HWFL1014V/HWFL1014VS/HWFL1014VT
This washing machine is equipped with automatic safety
functions which detect and diagnose at an early stage and
react appropriately.
F. "Options" button
G. "Favourite" button
H. "Spin" button
I. "Rinse" button
J. "Temp" button
Program
Care Label
-Washing temperature selected as per the Care Label instruction.
Cotton(1)
Heavily and moderately soiled cotton, or linen.
--,20ºC, 30ºC, 40ºC,
For very heavily soiled items select the "Prewash" function.
60ºC, 95ºC
Synthetics
Moderately soiled synthetics, cotton blended fabrics.
--,20ºC,30ºC, 40ºC,60ºC
Wool
Machine washable wool. (Refer to the washing label attached to the clothing).
--,20ºC,30ºC,40ºC
Quick 15'
Cotton, mixed fabrics. Items worn for a short time or newly bought.
30
--,20ºC,30ºC,40ºC
Mix
Mixed loads of moderately soiled cotton and synthetic fabrics.
--,20ºC,30ºC,40ºC
Jeans
The program is suitable for jeans.
--,20ºC,30ºC,40ºC,60ºC
30
Rinse +Spin
This program is defaulted to two rinses and spin.
Spin
Select the length, and speed, of the spin manually.
Skin Care
Extra rinse time. Making sure no residual detergent on textiles to protect skin form irritability.
--,20ºC, 30ºC, 40ºC,
Baby Care
Program to effectively extinguish bacteria in textiles. It is appropriate for clothes of babies who are
--,20ºC, 30ºC, 40ºC,
sensitive to clothes.
Shirts
Non-iron shirts or blouses made of cotton, linen, synthetic fibres or blended fabrics.
--,20ºC, 30ºC, 40ºC,60ºC
Dark Wash
Dark textiles made of cotton and dark easy-care textiles.
--,20ºC, 30ºC, 40ºC,60ºC
Sportswear
Sportswear and leisure wear made from microfibre fabrics.
30
--,20ºC, 30ºC, 40ºC
Duvet
Machine-washable items stuffed with synthetic fibres, such as pillows,
--,20ºC, 30ºC, 40ºC
quilts and bedspreads; also suitable for items stuffed with down.
Silk/Delicate
Soft delicate fabrics and machine washable silk. (Refer to the washing label attached to the clothing).
--,20ºC,30ºC,40ºC
Program to remove dirt and bacterial residue that can breed in the machine after it has been used for
Drum Clean
a period, especially when low temperature washes are used regularly.
95ºC
: Optional Functions
Yes : Detergent Required
(1) Wash performance test programs are: cotton 40˚C, 2 rinse times, maximum speed;（2）The detergent shall be dissolved in 1L of PBIS solution at a minimum temperature of 35 ℃ immediately before it is required.
Quick User Manual
C
Material / Level of Soiling
: Cannot be selected -- : Temperature of unheated water
J
I
H
G
F
E
D
Detergent Compartment
Maximum
Wash Load
Prewash
Main wash
Softener
Delay end
Prewash
kg
10.0
Yes
4.0
Yes
2.0
Yes
1.0
Yes
4.0
Yes
4.0
Yes
10.0
10.0
4.0
Yes
4.0
Yes
4.0
Yes
4.0
Yes
2.0
Yes
2.0
Yes
2.0
Yes
Yes
A
A. "On/Off" button
B
B. "Start/Pause" button
C. Program selector
D. Program and function status display window
E. "Delay End" button
Wash Program Functions
Default
ECO
Intensive
Ironing Spin
Temp.
spin speed
rinse
times
2
2
3
3
3
3
1
Maximum
spin speed
rpm
1400
1200
600
1000
1400
1000
1400
1400
1000
1400
1000
1000
1000
600
600
600
