LEGO® VINCENT VAN GOGH -
THE STARRY NIGHT #21333 LIGHT KIT
INSTALLATION GUIDE

Advertisement

loading
Need help?

Need help?

Do you have a question about the 21333 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LIGHT MY BRICKS 21333

Summary of Contents for LIGHT MY BRICKS 21333

  • Page 1 LEGO® VINCENT VAN GOGH - THE STARRY NIGHT #21333 LIGHT KIT INSTALLATION GUIDE...
  • Page 2 LEGO VINCENT VAN GOGH - THE STARRY NIGHT 21333 LIGHT KIT INSTALL GUIDE Light My Bricks LEGO VINCENT VAN GOGH - THE STARRY NIGHT 21333 INSTALLATION GUIDE Hi There! We’re here to help you get started on the LEGO Vincent Van Gogh - The Starry Night 21333 Light Kit.
  • Page 3 LEGO VINCENT VAN GOGH - THE STARRY NIGHT 21333 LIGHT KIT INSTALL GUIDE ASSORTED BRICKS: PACKAGE CONTENTS: • 2x Plate 1x2 MW Handle On End - Black • 3x Arm Skeleton, Bent with Clips at 90 degrees - Black 8x White 30cm Bit Light * •...

  • Page 4: Table Of Contents

    LEGO VINCENT VAN GOGH - THE STARRY NIGHT 21333 LIGHT KIT INSTALL GUIDE Contents Before You Begin Blueprint Instructions Final Product Troubleshooting Contact CONTENTS...

  • Page 5: Before You Begin

    LEGO VINCENT VAN GOGH - THE STARRY NIGHT 21333 LIGHT KIT INSTALL GUIDE Before You Begin Laying cables in between Connecting Cable and underneath bricks Connectors To Expansion Boards Cables can fit in between and underneath LEGO® bricks, plates, and tiles providing...
  • Page 6 LEGO VINCENT VAN GOGH - THE STARRY NIGHT 21333 LIGHT KIT INSTALL GUIDE Before You Begin Connecting Cable Connecting Micro Cable Connectors To Strip Lights Connectors To Micro Expansion Board Ports Take extra care when inserting connectors to ports on the Strip Lights. Connectors Take extra care when inserting the can be inserted only one way.
  • Page 7 LEGO VINCENT VAN GOGH - THE STARRY NIGHT 21333 LIGHT KIT INSTALL GUIDE Before You Begin Installing Bit Lights Under Lego® Bricks And Plates When installing Bit Lights under LEGO® pieces, ensure they are placed the correct way up (Yellow LED component exposed).

  • Page 8: Blueprint

    LEGO VINCENT VAN GOGH - THE STARRY NIGHT 21333 LIGHT KIT INSTALL GUIDE BLUEPRINT INSTRUCTIONS...

