D1010S-054 - D1010S-056 - D1010S-057
INSTRUCTION MANUAL
mV to mA Converter
DIN-Rail Models
D1010S-054, D1010S-056, D1010S-057
D1010-054 / -056 / -057 - mV to mA Converter
ISM0098-8

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D1010S-054 and is the answer not in the manual?

Questions and answers

Related Manuals for GMI D1010S-054

Summary of Contents for GMI D1010S-054

  • Page 1 D1010S-054 - D1010S-056 - D1010S-057 INSTRUCTION MANUAL mV to mA Converter DIN-Rail Models D1010S-054, D1010S-056, D1010S-057 D1010-054 / -056 / -057 - mV to mA Converter ISM0098-8...

  • Page 2: Technical Data

    Characteristics General Description: The single channel DIN Rail mV to mA converters, D1010S-054, D1010S-056, D1010S-057, convert a mV signal from sensors located in Hazardous Area, and repeat the current in floating circuit to drive a Safe Area load. Function: 1 channel I.S. analog input, provides 3 port isolation (input/output/supply) and current (source) output signal.

  • Page 3: Ordering Information

    Ordering information Model: D1010S 1 ch. range –5 to +55 mV -054 1 ch. range –5 to +35 mV -056 1 ch. range –5 to +10 mV -057 Power Bus enclosure Front Panel and Features  Input from Zone 0 (Zone 20), installation in Zone 2. ...
  • Page 4 Parameters Table In the system safety analysis, always check the Hazardous Area devices to conform with the related system documentation, if the device is Intrinsically Safe check its suitability for the Hazardous Area and gas group encountered and that its maximum allowable voltage, current, power (Ui/Vmax, Ii/Imax, Pi/Pi) are not exceeded by the safety parameters (Uo/Voc, Io/Isc, Po/Po) of the D1010-05* series Associated Apparatus connected to it.

  • Page 5: Function Diagram

    Function Diagram HAZARDOUS AREA ZONE 0 (ZONE 20), SAFE AREA, ZONE 2, GROUP IIC T4 GROUP IIC MODELS D1010S-054, D1010S-056, D1010S-057 Supply 24 Vdc Source I In 1 Out 1 G.M. International ISM0098-8 D1010-054 / 056 / 057- mV to mA Converter...

  • Page 6: Operation

    Warning D1010-054, D1010-056, D1010-057 are isolated Intrinsically Safe Associated Apparatus installed into standard EN50022 T35 DIN Rail located in Safe Area or Zone 2, Group IIC, Temperature Classification T4 Hazardous Area (according to EN/IEC60079-15) within the specified operating temperature limits Tamb -20 to +60 °C, and connected to equipment with a maximum limit for AC power supply Um of 250 Vrms.
  • Page 7 Voltage Meter Range 10 V, Resolution 1 mV Accuracy 0.01% Yokogawa Current Calibrator range 100 mV, Resolution 1 µV Accuracy 0.01 % 7651  Connect the unit as shown below: MODELS D1010S-054, D1010S-056, D1010S-057 Supply DMM mA In 1 Out 1 ...
  • Page 8 For D1010S-054  Set calibrator (CAL) at - 5.000 mV and verify that the output current, read by multimeter (DMM), is correspondent with a maximum deviation presented in the section “Technical Data”.  Set calibrator (CAL) at 55.000 mV and verify that the output current, read by multimeter (DMM), is correspondent with a maximum deviation presented in the section “Technical Data”.
