PEAKTOP YB0565GC Quick Start Manual

Unpack all parts from Styrofoam and bubble wrap inside the carton to ensure there are no missing or damaged parts.
If any parts are missing or damaged, do not attempt to assemble or use the product. Please contact customer service for replacement.

CARTON CONTENTS:

Part# Description
01. Top fountain
02. Screw
03. Washer (small)
04. Nut
05. Washer(large)
06. Butterfly nut
07 Basin
08. Pump

TOOLS REQUIRED FOR ASSEMBLY:

Wrench (Not Included)

ASSEMBLY INSTRUCTIONS:

Note: This item is fragile. Please be handle gently and with care. It is
recommended that two adults assemble the product in order to
avoid injury or damaging the item.
1. Unpack the contents of the box and check to make sure that all items are
accounted for and in good condition.
2. Select a flat, level surface for the assembly and final location of your fountain.
3. Place the top fountain on the floor upside down. Lead the bolts with the small
washers through the two mounting holes from inside of the top fountain out. Place an additional washer and nut over each bolt and tighten the buts with a
wrench. (Fig.1)
4. Place the basin on a flat, level surface. Align the bolts at the bottom of top fountain with the holes on the pedestal in the basin and place the top fountain
onto the pedestal. Place the large washers over the bolts and tighten the butterfly nuts to secure the top fountain to the basin pedestal. (Fig.2)
5. Insert the water supply tube from the bottom of top fountain into the pump outlet and then place the pump in the basin upright through the pump gate of
the pedestal. (Fig 3)
6. Add clean water into the basin. The water level should be approximately 30mm below the top edge of the basin. (Fig 4)
7. Connect the pump to the proper electrical outlet and the product will begin to function as intended. Gently sweep across the water surface to achieve
even water flow across the surface. (Fig 4)
8. After the initial set up, observe the flow of the water over the rim of the water pot. It may be necessary to adjust the level of the basin accordingly to gain
an even flow around the rim of the top fountain.
9. To eliminate the possibility of water damage to areas around your fountain, check for leaks and excessive splashing after the initial setup of your fountain.
It is highly recommended that this fountain be placed in an area that will not be damaged should the area come in contact with liquid.
10. Do not leave your fountain running for extended periods of time or when no one is present to observe the performance.
11. Check the area around your fountain on a regular basis to ensure that there is no leakage.
NOTE:
The diagrams shown are for illustrative purposes only and are not to scale.
Vendor Item # YB0565GC (084 09 3479)
Vase Fountain
Questions, Problems, Missing Parts? Before returning to your retailer,
PLEASE CALL CUSTOMER SERVICE at (866) 728-6187
9am – 5pm EST, Mon – Fri or e-mail customerservice@srg-usa.com.
PLEASE READ ALL INSTRUCTIONS BEFORE ASSEMBLY.
