ATX PS/2 Keyboard and
PS/2 Mouse Ports
The ATX PS/2 keyboard and the
PS/2 mouse are located on J28.
See Table 5-13 for pin definitions.
(The mouse port is above the key-
board port. See Figure 5-12.)

Universal Serial Bus (USB)

Two Universal Serial Bus connec-
tors are located on U38. USB1 is
the bottom connector and USB2 is
the top connector. Refer to Table
5-14 for pin definitions.

Extra USB Connectors

(J105/J106)
J105 is USB3, and J106 is USB4.
You will need a USB cable (not in-
cluded) to use this connection. Re-
fer to Table 5-14 for pin definitions.

LAN1/LAN2 Ports

Two Ethernet ports (designated
NIC1 and NIC2) are located beside
the VGA port on the I/O backplane.
These ports accept RJ45 type
cables. There are two jumpers for
the LAN1/LAN2 ports: JP8: NIC 1
Enable/Disable(Open: enable),
JP24: NIC2 Enable/Disable (Open:
enable). Each indicate a success-
ful connection (yellow) and activ-
ity (green).
SLED1 (SCSI LED) Indicator
The SLED connector is used to pro-
vide an LED indication of SCSI ac-
tivity. Refer to Table 5-15 for con-
necting the SCSI LED.
Manual
5-16
T a b le 5 -1 3
P S /2 K e yb o a rd
a n d M o u s e P o rt
P in D e fin itio n s
(J 2 8 )
P in
N umber D efinition
1 D ata
2 N C
3 G round
4 V C C
5 C lock
6 N C
T a b le 2 -1 4
U n ive rs a l S e ria l B u s P in D e fin itio n s
U S B 1
P in P in
N umber D efinition N umber
1 +5V 1
2 P 0- 2
3 P 0+ 3
4 G round 4
5 N /A 5
RJ45 Ethernet Port
T a b le 5 -1 5
S L E D 1 (S C S I L E D ) P in
D e fin itio n s
P in
N umber D efinition
1
2
3
4
U S B 2
D efinition
+5V
P 0-
P 0+
G round
K ey
+
-
-
+
