HWFPV8012EMT
This washing machine is equipped with automatic safety
functions which detect and diagnose at an early stage and
react appropriately.
A. "Start/Pause" button
B. "Options" button
C. "Delay End" button
D. "Spin" button
E. "Temp." button
Program
Care Label
-Washing temperature selected as per the Care Label instruction.
Cotton
Heavily and moderately soiled cotton, or linen.
--,20ºC, 30ºC, 40ºC,
For very heavily soiled items select the "Prewash" function.
60ºC, 95ºC
Cotton Eco (1)
Eco wash for cotton and linen.
--,20ºC, 30ºC, 40ºC,
Can reduce washing time and power consumption.
60ºC，95ºC
Skin Care
Extra rinse time. Making sure no residual detergent on textiles to protect skin form irritability.
--,20ºC, 30ºC, 40ºC
Synthetics
--,20ºC, 30ºC, 40ºC,
Moderately soiled synthetics, cotton blended fabrics.
60ºC
Wool
Machine washable wool. (Refer to the washing label attached to the clothing).
--,20ºC, 30ºC, 40ºC
Shirts
Non-iron shirts or blouses made of cotton, linen, synthetic fibres or blended fabrics.
--,20ºC, 30ºC, 40ºC,
60ºC
Dark Wash
--,20ºC, 30ºC, 40ºC,
Dark textiles made of cotton and dark easy-care textiles
60ºC
Quick 15'
Cotton, mixed fabrics. Items worn for a short time or newly bought.
30
--,20ºC, 30ºC, 40ºC
Mix
Mixed loads of moderately soiled cotton and synthetic fabrics.
--,20ºC, 30ºC, 40ºC
Sportswear
Sportswear and leisure wear made from microfibre fabrics.
--,20ºC, 30ºC, 40ºC
Duvet
Machine-washable items stuffed with synthetic fibres, such as pillows,
--,20ºC, 30ºC, 40ºC
quilts and bedspreads; also suitable for items stuffed with down.
Silk/Delicate
Soft delicate fabrics and machine washable silk. (Refer to the washing label attached to the clothing).
--,20ºC, 30ºC, 40ºC
Program to remove dirt and bacterial residue that can breed in the machine after it has been used for
Drum Clean
a period, especially when low temperature washes are used regularly.
95ºC
Rinse +Spin
This program is defaulted to two rinses and spin.
Spin
Select the length, and speed, of the spin manually.
Quick User Manual
G
Material / Level of Soiling
F
E
H D
I
C
B
A
Detergen Compartmentt
Maximum
Softener
Delay End
Wash Load
Prewash
Main wash
kg
Yes
8.0
8.0
Yes
4.0
Yes
4.0
Yes
2.0
Yes
4.0
Yes
4.0
Yes
1.0
Yes
Yes
4.0
4.0
Yes
4.0
Yes
Yes
2.0
Yes
8.0
8.0
F.
Program and function status display window
G.
Program selector
H.
Child Lock Function
I.
Mute Function
Wash Program Functions
Default
Spin
Temp.
Extra
Prewash
rinse
rinse
times
2
2
4
2
2
2
2
1
2
2
2
3
1
2
0
Maximum
spin speed
rpm
1200
1200
1200
1200
600
800
1000
800
1200
1000
600
600
600
1200
1200
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Hisense HWFPV8012EMT
Summary of Contents for Hisense HWFPV8012EMT
- Page 1 Quick User Manual HWFPV8012EMT This washing machine is equipped with automatic safety functions which detect and diagnose at an early stage and react appropriately. Program and function status display window Program selector A. “Start/Pause” button Child Lock Function B. “Options” button Mute Function C.
- Page 2 : Optional Functions Yes : Detergent Required : Cannot be selected -- : Temperature of unheated water (1) Wash performance test programs are: cotton eco 40˚C, maximum speed.
- Page 3 PARAMETER Door Lock Icon Child Lock Reload in Process HWFV8012/HWFV8012S/ After the program starts the Door Lock icon will light up Model HWFV8012T/HWFM8012/ To strengthen the safety of children, this machine is equipped If you want to reload clothes in the process of washing, please press “Start/Pause”...
- Page 4 X08080604A...
- Page 6 Instruction for use, installation guide, warranty card (depends on model) Wrench(depends on model)
- Page 7 Important: Transport bolts which are not removed can cause damage to the appliance. Screw off all transportation bolts for approx. 30mm with wrench following the direction of arrow shown (not fully screw it off). Push two transportation bolts on horizontal direction inward and loose transportation bolt.
- Page 9 for models having Dual Inlets.
- Page 10 FILL INSTRUCTION For Models with Dual Inlets If you wish to connect hot and cold water supply (Fig.1): 1. Fix the red marked inlet hose to the hot water tap and to the inlet valve with the red filter on the rear side of machine. 2.
-
Page 11: Connect The Drain Hose
CONNECT THE DRAIN HOSE In case the drain hose is installed as shown below: Unhook it only from the right clip (see arrow) Connect the drain hose to the siphon or hook it over the edge of a sink by means of the "U"... - Page 12 X08080499A...
- Page 13 USER’S OPERATION MANUAL X08060287B Before operating this unit, please read this manual thoroughly, and retain for future reference...
-
Page 15: Safety Information
SAFETY INFORMATION The manufacturer reserves the right for any modifications For appliances with ventilation openings in the base, that a on the product which might be deemed necessary or carpet must not obstruct the openings. useful without informing about it in this IFU. Children of less than 3 years should be kept away unless Before operating your new washing machine, please read continuously supervised. - Page 16 ensure Ensure Ensure that the ventilation openings in the base of the washing machine (if available on your model) are not obstructed by a carpet or other material. Single inlet - only Dual inlet - and cold...
- Page 17 that that The symbol on the product, or on the documents accompanying the product, indicates that this appliance may not be treated as household waste. Instead it shall be handed over to the applicable collection point for there cyclingof electrical and electronic equipment.
-
Page 18: Description Of The Washing Machine
BEFORE THE FIRST WASH CYCLE Clean the outside of the washing machine with a damp cloth. Do not use abrasive detergents. To remove any residual water used during testing by the manufacturer, we Never open the door forcibly or use it as a step. recommend that you carry out a short wash cycle without laundry. - Page 19 / soak...
- Page 20 Depending on the model, Insert removal tool like slotted screwdriver into the small opening of bottom baffle, press the bottom baffle downward with much strength and open it. Or, push down on the tabs provided on both the sides and remove it. unds...
- Page 22 solv no screen are off. and Choose the desired programmme to start the machine. The washing machine will not start, and the screen flashes. Check if the water tap is closed. remove some the screen is flashing. Press the the screen is flashing.
- Page 23 Hot / Cold fill fault - For Models with Dual Inlets Fault Code List If you wish to connect hot and cold water supply (Fig.1): Displayed on Display Window Fault Description 1. Fix the red marked inlet hose to the hot water tap and to the inlet valve with the red filter on the rear side of machine.
- Page 24 C. Fault code The washer stops when the program is running. The display window shows fault code “F02/F24”, fault codes from “F04’ to “F07”, “F13”,“F14”, “F23” or “Unb”. If fault code “F02/F24” is shown Water level reaches overflow level. Remove it by pressing “Start/Pause” key and feed water. Select and start required program.
