Your Work Never Looked Better
USER MANUAL
TABLE OF CONTENTS
FOR YOUR SAFETY -------------------------------------------------- 1
SAFETY PRECAUTIONS -------------------------------------- 2
BEFORE YOU OPERATE THE MONITOR ---------------------- 3
FEATURES -------------------------------------------------------- 3
PACKING LIST --------------------------------------------------- 3
INSTALLATION INSTRUCTIONS --------------------------- 3
CONTROLS AND CONNECTORS -------------------------- 4
OPERATING INSTRUCTIONS ------------------------------------- 5
GENERAL INSTRUCTIONS ---------------------------------- 5
HOW TO ADJUST A SETTING ------------------------------ 6
ADJUSTING THE PICTURE ---------------------------------- 7
POWER MANAGEMENT FEATURE ----------------------- 7
PLUG AND PLAY ------------------------------------------------ 9
TECHNICAL SUPPORT(FAQ) -------------------------------------10
APPENDIX ---------------------------------------------------------------11
SPECIFICATIONS ------------------------------------------
FACTORY PRESET TIMING TABLE -----------------------13
CONNECTOR PIN ASSIGNMENT ------------------------- 13
LIMITED THREE-YEAR WARRANTY -----------------------14-15
Thank you very much for choosing the AOC Color Monitor.
We recommend that you take a few minutes to read carefully through this
brief but comprehensive manual before installing and switching on the
monitor. Please keep this manual in a safe place for you future reference.
Plug & Play Drivers for the AOC Spectrum Series Monitors are available
at AOC's Web Site: www.aoc-europe.com
7Elr/7ElrA
7Elr+/7ElrA+
ENGLISH
DEUTSCH
FRANÇAIS
ESPAÑOL
ITALIANO
11-12
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for AOC Spectrum 7Elr+
Summary of Contents for AOC Spectrum 7Elr+
-
Page 1: Table Of Contents
Please keep this manual in a safe place for you future reference. Plug & Play Drivers for the AOC Spectrum Series Monitors are available at AOC’s Web Site: www.aoc-europe.com... -
Page 2: For Your Safety
It is the responsibilities of the user to correct such interference. As an NERGY Partner AOC International has determined that this product meets the NERGY guidelines for energy efficiency. WARNING : To prevent fire or shock hazard, do not expose the monitor to rain or moisture. -
Page 3: Safety Precautions
PRECAUTIONS ! Do not use the monitor near water, e.g. near a bathtub, washbowl, kitchen sink, laundry tub, swimming pool or in a wet basement. ! Do not place the monitor on an unstable cart, stand, or table. If the monitor falls, it can injure a person and cause serious damage to the appliance. -
Page 4: Before You Operate The Monitor
BEFORE YOU OPERATE THE MONITOR FEATURES • 43.2cm(17”) Color Monitor • Crisp, Clear Display for Windows • Supports Resolutions up to 1280 1024 • Power Management • Ergonomic Design (MPR II Approved for 7Elr+/7ElrA+) • Space Saving, Compact Case Design CHECKING THE CONTENTS OF THE MONITOR PACKAGE The product package should include the following items: Monitor... -
Page 5: Controls And Connectors
POWER CORD Power Source: 1. Make sure the power cord is the correct type that required in your area. 2. This monitor has a universal power supply that allows operation in either 100/120V AC or 220/240V AC voltage area ( No user adjustment is required. -
Page 6: Operating Instructions
OPERATING INSTRUCTIONS GENERAL INSTRUCTIONS The power switch is located at front panel of the monitor. Press the power switch to turn the monitor on or off. The other control knobs are located at the base of the monitor (See Figure 3). By changing these settings, the picture can be adjusted to your personal preferences. -
Page 7: How To Adjust A Setting
NOTES • Do not install the monitor in a location near heat sources such as radiators or air ducts , or in a place subject to direct sunlight , or excessive dust or mechanical vibration or shock. • Save the original shipping carton and packing materials, as they will come in handy if you ever have to ship your monitor. -
Page 8: Adjusting The Picture
ADJUSTING THE PICTURE The description for function control LEDS CONTRAST Adjust the picture contrast. BRIGHTNESS Adjust the picture brightness. H-SIZE Adjust the picture’s horizontal size. H-CENTER Adjust the horizontal position of the picture. V-SIZE Adjust the picture’s vertical size. V-CENTER Adjust the vertical position of the picture. - Page 9 • • • • Suspend Mode When the V-sync signal from the computer is off, the monitor enters into Suspend Mode which reduces the power consumption to less than 15W. The screen becomes dark, and the power indicator turns to orange. From Suspend Mode, the screen reappears instantaneously when the keyboard or the mouse is touched again.
-
Page 10: Plug And Play
PLUG AND PLAY Plug & Play DDC1/2B Feature This monitor is equipped with VESA DDC1/2B capabilities according to the VESA DDC STANDARD. It allows the monitor to inform the host system of its identity and, depending on the level of DDC used, communicate additional information about its display capabilities. -
Page 11: Technical Support(Faq)
*Check if the Video Card is Plug & Play compatible *Check if the D-15 plug pin of Video Cable is bent *Make sure the AOC Monitor Drivers are installed (AOC Monitor Drivers are available at: www.aoc-europe.com) No picture *Computer Power Switch should be in the... -
Page 12: Appendix
APPENDIX SPECIFICATIONS CRT Size 43.2cm(17"), 90 deflection, 27mm neck, Viewable Image 40.6cm (16"), diagonal Size Type 0.28mm dot pitch. Video 0.7Vpp, R,G,B Analog Input Separate Sync. TTL Level H./V.- Sync. Positive / Negative Scanning H-Frequency 30kHz - 69kHz Frequency V-Frequency 50Hz-160Hz Max. - Page 13 • Switch Power On/Off switch • Up/Down Key • Function Key • External Controls: Functions Contrast • Brightness • H-Size • H-Center • V-Size • V-Center • Pincushion • Trapezoid • Rotation (for 7ElrA/7ElrA+ only) Plug & Play DDC1/2B Power Management EPA, VESA DPMS Power Consumption ( Maximum )
-
Page 14: Factory Preset Timing Table
FACTORY PRESET TIMING TABLE HORIZONTAL VERTICAL STANDARD RESOLUTION FREQUENCY FREQUENCY 720 x 400 31.5kHz 70Hz 640 x 480 31.5kHz 60Hz VESA/85 640 x 480 43.2kHz 85Hz VESA/85 800 x 600 53.6kHz 85Hz VESA/85 1024 x 768 68.7kHz 85Hz VESA/60 1024 x 1024 64.0kHz 60Hz CONNECTOR PIN ASSIGNMENT... -
Page 15: Limited Three-Year Warranty
If the product appears to be defective, please contact your local dealer or refer to the warranty card when attached to the product. Deliver the product freight pre-paid, along with the dated proof of purchase, to the AOC Authorized Service Center. If you cannot deliver the product in person: •... - Page 16 OTHER THEORY, SHALL NOT EXCEED THE PRICE OF THE INDIVIDUAL UNIT WHOSE DEFECT OR DAMAGE IS THE BASIS OF THE CLAIM. IN NO EVENT SHALL AOC INTERNATIONAL (EUROPE) GMBH BE LIABLE FOR ANY LOSS OF PROFITS, LOSS OF USE OR FACILITIES OR EQUIPMENT, OR OTHER INDIRECT, INCIDENTAL, OR CONSEQUENTIAL DAMAGE.
