- Page 1 SPOT 160 User Manual...
-
Page 2: Table Of Contents
Reset..........................14 Factory Reset......................... 14 System Information ......................14 IRC-6 Infrared Remote Control ................IRC-6 Operation ......................15 Master/Slave Mode ....................5. Maintenance....................Product Maintenance ....................6. Technical Specifications................Returns ......................Contact Us......................Intimidator Spot 160 User Manual Rev. 1... -
Page 3: Before You Begin
Electronically published by Chauvet in the United States of America. CHAUVET, the Chauvet logo, and Intimidator Spot 160 are registered trademarks or trademarks of Chauvet & Sons LLC (d/b/a Chauvet and Chauvet Lighting) in the United States and other countries. Other company and product names and logos referred to herein may be trademarks of their respective companies. -
Page 4: Safety Notes
Keep this User Manual for future use. If the product is sold to someone else, be sure that they also receive this document. Page 2 of 20 Intimidator Spot 160 User Manual Rev. 1... -
Page 5: Introduction
(127 mm) 5 in (127 mm) 6.46 in (164 mm) 12.13 in (308 mm) 9.33 in (237 mm) 3.58 in (91 mm) 7.6 in 5.87 in (193 mm) (149 mm) Intimidator Spot 160 User Manual Rev. 1 Page 3 of 20... -
Page 6: Setup
3. Setup AC Power The Intimidator Spot 160 has an auto-ranging power supply, and it can work with an input voltage range of 100 to 240 VAC, 50/60 Hz. To determine the product’s power requirements (circuit breaker, power outlet, and wiring), use the current value listed on the label affixed to the product’s back panel, or refer to the product’s specifications chart. -
Page 7: Mounting
Before mounting the product, read and follow the safety recommendations indicated in the Safety Notes. Orientation The Intimidator Spot 160 may be mounted in any position; however, make sure adequate ventilation is provided around the product. Rigging • Before deciding on a location, always make sure there is easy access to the product for maintenance and programming. -
Page 8: Operation
DOWN floor mounting Sensitivity 001–100 Sets the sound sensitivity Indicator Enables/disables LED indicator Flash if DMX Enables/disables Flash if DMX Reset Resets the product Factory Set Loads factory defaults Page 6 of 20 Intimidator Spot 160 User Manual Rev. 1... -
Page 9: Configuration (Dmx)
Temperature: _ _ °C Displays the product temperature in °C Configuration (DMX) The Intimidator Spot 160 works with a DMX controller. Information about DMX is in the CHAUVET DMX Primer, which is available from the Chauvet website: http://www.chauvetlighting.com/downloads/DMX_Primer_rev05_WO.pdf. Starting Address When selecting a starting DMX address, always consider the number of DMX channels the selected DMX mode uses. -
Page 10: Dmx Channel Assignments And Values
063 064 White 065 189 Color indexing 190 221 Color cycling rainbow (fast to slow) 222 223 Stop 224 255 Reverse color cycling rainbow (slow to fast) Page 8 of 20 Intimidator Spot 160 User Manual Rev. 1... - Page 11 004 007 Open 008 076 Strobe (slow to fast) Shutter 077 145 Pulse strobe (slow to fast) 146 215 Random strobe (slow to fast) 216 255 On Intimidator Spot 160 User Manual Rev. 1 Page 9 of 20...
- Page 12 184 199 Sound-active movement macro 4 200 215 Sound-active movement macro 5 216 231 Sound-active movement macro 6 232 247 Sound-active movement macro 7 248 255 Sound-active movement macro 8 Page 10 of 20 Intimidator Spot 160 User Manual Rev. 1...
-
Page 13: 05Ch
004 007 Open 008 076 Strobe (slow to fast) Shutter 077 145 Pulse strobe (slow to fast) 146 215 Random strobe (slow to fast) 216 255 On Intimidator Spot 160 User Manual Rev. 1 Page 11 of 20... -
Page 14: Configuration (Standalone)
4. Use <UP> or <DOWN> to select Sound. 5. Press <ENTER>. Sound Sensitivity To set the sound sensitivity on the Intimidator Spot 160, follow the instructions below: 1. Press <MENU>. 2. Use <UP> or <DOWN> to select Setup. 3. Press <ENTER>. -
Page 15: Configuration (Settings)
6. Use <UP> or <DOWN> to select from 540 (540°), 360 (360°), or 180 (180°). 7. Press <ENTER>. Tilt Angle To set the tilt angle range on the Intimidator Spot 160, follow the instructions below: 1. Press <MENU>. 2. Use <UP> or <DOWN> to select Setup. -
Page 16: Totem Mode
4. Use <UP> or <DOWN> to select Reset. 5. Press <ENTER>. Factory Reset To restore the Intimidator Spot 160 to factory default settings, follow the instructions below: 1. Press <MENU>. 2. Use <UP> or <DOWN> to select Setup. 3. Press <ENTER>. -
Page 17: Irc-6 Infrared Remote Control
Operation IRC-6 Infrared Remote Control The Intimidator Spot 160 is compatible with the IRC-6 infrared remote control from Chauvet. To set the Intimidator Spot 160 to IR mode, follow the instructions below: 1. Press <MENU>. 2. Use <UP> or <DOWN> to select Run Mode. -
Page 18: Master/Slave Mode
The Master/Slave mode allows a single Intimidator Spot 160 product (the “master”) to control the actions of one or more Intimidator Spot 160 products (the “slaves”) without the need of a DMX controller. The master product will be set to operate in either standalone mode or with the IRC-6, whereas the slave products will be set to operate in slave mode. -
Page 19: Maintenance
7. Gently polish the transparent surfaces until they are free of haze and lint. Always dry the transparent surfaces carefully after cleaning them. Do not spin the cooling fans using compressed air because they could be damaged. Intimidator Spot 160 User Manual Rev. 1 Page 17 of 20... -
Page 20: Technical Specifications
Maximum External Temperature Cooling System 104 °F (40 °C) I/O Connector Channel Range 3-pin XLR 5 or 11 Ordering Product Name Item Code UPC Number Intimidator Spot 160 01081587 781462219352 Page 18 of 20 Intimidator Spot 160 User Manual Rev. 1... -
Page 21: Returns
Be sure to pack the product properly. Any shipping damage resulting from inadequate packaging will be your responsibility. FedEx packing or double-boxing are recommended. Chauvet reserves the right to use its own discretion to repair or replace returned product(s). Intimidator Spot 160 User Manual Rev. 1 Page 19 of 20... -
Page 22: Contact Us
Visit the applicable website above to verify our contact information and instructions to request support. Outside the US, the UK, Ireland, Mexico, France, Germany, or Benelux, contact the dealer of record. Page 20 of 20 Intimidator Spot 160 User Manual Rev. 1...
