Brother DCP-B7548W Quick Setup Manual

CHN-ENG
Version 0
EN
Unpack the machine and check the components
Remove the protective tape or film covering the machine and the supplies.
USB Interface Cable
1
Remove the packing materials and install the toner cartridge and drum unit assembly
2
Load paper in the paper tray
3
Connect the power cord and turn the machine on
Back
Quick Setup Guide
DCP-B7548W / DCP-B7558W / DCP-B7578DW / DCP-B7608W /
DCP-B7628DW / DCP-B7638DN / DCP-B7648DW / DCP-B7658DW
Read the Product Safety Guide first, then read this Quick Setup Guide for the correct installation procedure.
Operation Videos:
www.95105369.com
Drum Unit
Quick Setup Guide Product Safety Guide
Front
Installation & Using Videos
NOTE:
• The available connection interfaces vary depending on the model.
If you use a wired connection, you must purchase the correct cable for the
interface you want to use.
Toner Cartridge
• The screens and images in this Quick Setup Guide show the DCP-B7658DW.
• Save all packing materials and the box in case you must ship your machine.
1
2
Remove the orange part.
Do not exceed this mark.
Adjust the paper
guides.
• USB cable
We recommend using a USB 2.0 cable (Type A/B) that is no more than
2 metres long.
• Network cable (for DCP-B7558W/DCP-B7578DW/DCP-B7608W/
DCP-B7628DW/DCP-B7638DN/DCP-B7648DW/DCP-B7658DW)
Use a straight-through Category 5 (or greater) twisted-pair cable.
1
Push firmly.
1