  • Page 9: Instructions

    LEGO VINCENT VAN GOGH - THE STARRY NIGHT 21333 LIGHT KIT INSTALL GUIDE INSTRUCTIONS To ensure a smooth installation of your light kit, please read and follow each step carefully. If you run into any issues, please refer to the online troubleshooting guide.
  • Page 10 LEGO VINCENT VAN GOGH - THE STARRY NIGHT 21333 LIGHT KIT INSTALL GUIDE Gently disconnect the frame from the painting as the painting will fall if not supported CONNECT / Legend DISCONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST...
  • Page 11 LEGO VINCENT VAN GOGH - THE STARRY NIGHT 21333 LIGHT KIT INSTALL GUIDE Use the LEGO Brick Separator Tool or similar to pry parts Carefully pry this 1x1 Round Plate Open Stud - White 30cm Bit Light section apart from...
  • Page 12 LEGO VINCENT VAN GOGH - THE STARRY NIGHT 21333 LIGHT KIT INSTALL GUIDE Plate 1x1 Mod Rounded w Plate 1x2 MW Handle On End Handle - Black - Black Arm Skeleton, Bent with Clips at 90 degrees - Black CONNECT /...
  • Page 13 LEGO VINCENT VAN GOGH - THE STARRY NIGHT 21333 LIGHT KIT INSTALL GUIDE Plate 1x2 MW Handle On End Plate 1x1 Mod Rounded w - Black Handle - Black CONNECT / Legend DISCONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID...
  • Page 14 LEGO VINCENT VAN GOGH - THE STARRY NIGHT 21333 LIGHT KIT INSTALL GUIDE Yellow 30cm Bit Light 1x1 Round Plate - Trans Yellow CONNECT / Legend DISCONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON RECONNECT...
  • Page 15 LEGO VINCENT VAN GOGH - THE STARRY NIGHT 21333 LIGHT KIT INSTALL GUIDE Yellow 30cm Bit Light Pull the spotlight cables towards the back as shown CONNECT / Legend DISCONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST...
  • Page 16 LEGO VINCENT VAN GOGH - THE STARRY NIGHT 21333 LIGHT KIT INSTALL GUIDE 12-Port Expansion Board CONNECT / Legend DISCONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON RECONNECT INSTRUCTIONS...
  • Page 17 LEGO VINCENT VAN GOGH - THE STARRY NIGHT 21333 LIGHT KIT INSTALL GUIDE Yellow 30cm Bit Light 1x1 Round Plate - White 1x1 Round Plate - Trans Orange CONNECT / Legend DISCONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST...
  • Page 18 LEGO VINCENT VAN GOGH - THE STARRY NIGHT 21333 LIGHT KIT INSTALL GUIDE 1x1 Round Plate - White Yellow 30cm Bit Light Large Warm White 30cm Bit Light Connect all the three cables from step 12 and 13 to the 12-Port...
  • Page 19 LEGO VINCENT VAN GOGH - THE STARRY NIGHT 21333 LIGHT KIT INSTALL GUIDE If you experience any issues with the lights not working and suspect an issue with a component, please try a different port on the expansion board to verify where the fault lies (with the light or expansion board).
  • Page 20 LEGO VINCENT VAN GOGH - THE STARRY NIGHT 21333 LIGHT KIT INSTALL GUIDE Ensure the three 1x1 Round Plate - Trans Clear cables are placed in between studs and running out the back White 30cm Bit Light CONNECT / Legend...
  • Page 21 LEGO VINCENT VAN GOGH - THE STARRY NIGHT 21333 LIGHT KIT INSTALL GUIDE CONNECT / Legend DISCONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON RECONNECT INSTRUCTIONS...
  • Page 22 LEGO VINCENT VAN GOGH - THE STARRY NIGHT 21333 LIGHT KIT INSTALL GUIDE Large Cool White 30cm Bit Light 1x1 Round Plate - Trans Yellow 1x1 Round Plate - White CONNECT / Legend DISCONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID...
  • Page 23 LEGO VINCENT VAN GOGH - THE STARRY NIGHT 21333 LIGHT KIT INSTALL GUIDE 1x1 Round Plate - White Large Warm White 30cm Bit Light CONNECT / Legend DISCONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON...
  • Page 24 LEGO VINCENT VAN GOGH - THE STARRY NIGHT 21333 LIGHT KIT INSTALL GUIDE 1x1 Round Plate - Trans Blue 1x1 Round Plate - White White 30cm Bit Light Large Warm White 30cm Bit Light CONNECT / Legend DISCONNECT TURN / FLIP...
  • Page 25 LEGO VINCENT VAN GOGH - THE STARRY NIGHT 21333 LIGHT KIT INSTALL GUIDE White 30cm Bit Light 1x1 Round Plate - Trans Clear 1x1 Round Plate - Trans Orange CONNECT / Legend DISCONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID...
  • Page 26 LEGO VINCENT VAN GOGH - THE STARRY NIGHT 21333 LIGHT KIT INSTALL GUIDE White 30cm Bit Light Yellow 30cm Bit Light 1x1 Round Plate - White CONNECT / Legend DISCONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST...
  • Page 27 LEGO VINCENT VAN GOGH - THE STARRY NIGHT 21333 LIGHT KIT INSTALL GUIDE 1x1 Round Plate - White Large Warm White 30cm Bit Light CONNECT / Legend DISCONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON...
  • Page 28 LEGO VINCENT VAN GOGH - THE STARRY NIGHT 21333 LIGHT KIT INSTALL GUIDE Remove the Adhesive Square backing after sticking to the Board 30cm Connecting Cable 8-Port Expansion Board 2x Adhesive Squares CONNECT / Legend DISCONNECT TURN / FLIP DIRECTIONAL...
  • Page 29 LEGO VINCENT VAN GOGH - THE STARRY NIGHT 21333 LIGHT KIT INSTALL GUIDE Remove the 2x Adhesive Squares Adhesive Square backing after sticking to the Board CONNECT / Legend DISCONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST...
  • Page 30 LEGO VINCENT VAN GOGH - THE STARRY NIGHT 21333 LIGHT KIT INSTALL GUIDE Put the USB Power Cable through the picture frame and out the side. Then lay the painting down in the frame CONNECT / Legend DISCONNECT TURN / FLIP...
  • Page 31 LEGO VINCENT VAN GOGH - THE STARRY NIGHT 21333 LIGHT KIT INSTALL GUIDE If you experience any issues with the lights not working and suspect an issue with a component, please try a different port on the expansion board to verify where the fault lies (with the light or expansion board).

