Summary of Contents for GMI D6072S-099
- Page 1 D6072S-099 - D6072D-099 INSTRUCTION MANUAL SIL 2 Multifunction Sink-Out Temperature Converter DIN-Rail and Termination Board Models D6072S-099, D6072D-099 D6072-099 - SIL 2 Multifunction Sink-Out Temperature Converter G.M. International ISM0438-8...
-
Page 2: Technical Data
Output: voltage free SPST photoMOS: 100 mA, 60 Vdc (≤ 1 V voltage drop). Performance: Ref. Conditions 24 V supply, 250 Ω load, 23 ± 1 °C ambient temperature, slow integration mode, 4-wires (for D6072S-099) or 3-wires (for D6072D-099) configuration for RTD. -
Page 3: Ordering Information
+Output Ch1 (sink current mode) D6072D-099: +Input Ch1 for thermocouple TC or for 3 wire RTD or potentiometer D6072S-099: -Input for thermocouple TC or for 2, 3, 4 wire RTD or potentiometer -Output Ch1 (sink current mode) D6072D-099: -Input Ch1 for thermocouple TC or for 2, 3 wire RTD or potentiometer... -
Page 4: Function Diagram
Function Diagram SAFE AREA, ZONE 2 GROUP IIC T4, NON HAZARDOUS LOCATIONS, CLASS I, DIVISION 2, GROUPS A, B, C, D T-Code T4 MODEL D6072D-099 In 1 Supply 24 Vdc TC + Out 1 (SIL 2) 2-3 wires ext. comp. Pot. - Page 5 RTD for Cold Junction Compensation In 2 Termination Modbus RS485 Power and board Fault Bus connector MODEL D6072S-099 2-3-4 wires Supply 24 Vdc Pot. RTD / Resistance TC + ext. comp. Sink I TC / mV Out 1-A (SIL 2)
-
Page 6: Operation
Warning D6072-099 series are isolated apparatus installed into standard EN/IEC60715 TH 35 DIN-Rail located in Safe Area/Non Hazardous Locations or Zone 2, Group IIC T4 or Class I, Division 2, Group A, B, C, D, T4 Hazardous Area within the specified operating temperature limits Tamb -40 to +70 °C. D6072-099 series must be installed, operated and maintained only by qualified personnel, in accordance to the relevant national/international installation standards (e.g. -
Page 7: Input Specifications
-500 to 500 ≤ ±20 Notes: RTD/resistance accuracy shown in 4-wires (for D6072S-099) or 3-wires (for D6072D-099) configuration, in slow acquisition mode, after calibration. TC/mV Accuracy shown in slow acquisition mode, after calibration. G.M. International ISM0438-8 D6072-099 - SIL 2 Multifunction Sink-Out Temperature Converter... -
Page 8: Supported Modbus Functions
Addr. Description Rights Type Supported Modbus functions: 1602 Ch2: cold junction resistance value [mOhm] SINT32 Code Name Notes 1604 Ch2: sensor temperature [0.1°C] SINT32 read holding registers reads a stream of words from memory 1606 Ch2: cold junction temperature [0.1°C] SINT32 read input registers reads a stream of words from memory... - Page 9 Modbus parameters details: thermocouple C thermocouple D thermocouple E *1 Command List thermocouple J Bit pos. Value Description thermocouple K 0..3 full eeprom write thermocouple L *2 Fault Mask thermocouple LR Bit pos. Value Description thermocouple N 0..0 no internal/hardware fault thermocouple R internal/hardware fault thermocouple S...
