page 18 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® White 15cm Micro Bit Light NOTE Repeat the same process for the other two candles INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 19 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® 15cm Connecting Cable 4-Port Micro Expansion Board 5cm Connecting Cable NOTE Connect the three White 15cm Micro Bit Lights (from the candles) to the Micro 4-Port Expansion Board 4-Port Micro Expansion Board INSTRUCTIONS DISCONNECT...
  • Page 20 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® NOTE Wrap the Micro Bit Light cables around the Board to reduce cable slack Green 30cm Bit Light Plate, Round 1x1 with Open Stud - Black INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT...
  • Page 21 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® Tile, Modified 1x1 with Open O Clip - Black NOTE Thread the Green 30cm Bit Light from the cauldron and the 15cm Connecting Cable from the Micro Expansion Board from Step 9 through the following hole as shown...
  • Page 22 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® NOTE NOTE While pulling the cables to reduce cable slack, ensure that Ensure the Micro Expansion the Micro Expansion Board Board is still concealed in the is still hidden in the following following position position NOTE...
  • Page 23 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® NOTE Connect the shorter cable to the ‘OUT’ port of the Flicker Effects Board and the longer cable to the 6-Port Expansion Board NOTE Use the LEGO Removal Tool to assist in disconnecting parts USB Power Cable INSTRUCTIONS...
  • Page 24 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® NOTE NOTE Rest the USB Power Cable in Connect the USB Power Cable the following position before to the 6-Port Expansion Board routing the cable NOTE Ensure the connector head of the USB Power Cable reaches the following Green Plate NOTE...
  • Page 25 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® If you experience any issues with the lights not working and suspect an issue with a component, please try a different port on the expansion board to verify where the fault lies (with the light or expansion board).
  • Page 26 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® NOTE Ensure the 5cm Connecting Cable between the Micro Expansion Board is positioned as shown Plate 1x2 - Black 15cm Connecting Cable INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT...
  • Page 27 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® NOTE Twist the candle holder to reduce cable slack NOTE Run the loose 15cm Connecting Cable and Micro Bit Lights from the candles through the following area before reconnecting the stairs INSTRUCTIONS DISCONNECT...
  • Page 28 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® 6-Port Expansion Board White 30cm Bit Light INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 29 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® NOTE Thread the cable from the Candle in between the studs and up the wall NOTE If you are having trouble reconnecting the Barrel and completing the next Step, temporarily disconnect the entire roof.
  • Page 30 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® Pink 30cm Large Bit Light INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 31 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® NOTE Tightly pull the cables upwards to reduce slack before twisting the cables together INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 32 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® NOTE From now on, the wheel can only rotate clockwise. Test the rotation of the wheel INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 33 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® White 15cm Micro Bit Light INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 34 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® 30cm Connecting Cable NOTE Connect the 30cm Connecting Cable into the “OUT” port of the Flicker Effects Board 4-Port Micro Expansion Board INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT...
  • Page 35 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® NOTE Keep the boards in the following position as the 30cm Connecting Cable is being routed Plate 1x2 - Black INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID...
  • Page 36 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® 2x Adhesive Square Cool White 15cm Bit Light INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 37 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® 15cm Connecting Cable 2x Adhesive Square NOTE Connect the Cool White 15cm Connecting Cable to the 6-Port Expansion Board INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 38 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® NOTE Connect to a 5V USB Power Bank, 5V USB Wall Adaptor, or USB to AA Battery Pack (sold separately) If you experience any issues with the lights not working and suspect an issue with a component, please try a different port on the expansion board to verify...
  • Page 39 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® NOTE Pull the loose 15cm Connecting Cable to the left as shown 6-Port Expansion Board INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 40 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® Scary Flicker Effects Board 5cm Connecting Cable NOTE Connect the 5cm Connecting Cable into the “IN” port of the Scary Flicker Effects Board NOTE Connect the other end of the 5cm Connecting Cable to the 6-Port Expansion Board INSTRUCTIONS...
  • Page 41 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® White 30cm Bit Light Plate, Round 1x1 - Black INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 42 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® Cool White 30cm Bit Light INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 43 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® Plate, Round 1x1 with Open Stud - Black Tile, Modified 1x1 with Open O Clip Plate, Round 1x1 with Bar Handle - Black - Black INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL...
  • Page 44 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® Cool White 30cm Bit Light Plate, Round 1x1 with Open Stud - Black Tile, Modified 1x1 with Open O Clip Plate, Round 1x1 with Bar Handle - Black - Black INSTRUCTIONS DISCONNECT...
  • Page 45 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 46 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® Cool White 30cm Bit Light Plate, Round 1x1 with Open Stud - Black Plate, Round 1x1 with Bar Handle Arm Skeleton, Bent with Clips at - Black 90 degrees (Vertical Grip) - Black Plate, Round 1x1 with Bar Handle - Black...
  • Page 47 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® NOTE Hold down the cogwheel on the inside of the cottage while simulatenously disconnecting the wheel Blue 15cm Bit Light INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID...
  • Page 48 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® NOTE Hold down the cogwheel on the inside of the cottage while simulatenously reconnecting the wheel INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 49 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® NOTE Connect the indicated Cool White 30cm Bit Light (spotlight) in the previous picture to the the ‘OUT’ port of the Scary Flicker Effects Board NOTE 50cm Connecting Cable Connect the shorter cable to the 6-Port Expansion Board and the longer cable to the...
  • Page 50 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® NOTE Hold the 6-Port Expansion Board in the following position while threading the 50cm Connecting Cable all the way through the following gap NOTE Connect the top cable only to the 6-Port Expansion Board INSTRUCTIONS DISCONNECT...
  • Page 51 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® NOTE Take the indicated cable (final spotlight) 50cm Connecting Cable NOTE NOTE Hold the Expansion Board in Connect the cable to the ‘OUT’ the following position while port of the Scary Flicker Effects the 50cm Connecting Cable is Board...
  • Page 52 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® NOTE Continue to hold the 6-Port Expansion Board in the following position 2x Adhesive Square 2x Adhesive Square INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 53 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® NOTE Connect to a 5V USB Power Bank, 5V USB Wall Adaptor, or USB to AA Battery Pack (sold separately) If you experience any issues with the lights not working and suspect an issue with a component, please try a different port on the expansion board to verify...
  • Page 54 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® NOTE If you are having trouble with this following Step, you can simply disconnect the roof temporarily 2 x White 15cm Bit Light INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT...
  • Page 55 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® Flicker Effects Board NOTE Connect both White 15cm Bit Lights to the ‘OUT’ port of the Flicker Effects Board INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 56 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® White 15cm Bit Light NOTE Connect the White 15cm Bit Light to the ‘OUT’ port of the Flicker Effects Board NOTE Connect the loose 50cm Connecting Cable from Step 41 to the ‘IN’...
  • Page 57 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® NOTE Conceal any slack from the 50cm Connecting Cable beneath the building INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 58 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® NOTE Connect to a 5V USB Power Bank, 5V USB Wall Adaptor, or USB to AA Battery Pack (sold separately) If you experience any issues with the lights not working and suspect an issue with a component, please try a different port on the expansion board to verify...
  • Page 59 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 60 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® Green 15cm Micro Bit Light NOTE Repeat the same process for the opposite hand INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 61 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® 4-Port Micro Expansion Board INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 62 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® Cool White 30cm Bit Light Plate, Round 1x1 with Open Stud - Black Plate, Round 1x1 with Bar Handle Arm Skeleton, Bent with Clips at - Black 90 degrees (Vertical Grip) - Black INSTRUCTIONS DISCONNECT...
  • Page 63 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® Plate 1x2 - Black 2x Adhesive Square INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 64 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 65 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® NOTE Connect to a 5V USB Power Bank, 5V USB Wall Adaptor, or USB to AA Battery Pack (sold separately) If you experience any issues with the lights not working and suspect an issue with a component, please try a different port on the expansion board to verify...

