INSTALLATION INSTRUCTIONS
CONTENTS
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE
AUTOMATIC HIGH LOOP
AUTOMATIC HIGH LOOP
The drain hose is fastened to the back of the machine at
The drain hose is fastened to the back of the machine at
the best height. To eliminate potential drain problems, leave
the best height. To eliminate potential drain problems, leave
this hose in place.
this hose in place.
DISHWASHER
2
2
3
3
3
4
4
4
5
5
6
7
8
9
9
11
11
12
12
13
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Asko Dishwasher
Summary of Contents for Asko Dishwasher
-
Page 1: Table Of Contents
DRAIN CONNECTIONS ELECTRICAL CONNECTIONS PREPARING THE DISHWASHER FOR INSTALLATION MOVING THE MACHINE INTO PLACE CONNECTING THE ELECTRIC CABLE CONNECTING THE WATER SUPPLY FASTENING THE DISHWASHER TO THE CABINET INSTALLING THE TOE KICK INSTALLATION CHECKLIST SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE... -
Page 2: Introduction
NOTE: If a dishwasher is being installed in this area for the first Cosmetic damage must be reported to the ASKO time, most of the cabinet work, plumbing, and electrical dealer within five days from the date of purchase. -
Page 3: Xxl Dishwashers
610 mm Depth 24˝ 610 mm The best place for your dishwasher is in the kitchen near the sink. This makes it easier to connect the water and drain supply lines. A built-in dishwasher must be enclosed on the top, both sides and the back. -
Page 4: Ada Dishwashers
610 mm Depth 24˝ 610 mm The best place for your dishwasher is in the kitchen near the sink. This makes it easier to connect the water and drain supply lines. A built-in dishwasher must be enclosed on the top, both sides and the back. -
Page 5: Corner Installation
CORNER INSTALLATION If the dishwasher is installed in a corner, there must be a minimum clearance of 2˝ (50 mm) from the side wall so the door can open. 2˝ clearance EASYINSTALL CONNECTIONS PEX tubing with 3/8˝ compression fitting Electrical cord 120 volts, 15 amp cord is supplied with PEX tubing has a 95-year spec life. -
Page 6: Water Supply
Choosing a hot water connection cuts program times and reduces the dishwasher’s electricity consumption. The dishwasher comes with a 6-foot PEX water supply line that has a 3/8˝ NPT female connection. 1. Water supply After determining where the water supply line will enter 2. -
Page 7: Drain Connections
♦ Failure to provide the proper drain connection height (minimum of 20˝ (508 mm) above the bottom of the C) Connection to waste disposer with air gap dishwasher base) or a 20˝ (508 mm) high loop will result in improper drainage, which will damage the machine. -
Page 8: Electrical Connections
Damage to the dishwasher could occur if it is not properly grounded. WARNING! Make sure the water supply line, drain line and branch circuit wiring do not touch any exposed terminals of dishwasher wiring. -
Page 9: Preparing The Dishwasher For Installation
Be sure to remove the toe kick and toe kick insulation (only on certain models) from the top of the dishwasher. SLIDES FOR LEGS The unit comes with white plastic slides for the legs to protect the kitchen floor from being damaged when you slide the unit into place. -
Page 10: Moving Into Place
11. If installing in a metal cabinet, the hole(s) for the drain hose and connection pipe must be fitted with edge 12. Place the spirit level on the dishwasher door to check protectors/rubber grommets. that the machine is level and adjust if necessary. The door must be fully closed! 12. -
Page 11: Connecting The Electric Cable
3. Turn off the electrical power and check for leaks under the dishwasher and sink. 4. Make sure that no kinks have developed in the drain lines. If there are no leaks and the dishwasher seems to be working properly, continue with the installation. Page 11 Customer Care Center 1-800-898-1879 www.askousa.com... -
Page 12: Fastening The Dishwasher To The Cabinet
Cover the screw heads with the plastic NOTE: plugs provided with the machine. 1" When it is not possible to attach the dishwasher to the (25 mm) When the machine is properly attached, cabinet or the underside of the counter top, you should... -
Page 13: Installation Checklist
ASKO - DISHWASHER Appliance Installation Checklist • Remove packaging and check for cosmetic damages. • Remove the information packets from inside the dishwasher. • Attach any accessories as required by the installation. Fill strips, light shielding film, supplied door sealing... - Page 14 NOTES Page 14 Customer Care Center 1-800-898-1879 www.askousa.com...
- Page 15 NOTES Page 15 Customer Care Center 1-800-898-1879 www.askousa.com...
- Page 16 Art. No 8092457 Rev. 01 Page 16 Customer Care Center 1-800-898-1879 www.askousa.com...