  • Page 32: Final Product

    LEGO VINCENT VAN GOGH - THE STARRY NIGHT 21333 LIGHT KIT INSTALL GUIDE FINAL PRODUCT This finally completes installation of the Light My Bricks LEGO Vincent Van Gogh - The Starry Night 21333 Light Kit. FINAL PRODUCT...

  • Page 33: Troubleshooting

    LEGO VINCENT VAN GOGH - THE STARRY NIGHT 21333 LIGHT KIT INSTALL GUIDE TROUBLESHOOTING Light My Bricks lighting To prevent unnecessary If you are experiencing kits contain individual damage to components, issues with your Light components that are very we highly recommend that...
  • Page 34 LEGO VINCENT VAN GOGH - THE STARRY NIGHT 21333 LIGHT KIT INSTALL GUIDE Troubleshooting Firstly, ensure that the Check For CR2032 Batteries batteries have power using a Using The Flat Battery Pack battery charge gauge. Inside the battery pack is a symbol...
  • Page 35 LEGO VINCENT VAN GOGH - THE STARRY NIGHT 21333 LIGHT KIT INSTALL GUIDE Troubleshooting Check For Cr2032 Batteries Check for AA batteries Using The Round Battery using the AA battery pack Pack Inside the battery pack are symbols indicating which direction the AA battery Inside the battery pack is a symbol indicating should be inserted.
  • Page 36 LEGO VINCENT VAN GOGH - THE STARRY NIGHT 21333 LIGHT KIT INSTALL GUIDE Troubleshooting Check Your Wires In order for Light My Bricks components to fit If the wiring is detached from the LED itself, the in between and underneath LEGO® bricks, the light will not operate.
  • Page 37 LEGO VINCENT VAN GOGH - THE STARRY NIGHT 21333 LIGHT KIT INSTALL GUIDE Troubleshooting Check Your Expansion Board A short circuit can also result in overheating of the board, cable or Ports/ Strip Light Ports / batteries. If you suspect a short circuit,...

  • Page 38: Contact

    LEGO VINCENT VAN GOGH - THE STARRY NIGHT 21333 LIGHT KIT INSTALL GUIDE CONTACT US If you have an enquiry regarding the online shop, our products or a general enquiry please refer to our Frequently Asked Questions webpage here. Alternatively, you can contact our Customer Services team by visiting our online support portal here.