  • Page 66: Final Product

    LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® FINAL PRODUCT This finally completes installation of the Light My Bricks LEGO Hocus Pocus The Sanderson Sisters’ Cottage 21341 Light Kit. ® FINAL PRODUCT...

  • Page 67: Troubleshooting

    LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® TROUBLESHOOTING Light My Bricks lighting To prevent unnecessary If you are experiencing kits contain individual damage to components, issues with your Light components that are very we highly recommend that...
  • Page 68 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® Troubleshooting Firstly, ensure that the Check for AA batteries batteries have power using a using the AA battery pack battery charge gauge. Inside the battery pack are symbols indicating which direction the AA battery If the batteries have no power, should be inserted.
  • Page 69 HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® Troubleshooting Check Your Wires In order for Light My Bricks components to fit If the wiring is detached from the LED itself, the in between and underneath LEGO bricks, the light will not operate.
  • Page 70 LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® Troubleshooting Check Your Expansion Board A short circuit can also result in overheating of the board, cable or Ports/ Strip Light Ports / batteries. If you suspect a short circuit, Effects Board Ports DISCONNECT POWER IMMEDIATELY Batteries can fail, catch fire, or even...

  • Page 71: Contact

    LEGO HOCUS POCUS THE SANDERSON SISTERS’ COTTAGE 21341 LIGHT KIT INSTALL GUIDE ® CONTACT US If you have an enquiry regarding the online shop, our products or a general enquiry please refer to our Frequently Asked Questions webpage here. Alternatively, you can contact our Customer Services team by visiting our online support portal here.
  • Page 72 © 2023 Light My Bricks Pty Ltd - Head Office: 4/26 Rushdale Street, Knoxfield VIC 3180, Australia. Phone: +61 420 643 543 | All Rights Reserved | Light My Bricks™ sell LED lighting kits only. All LEGO sets featured in images are sold ®...
