Dear Customer,
Thank you for choosing this quality product from ASKO.
We hope it will meet your expectations and fulfil your needs for many years to
come. Scandinavian design combines clean lines, everyday functionality and
high quality. These are key characteristics of all our products and the reason
they are greatly appreciated throughout the world.
To get the most from your new dishwasher, we recommend that you read the
operating instructions before using the dishwasher. The operating instructions
also include information on how you can help protect the environment.
Operating Instructions
Dishwasher
ASKO D5457
Advertisement
Table of Contents
Related Manuals for Asko D5457
Summary of Contents for Asko D5457
- Page 1 Dear Customer, Thank you for choosing this quality product from ASKO. We hope it will meet your expectations and fulfil your needs for many years to come. Scandinavian design combines clean lines, everyday functionality and high quality. These are key characteristics of all our products and the reason they are greatly appreciated throughout the world.
-
Page 2: Table Of Contents
Contents Front panel Troubleshooting Safety instructions Technical information Before washing for the first time Installation Loading the dishwasher Service Using the dishwasher Program chart Settings Your notes Care and cleaning Front panel The panel is fitted with touch buttons with audible feedback (see the chapter Settings). 12 13 Program selector Rinse &... -
Page 3: Safety Instructions
Safety instructions General WARNING! Read the operating instructions and keep them in a safe place! Dishwasher detergents are strongly alkaline. They can be Never use the dishwasher for any purpose other than that extremely dangerous if swallowed. Avoid contact with skin and specified in these operating instructions. -
Page 4: Before Washing For The First Time
Before washing for the first time Disposal Program key When the dishwasher has reached the end of its service life Some dishwashers include program keys in different languages. and is to be disposed of, it should immediately be made Attach the program key in the desired language to the top of the unusable. -
Page 5: Loading The Dishwasher
Loading the dishwasher Economic dishwashing Upper basket and knife basket Run programs only with a full load Place glasses, cups, bowls, side plates and saucers in the upper basket. Wine glasses are placed on the wine glass shelf (if fitted). Wait to run a program until the dishwasher is full. - Page 6 Knife basket Lower basket Cutlery basket Place plates, side plates, serving dishes, pots and cutlery (in the cutlery basket) in the lower basket. Place cutlery with the handles facing down, except for knives, Place pots and pans in the rear left of the lower basket to best and spread them out as much as possible.
-
Page 7: Using The Dishwasher
Using the dishwasher Positioning of cutlery basket lid (in upper basket) Add detergent The cutlery basket lid can be removed and used, for example, as an extra cutlery basket in the upper basket (see below). 1 Prewash detergent compartment 2 Main wash detergent compartment Detergent is added according to water hardness. - Page 8 Daily wash High temperature A program suitable for day-to-day dishwashing. This program Activate this option for improved dishwashing results. The can also clean dried leftovers, but is not intended for burnt food, machine then uses a higher temperature for the main wash. This such as on oven dishes.
- Page 9 Time remaining Do you want to add more dishes? Once you have selected a program and options, the display Open the door. The dishwasher stops automatically. Add the indicates how long the program took the last time it was used. dishes, close the door and the dishwasher continues the program.
-
Page 10: Settings
Settings Do as follows to open the settings menu: Turn off the dishwasher using the main power switch. Wait about five seconds. Then press the main power switch again. Wait until the numbers appear in the right-hand display before continuing to the next step. - Page 11 Button press Options Settings Description Operation volume This sound is used to confirm each button press. (Off) (Low) (High) Press Start/Stop to save the setting value and continue to the next setting. LCD contrast For adjusting the contrast of the display. (Low) (High) Press Start/Stop to save the setting value and continue to the next setting.
-
Page 12: Care And Cleaning
Care and cleaning Coarse filter NOTE! The coarse filter traps larger food particles, which cannot get The dishwasher must not be used without the filter in place! past the drainage pump. Empty the coarse filter as necessary. Diswashing efficiency can be affected if the course filter is 1 Lift the coarse filter by the handle. - Page 13 Door When cleaning the edge around the door, use only a slightly damp cloth (with a little cleaner if necessary). WARNING! Do not use a spray bottle or the like around the door lock. This is to ensure that water does not penetrate the door catch and come into contact with the electrical components.
-
Page 14: Troubleshooting
Troubleshooting Display Type of fault Action Overfilling Call the service division. Water outlet fault See "Water remains in the dishwasher" in the table below. Water inlet fault Check that the water tap is on. Check whether dishwasher inlet hose is connected to a pressure limiting valve (some pressure limiting valves may restrict the supply of water to the dishwasher). - Page 15 Problem Possible causes Action Spots left after washing. Lipstick and tea can be difficult to wash off. Use a detergent with a bleaching agent. Rattling sound when dishwashing. The dishes are not correctly placed or the Check that the dishes are placed securely. spray arms are not rotating.
- Page 16 Problem Possible causes Action Cannot close door. The baskets are not correctly positioned. Check that the baskets are correctly posi- tioned horizontally. Check that the dishes are not blocking the baskets from sliding properly into place. The touch buttons do not react when You have pressed the touch buttons too soon Wait a moment then try again.
-
Page 17: Technical Information
Technical information Information for test institute Energy labelling Australian standard: AS/NZS 2007 Number of place settings: Dishwashing programs: Normal program; Low temperature, Short dry (no options) The door should be opened upon completion of the drying cycle a distance of 35 mm at V. Program time: 1:45 hours:minutes Connection:... - Page 18 1 Teaspoons 2 Dessertspoons 3 Soupspoons 4 Forks 5 Knives Technical data Height: 817-872 mm Width: 596 mm Depth: 550 mm Weight: 49 kg Capacity: 14 Place settings Water pressure: 0.03–1.0 MPa 0.3–10 kp/cm 3–100 N/cm Electrical connection: See type plate. Rated power: See type plate.
-
Page 19: Installation
Installation 1189 [mm] 30-94 *Remove locking nuts for an installed height of 820-821 mm. Safety instructions Transport protection for the door Connections to electricity, water and drainage must be Do not forget to remove the transport protection for the door when performed by a qualified professional. - Page 20 C. Partially built-in Suggested machine installations If the dishwasher is located so that one of its sides is visible, a The dishwasher can be installed built-in, completely freestanding side panel must be fitted. Accessories can be purchased where or partially built-in. you bought the dishwasher.
- Page 21 The drainage hose may be extended by a maximum of 3 m (the Connection to water supply total length of the drainage hose must not exceed 4.5 m). Any Use only the supply hose provided with the dishwasher. Do not joins and connecting pipes must have an internal diameter of at re-use old hoses or other spare supply hoses.
- Page 22 Screwing the dishwasher into place Adjusting the plinth (only when using toe kick accessory) (Applicable only to built-in dishwashers.) After fastening the machine, check that the front feet still touch The dishwasher is supplied with one or two toe kicks depending the floor.
- Page 23 Type B Set the correct plinth depth as follows Type A...
-
Page 24: Service
Service Read chapter Troubleshooting before contacting the service department. Note down the details on the rating plate positioned on the right inside the dishwasher. Note down the item number (1) and serial number (2). ART. NO. SERIAL NO. -
Page 25: Program Chart
Program chart... -
Page 26: Your Notes
Your notes... - Page 27 Your notes...
- Page 28 Press the main power switch and close the door. Select a program and any options (see page 7) Press and hold Start/Stop for two seconds (see page 8) en (05-14) ASKO APPLIANCES AB SOCKERBRUKSGATAN 3, SE-531 40 LIDKÖPING, SWEDEN WWW.ASKO.COM...
