Table of Contents
Advertisement
Quick Links
The links below will work in most PDF viewers and link to the topic area by clicking the link.
We recommend Adobe Reader version 10 or greater available at:
http://get.adobe.com/reader
C87214 | C87030 FAQS ................................................................................................... 1
AC Power ............................................................................................................................... 2
Batteries ................................................................................................................................ 2
Weather Station Factory Restart .................................................................................. 2
Outdoor Temperature Sensor ......................................................................................... 3
Compatible Outdoor sensors ............................................................................................. 3
Quick Connect ..................................................................................................................... 3
Outdoor Temperature Signal Strength ............................................................................ 3
Dashes show for Outdoor Temperature .......................................................................... 3
Power Requirements .......................................................................................................... 3
Inaccurate Outdoor Temperature Reading ..................................................................... 4
Intermittent Outdoor Temperature .................................................................................. 4
Outdoor Temperature is stuck or HH.H, LL.L ................................................................. 4
Outdoor sensor drains batteries quickly ......................................................................... 5
Outdoor Humidity goes to dashes when temperature is cold. .................................... 5
Outdoor sensor fell. The sensor no longer works .......................................................... 5
Temperature Trend Arrows ............................................................................................... 5
Humidity Trend Arrows ...................................................................................................... 6
HI/LO Temperature readings ............................................................................................ 6
Heat Index/Dew Point ........................................................................................................ 6
Channels ............................................................................................................................... 7
Multiple Outdoor Transmitters .......................................................................................... 7
Mounting/Positioning Outdoor sensor ............................................................................. 7
Position Weather station .................................................................................................... 8
Distance/Resistance/Interference .................................................................................... 8
Temperature Alerts ........................................................................................................ 9
Weather Station .................................................................................................................. 9
Power Requirements .......................................................................................................... 9
12-Hour or 24-Hour time format ..................................................................................... 9
Fahrenheit/Celsius .............................................................................................................10
Backlight ..............................................................................................................................10
Dashes, HH.H, LL.L or stuck Indoor Temperature/Humidity ......................................10
Inaccurate Indoor Temperature Reading .......................................................................10
Set Time Alarm...................................................................................................................11
Activate/Deactivate time alarm .......................................................................................11
La Crosse Technology, Ltd.
C8 72 1 4 | C 8 70 30 F AQ S
CO N T E NT S
www.lacrossetechnology.com/support
Page 1
Advertisement
Table of Contents
Related Manuals for La Crosse Technology C87214
Summary of Contents for La Crosse Technology C87214
-
Page 1: Table Of Contents
The links below will work in most PDF viewers and link to the topic area by clicking the link. We recommend Adobe Reader version 10 or greater available at: http://get.adobe.com/reader CO N T E NT S C87214 | C87030 FAQS ....................1 AC Power ..........................2 Batteries ..........................2 Weather Station Factory Restart .................. 2 Outdoor Temperature Sensor .................. -
Page 2: Ac Power
15 minutes to establish a strong connection. 10. Do not press buttons for 15 minutes. For optimum 433MHz transmission, place the outdoor sensor no more than 200 feet (60 meters, open air) from the weather station. La Crosse Technology, Ltd. www.lacrossetechnology.com/support Page 2... -
Page 3: Outdoor Temperature Sensor
Turn the weather station 90 degrees towards the outdoor sensor to provide better reception. This allows more antenna surface to face the outdoor sensor signal. Try the quick connect factory restart. Power Requirements La Crosse Technology, Ltd. www.lacrossetechnology.com/support Page 3... -
Page 4: Inaccurate Outdoor Temperature Reading
Outdoor Temperature is stuck or HH.H, LL.L Explanation: These symbols are error messages indicating the outdoor sensor is outside of its readable range. Check Batteries. Overpowered or underpowered batteries can cause this reading. Replace outdoor sensor. La Crosse Technology, Ltd. www.lacrossetechnology.com/support Page 4... -
Page 5: Outdoor Sensor Drains Batteries Quickly
Note: Be sure to order the correct model and frequency to avoid receiving the incorrect item. Call La Crosse Technology® Store at 608-785-7939 or e-mail from the store website if you are unsure about the correct item to order. Each item carries the original new product warranty and includes access to La Crosse Technology®... -
Page 6: Humidity Trend Arrows
View Dew Point Temperature: From the default time display, press the HEAT/DEW button twice and Dew Point will show instead of the outdoor ambient temperature. The words “Dew Point” will show near outdoor temperatures. Note: Dew Point is lower than the actual temperature. La Crosse Technology, Ltd. www.lacrossetechnology.com/support Page 6... -
Page 7: Channels
Avoid more than one wall between the outdoor sensor and the weather station. The HIimum transmitting range in open air is over 300 feet (91 meters). Obstacles such as walls, windows, stucco, concrete and large metal objects can reduce the range. La Crosse Technology, Ltd. www.lacrossetechnology.com/support Page 7... -
Page 8: Position Weather Station
Sometimes a simple relocation of the outdoor sensor or the weather station will correct the interference. Windows can reflect the radio signal. Metal will absorb the RF (radio frequency) signal. La Crosse Technology, Ltd. www.lacrossetechnology.com/support Page 8... -
Page 9: Temperature Alerts
This weather station is powered by a 5 volt AC power adapter Alternatively, optional 3-AAA alkaline batteries may be used. 12-Hour or 24-Hour time format Time can display in 12-hour (am, pm) or 24-hour format. La Crosse Technology, Ltd. www.lacrossetechnology.com/support Page 9... -
Page 10: Fahrenheit/Celsius
Side-by-side test: Bring the outdoor sensor in the house and place it next to the weather station for 2 hours. Compare indoor and outdoor temperature. The temperature should be within 4 degrees to be within tolerance. La Crosse Technology, Ltd. www.lacrossetechnology.com/support Page 10... -
Page 11: Set Time Alarm
DST. Confirm with the TIME SET button and move to 12/24 hour time. 7. 12H will show. Press and release the ▲ and ▼ buttons to select 24H. Confirm with the La Crosse Technology, Ltd. www.lacrossetechnology.com/support Page 11... - Page 12 Clock must operate on AC power for backlight to stay on. Weather station is blank: No letters, numbers or dashed lines Check that the AC adapter. Is it correctly installed and connects to an active outlet. La Crosse Technology, Ltd. www.lacrossetechnology.com/support Page 12...
- Page 13 Remove batteries from alarm clock. Press any button 20 times. Leave the alarm clock unpowered for 1-2 hours. Power clock with AC adapter only to determine if batteries were an issue. La Crosse Technology, Ltd. www.lacrossetechnology.com/support Page 13...
