5. Insert one end of the flexible hose into
the main body as shown until you hear a
'click'. Then run the flexible hose over the
hose storage. Insert the other end of the
hose into the lower hose connection as
shown until you hear a 'click'.
II
I
6. Store the extension wand under the hose
storage as shown. Make sure the smaller
end of the extension wand is upward.
Push and snap into place.
ASSEMBLY INSTRUCTIONS
Hose
Storage
III
Lower
Hose
Connection
- 9 -
7. Insert the crevice tool onto the accessory
storage post located on the back of the
main body. The Pet HandiMate
in the attachment holder on the wand.
II
I
8. Make sure the upper cord hook is in
the proper position as shown. Wrap the
power cord loosely around the upper
and lower cord hooks.
NOTE:
Make sure to wrap the power
cord around the upper cord hook first, and
then around the lower cord hook to avoid
damaging the power cord.
®
is stored
Upper
Cord
Hook
Hide quick links:
Advertisement
Chapters
Table of Contents
Need help?
Do you have a question about the FeatherLite DU1096 and is the answer not in the manual?
Questions and answers
I can’t get the bottom off to change the belt. All screws are out
To remove the bottom of a Kenmore FeatherLite DU1096 to change the belt, follow these steps:
1. Use a Phillips head screwdriver to remove the six screws from the belt cover and the lower plate.
2. Remove the belt cover from the floor nozzle.
3. Lift the lower plate combined with the brushroll. Be cautious, as there are sharp edges inside to prevent hair entanglement, and avoid putting any part of your body into the floor brush during maintenance.
Proceed with changing the belt as described in the manual.
This answer is automatically generated
