Dear Customer,
Thank you for choosing this quality product from ASKO.
We hope it will meet your expectations and fulfill your needs for many years to come.
Scandinavian design combines clean lines, everyday functionality, and high quality.
These are key characteristics of all our products and the reason they are greatly
appreciated throughout the world.
To get the most out of your new dishwasher, we recommend that you read the
operating instructions before using it. The operating instructions also include
information on how you can help protect the environment.
Do you need this Use&Care Guide in Spanish? Log on to
www.askousa.com/customer-care to download.
¿Necesita esta Instrucciones de uso y cuidado en español? Entre en
www.askousa.com/customer-care y descárguesela.
Operating Instructions
Dishwasher
ASKO D5454XL S
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Asko D5454
Summary of Contents for Asko D5454
-
Page 1: Operating Instructions
Dear Customer, Thank you for choosing this quality product from ASKO. We hope it will meet your expectations and fulfill your needs for many years to come. Scandinavian design combines clean lines, everyday functionality, and high quality. These are key characteristics of all our products and the reason they are greatly appreciated throughout the world. -
Page 2: Table Of Contents
CONTENTS FRONT PANEL CARE AND MAINTENANCE IMPORTANT SAFETY INSTRUCTIONS INSTRUCTIONS BEFORE WASHING FOR THE FIRST TIME TROUBLESHOOTING LOADING THE DISHWASHER TECHNICAL INFORMATION USING THE DISHWASHER SERVICE SETTINGS PROGRAM CHART FRONT PANEL The panel is fitted with touch buttons with audible feedback (see the chapter Settings). START STOP P R O G... -
Page 3: Important Safety
IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE • Should a child swallow dishwasher detergent or rinse aid, give plenty to drink immediately, i.e., one or two glasses of milk or WARNING! water. Do not try to induce vomiting. Seek medical advice immediately: Call the National Capital Poison Center at This manual does not cover all possible conditions and situations 1-800-222-1222. -
Page 4: Loading The Dishwasher
BEFORE WASHING FOR THE FIRST TIME LOADING THE DISHWASHER WATER SUPPLY ECONOMIC DISHWASHING The machine can be connected to either a hot (max. 160 °F, 70 Run programs only with a full load °C) or cold water supply. We recommend a cold water supply. Wait until the dishwasher is fully loaded before running a program, The water pressure should be 4.2-140 psi. - Page 5 Wood Wooden items should only be washed in a dishwasher if marked dishwasher safe. Aluminum Aluminum can lose its shine if washed in a dishwasher. However, good quality aluminum pans can be washed in a dishwasher, even if some of the shine will be lost. Plastic items Avoid washing plastic items that cannot withstand high temperatures.
- Page 6 The two baskets in the middle basket can be removed, or the entire middle basket can be removed, to create more space between the upper and lower baskets if larger items are being washed. LOWER BASKET Place plates, side plates, serving dishes, and pots in the lower basket. Place pots and pans in the rear of the lower basket to best utilize dishwashing performance from the two rear spray nozzles (Double Power Zone™...
-
Page 7: Program Selector
USING THE DISHWASHER ADD DETERGENT Recommended detergent amounts based on water hardness Water hardness Detergent amounts Soft Prewash 1 teaspoon (0-3 grains per gallon) Main wash 1 to 1-1/2 tablespoons Medium Prewash 1 teaspoon (4-8 grains per gallon) Main wash 1 to 2 tablespoons Hard Prewash 1 teaspoon (9+ grains*) -
Page 8: Normal Wash
Long dry Normal wash A higher temperature in the final rinse and a longer drying phase Use to wash normally soiled dishes, and even dishes with dried improves the drying result if you activate the Long dry option. This leftovers, such as plates, serving dishes, cups, glasses, and so on. causes a slight increase in energy consumption. - Page 9 time is shown, for example, as 1:15, which means the program will IF THE DISHWASHER IS TURNED OFF USING run for another 1 hour and 15 minutes. THE MAIN POWER SWITCH OR DUE TO A POWER FAILURE NOTE! If the program was not finished, the interrupted program resumes During the first run of each program, the remaining time when power is restored.
-
Page 10: Start/Stop
SETTINGS DO AS FOLLOWS TO OPEN THE SETTINGS MENU: Turn off the dishwasher using the main power switch. Wait about five seconds. Then press the main power switch again. Wait until the numbers appear in the right-hand display before continuing to the next step. - Page 11 Button press Options Settings Description Operation volume This sound is used to confirm each button press. (Off) (Low) (High) Press Start/Stop to save the setting value and continue to the next setting. LCD contrast For adjusting the contrast of the display. (Low) (High) Press Start/Stop to save the setting value and continue to the next setting.
-
Page 12: Care And Maintenance
CARE AND MAINTENANCE INSTRUCTIONS COARSE FILTER NOTE! The coarse filter traps larger food particles, which cannot get past The dishwasher must not be used without the filter in place! the drain pump. Empty the coarse filter as necessary. Dishwashing efficiency can be affected if the coarse filter is 1 Lift the coarse filter by the handle. - Page 13 2 Remove any debris using a needle, toothpick, or some other DOOR similar pointed device. The spray arms also have holes When cleaning the edge around the door, use only a slightly damp underneath. cloth (with a little cleaner if necessary). WARNING! Do not use a spray bottle or the like around the door lock.
-
Page 14: Troubleshooting
TROUBLESHOOTING Display Type of fault Action Overfilling Call the Customer Care Center. Water outlet fault See "Water remains in the dishwasher above the filters" in the table below. Water inlet fault Check that the water supply valve is on. Inlet valve leakage Turn off the water supply valve and call the Customer Care Center. - Page 15 Problem Possible causes Action The dishwasher does not start. The Start/Stop start button has been pressed Press and hold Start/Stop until the display for too short a time. flashes three times with the remaining time. The door is not properly closed. Check.
- Page 16 Problem Possible causes Action The touch buttons do not react when pressed. You have pressed the touch buttons too soon Wait a moment then try again. after opening the door. Dirt on the touch buttons. Clean with a dry or slightly damp cloth. Child lock (button lock) activated.
-
Page 17: Technical Information
TECHNICAL INFORMATION TECHNICAL DATA Height: 32-1/4'' - 34'' (819-864 mm) Width: 24" (610 mm) Depth: 22-7/8" (581 mm) Weight: 108 lb (49 kg) Water pressure: 4.2–140 psi Electrical connection: See serial number tag and rating plate. Rated power: See serial number tag and rating plate. Weight can vary due to different specifications. -
Page 18: Service
For residential installations only ASKO Appliances Inc. will pay for: Length of warranty Two-Year Full ASKO replacement parts and/or repair labor to correct defect in mate- rials or workmanship. Service must be provided by an authorized ASKO From date of purchase. -
Page 19: Program Chart
PROGRAM CHART Customer Care Center 1-800-898-1879 www.askousa.com... -
Page 20: Display
PRESS THE MAIN POWER SWITCH AND CLOSE THE DOOR. SELECT A PROGRAM AND ANY OPTIONS (SEE PAGE 7) PRESS START/STOP (SEE PAGE 8) www.asko.com Item No.: 8093969. Rev. 02. We reserve the right to make changes.
