Dear Customer,
Thank you for choosing this quality product from ASKO.
We hope it will meet your expectations and fulfil your needs for many years to
come. Scandinavian design combines clean lines, everyday functionality and
high quality. These are key characteristics of all our products and the reason
they are greatly appreciated throughout the world.
To get the most out of your new dishwasher, we recommend that you read the
operating instructions before using the dishwasher. The operating instructions
also include information on how you can help protect the environment.
Operating Instructions
Dishwasher
ASKO D5456FS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D5456FS and is the answer not in the manual?

Questions and answers

Related Manuals for Asko D5456FS

Summary of Contents for Asko D5456FS

  • Page 1 Dear Customer, Thank you for choosing this quality product from ASKO. We hope it will meet your expectations and fulfil your needs for many years to come. Scandinavian design combines clean lines, everyday functionality and high quality. These are key characteristics of all our products and the reason they are greatly appreciated throughout the world.

  • Page 2: Table Of Contents

    Contents Front panel Troubleshooting Safety instructions Information for test institute Before washing for the first time Technical information Loading the dishwasher Installation Using the dishwasher Service Settings Programme chart Care and cleaning Front panel To start the machine, press and hold the main power switch until the display lights up. START STOP P R O G...
  • Page 3 Safety instructions Activate the child safety lock (Kid Lock ) General (only certain models) Read the operating instructions and keep them in a safe place! A child safety lock is fitted to prevent children from opening the Never use the dishwasher for any purpose other than that dishwasher door.
  • Page 4 Before washing for the first time Do as follows the first time: Programme key 1 Unscrew the lid as illustrated. Some dishwashers include programme keys in different 2 Place the funnel supplied with the dishwasher in the salt languages. Attach the programme key in the desired language compartment top-up hole.
  • Page 5 Loading the dishwasher Economic dishwashing NOTE! Run programmes only with a full load After topping up, it may take a while before the symbol goes out. Wait to run a programme until the dishwasher is full, this way you save energy. Use the Rinse & Hold programme to rinse the dishes if there are any unpleasant odours while you wait for the Setting the rinse aid dosage dishwasher to become fully loaded.
  • Page 6 The dishwasher's baskets The dishwasher is equipped with a top cutlery tray, an upper basket and a lower basket with cutlery basket. The appearance of the baskets may differ depending on the dishwasher setup. Top cutlery tray The top cutlery tray has space for cutlery, ladles, whisks, serving cutlery and similar items.
  • Page 7 NOTE! Check that the spray arms can rotate freely. Washing large plates Move foldable tines and their mounts to widen the distance between the tine rows to adapt the lower basket to plates with a diameter greater than 25 cm. Cutlery basket Place cutlery with the handles facing down, except for knives, and spread them out as much as possible.

  • Page 8: Programme Selector

    Using the dishwasher Add detergent Main power switch Press the main power switch and close the door. Programme selection Press the Programme selector one or more times until the desired programme symbol lights. Auto wash The dishwasher can measure how dirty the dishes are and adjust water consumption and temperature accordingly.

  • Page 9: High Temperature

    the next time you use the same programme. An exception is the NOTE! Delayed start option. If the machine does not start within 2 minutes of the last button press, the display returns to showing the last programme run. Set time Press the option button several times –...

  • Page 10: Start/Stop

    Settings Do as follows to open the settings menu: Button press Description Turn off the dishwasher using the main power switch. Wait about five seconds. Then press the main power switch again. Wait until the numbers appear in the right-hand display before continuing to the next step.
  • Page 11 Button press Options Settings Description Buzzer volume The dishwasher uses a buzzer to indicate when a (Off) programme is finished or when a fault has occurred. (Low) (High) Press Start/Stop to save the setting value and continue to the next setting. Operation volume This sound is used to confirm each button press.
  • Page 12 Button press Options Settings Description You can activate this setting when using 3-in-1/ All-in-one (Off) (3-in-1/all-in-one detergent) detergent. The dishwashing programmes automatically (On) adapt to provide the best possible dishwashing and drying results every time. If you deactivate this option, the dishwasher will return to ordinary function for all programmes.
  • Page 13 Care and cleaning Coarse filter NOTE! The coarse filter traps larger food particles, which cannot get The dishwasher must not be used without the filters in place! past the drainage pump. Empty the coarse filter as necessary. Dishwashing results may be affected if the coarse filter is 1 Lift the coarse filter by the handle.
  • Page 14 Door When cleaning the edge around the door, use only a slightly damp cloth (with a little cleaner if necessary). WARNING! Do not use a spray bottle or the like around the door lock. This is to ensure that water does not penetrate the door catch and come into contact with the electrical components.
  • Page 15 Troubleshooting Display Type of fault Action Overfilling Call the service department. Water outlet fault See "Water remains in the dishwasher" in the table below. Water inlet fault Check that the water tap is on. Inlet valve leakage Turn off the water tap and call the service department. Turn off the machine with the main power switch and then turn it on again to clear the error message from the display.
  • Page 16 Problem Possible causes Action Spots on stainless steel or silver. Some foodstuffs, such as mustard, Rinse off these types of foodstuffs if not mayonnaise, lemon, vinegar, salt and starting the dishwasher immediately. Why dressings, can mark stainless steel if left for not use the Rinse &...
  • Page 17 Problem Possible causes Action The dishes are not dry enough. Drying power too low. Activate the Long dry option. The dishwasher is not fully loaded. Fully load the dishwasher. Rinse aid needs topping up or dosage is set Top up with rinse add or increase the rinse too low.
  • Page 18 Information for test institute Energy labelling European test standard: EN 60436 Number of standard place settings: Dishwashing programmes: Eco wash, High temperature Connection: Cold water 15 °C Dosages during testing Detergent: In accordance with EN 60436 Rinse aid: In accordance with EN 60436 Prewash: 7.5 gram Rinse aid dosage:...
  • Page 19 Technical information Information on energy labelling Information sheet, in compliance with Commission Delegated Regulation (EU) No. 1059/2010 ASKO Model designation: D5456FS Number of standard place settings: Energy efficiency class: Annual energy consumption(AE 264 kWh per year Energy consumption of the standard cleaning cycle(E 0.93 kWh...
  • Page 20 Installation 1235 [mm] *Remove rubber feet and locking nuts for an installed height of 850-861 mm. Safety instructions Transport protection for the door Connections to electricity, water and drainage must be Do not forget to remove the transport protection for the door when performed by a qualified professional.
  • Page 21 Suggested machine installations The dishwasher is intended for freestanding installation, but can also be installed under a worktop. Check that there is an air gap of 3 mm around the dishwasher. Adjust the height and slide the dishwasher into place Freestanding 1 Make sure the area on which the dishwasher is to be installed is firm.
  • Page 22 Service Read chapter Troubleshooting before contacting the service Figure 1 department. Note down the details on the serial number plate positioned on the right inside the dishwasher. Note down the item Min. 14 mm number (1) and serial number (2). Max.
  • Page 23 Programme chart...

  • Page 24: Salt Indicator

    Select a programme and any options (See page 8.) Normal wash a powerful programme for daily use with maximum rinsing effect. It gives you outstanding results for cleaning and drying. Press Start/Stop en (10-16) ASKO APPLIANCES AB SOCKERBRUKSGATAN 3, SE-531 40 LIDKÖPING, SWEDEN WWW.ASKO.COM...
