Summary of Contents for Holemaker Technology MAX50T
- Page 1 USER MANUAL HMT MAX50T Magnetic Drilling Machine PLACE MACHINE MOTOR STICKER HERE SERIAL NO.____________ DATE OF PURCHASE __________...
- Page 2 Congratulations on your purchase of the HMT MAX50T Portable Magnetic Drilling Machine. Your model is designed to produce superior holes quickly and efficiently. Through years of experience, constant innovation and development, HMT is committed to provide you with cutting tool innovation to speed up metalworking.
- Page 3 Fig. 1 HMT_MAX50T_V1...
- Page 4 Explanation of terms used and Pictograms marked on tool HMT_MAX50T_V1...
-
Page 5: General Power Tool Safety Warnings
GENERAL POWER TOOL SAFETY WARNINGS Do not use this power tool before you have thoroughly read and completely understood this Instruction Manual and the “General Safety Instructions”, including the figures, specifications, safety regulations and the signs indicating DANGER, WARNING and CAUTION. WARNING: When using electrical tools basic safety precautions should always be followed to reduce the risk of fire, electrical shock and personal injury including following. - Page 6 alcohol, or medication. A moment of inattention while operating magnetic drilling machines may result in serious personal injury. 2. Dress properly. Do not wear loose clothing or jewelry. Contain long hair. Keep your hair, clothing, and gloves away from moving parts. Loose clothes, jewelry, or long hair can be caught in moving parts.
- Page 7 2. When servicing a tool, use only identical replacement parts. Follow instructions in the Maintenance section of this manual. Use of unauthorized parts or failure to follow Maintenance Instructions may create a risk of electric shock or injury. 3. When using this machine, you MUST wear ear and eye protection. ADDITIONAL SPECIFIC SAFETY RULES FOR MAGNETIC DRILLING MACHINES •...
-
Page 8: Residual Risks
• Do not place loose fitting gloves (especially Rigger Gloves), items of clothing, or jewellery near rotating tools or machine spindles. • Safety chains or similar restraints should be used to prevent a magnet drill falling in the event of a power cut to the electromagnetic base. Use extra caution with generator power supply for this reason •... - Page 9 POSITION Serial number The Serial Number, which also includes the type of machine, the year and month of manufacturing and identification number, is engraved on the frame, magnet and the motor unit. Example: 30 14 09 001 Model type Year of Manufacture Month of manufacture Identification number Package Contents...
- Page 10 TECHNICAL DATA HMT MAX50T Emission values for sound and vibration (Two-figure – specifications as per ISO 4871) Sound emission Measured A-weighted sound power level LwA (re 1 pW), in decibels Measuring uncertainty KwA, in decibels A-weighted emission pressure power level measured at the workplace LpA (re 20 μPa), in decibels...
-
Page 11: Description (Fig. 1)
DESCRIPTION (fig. 1) WARNING: Never modify the power tool or any part of it. Damage or personal injury could result. 1. Safety Guard 2. Feed handle 3. Cooling system tank 4. Magnetic stand 5. Magnet switch 6. Motor switch INTENDED USE This magnetic drilling machine is intended for commercial use as a drilling machine for drilling materials with a magnetizable surface using annular cutters and twist drill. - Page 12 If the supply cord is damaged, it must be replaced by a specially prepared cord available through the HMT service organization. EXTENSION CABLE If an extension cable is required, use an approved 3-core extension cable suitable for the power input of this tool (see technical data).The minimum conductor size is 1.5 mm²; the maximum length is 30 meter.
-
Page 13: Prior To Operation
INSERTING AND REMOVING AN ACCESSORY The tool holder accepts annular cutters with a 19,05 mm Weldon shank with one or more flats. WARNING: The teeth of a cutter are very sharp and can be dangerous. 1. In order to fit an annual cutter it is necessary to remove the guard (1); 2. -
Page 14: The Control Panel
“0” figure Torque The MAX50T is equipped with an all-time electronic torque protection. It will stop the motor unit when it gets overloaded. In that case just push the OFF switch to reset and ON switch to start drilling again... -
Page 15: Drilling A Hole
The ECO50T is equipped with an all-time electronic temperature protection. If the temperature of the motor unit runs up to 70 Degree celcius the motor unit will stop. After a few minutes it can be started again, and it is recommended to run the motor unloaded, with speed dial ( see 5. - Page 16 abrasion resistance. Whilst hardness and/or strength is the usual criterion, wide variations in machineability can exist among material showing similar physical properties. The drilling conditions are dependent on requirements for tool life and surface finish. These conditions are further restricted by the rigidity of the tool and the work piece, lubrication and machine power available.
- Page 17 WARNING: Never use solvents or other harsh chemicals for cleaning the non- metallic parts of the tool. These chemicals may weaken the materials used in these parts. Use a cloth dampened only with water and mild soap. Never let any liquid get inside the tool;...
-
Page 18: Maintenance
MAINTENANCE Your HMT power tool has been designed to operate over a long period of time with a minimum of maintenance. Continuous satisfactory operation depends upon proper tool care and regular cleaning. CAUTION: To reduce the risk of injury, turn unit off and disconnect machine from power source before installing and removing accessories, before adjusting or changing set- ups or when making repairs. - Page 19 ADJUSTMENT OF SLIDE An essential requirement of the machine is that the slide can move in a smooth and controlled manner, free of lateral movement and vibration. This situation can be maintained by periodic adjustment of the slide and is accomplished in the following manner: 1.
-
Page 20: Troubleshooting
TROUBLE SHOOTING Magnet and motor do not - The magnet switch is not connected to the power supply function - Damaged or defective wiring - Defective fuse - Defective magnet switch - Defective Control Unit - Defective power supply Magnet does function, the - Damaged or defective wiring motor does not work - Carbon brushes are stuck or worn out... -
Page 21: Protecting The Environment
Frame under voltage - Damaged / defective wiring - Defective magnet - Motor seriously dirty Fuse blows when magnet - Damaged or defective wiring switch is turned on - Wrong value fuse - Defective magnet switch - Defective Control Unit - Defective magnet Fuse blows when motor is - Damaged or defective wiring... - Page 22 SPARE PART LIST HMT MAX50T Article No: Description: 050.0106 Screw 5x45 050.0111 End Cover 050T.0332 Screw for control unit 2 050T.0006 Control Unit 2 (110 & 220V) 100.0373 Screw M4x12 100.0374 Washer DIN137 M4 050.0147 (230V) Carbon brush 050.0148 (110V) 050.0371...
- Page 23 050.0231 Gear shaft / Axle 100.4496 Key 5x5x28 032.0221 Bearing 608 (8x22x7) 050.0426 Circlip 471/15/1 050.0177 Spindle gear 050.0182 Adaptor ring 050.0291 Clutch shaft 040.0286 Gear Switch 032.0211 Casing pin 4 x 12 050.0221 Bearing 17/40/12 050.0208 (230V) Gear box incl. plate 050.0209 (110V) 032.0106...
- Page 24 Above – MAX50T Motor exploded drawing HMT_MAX50T_V1...
- Page 25 Article No: Description: 050T.0101/2 Motor unit 230v 050T.0102/2 Motor unit 110v 020.0156 Screw SSM6x20 020.0111 Washer M6 DIN7980 040.0041 Motor fixing plate 110mm KSP.MS Screw KSP.M/3 Coolant hanger 050.0141 Motor holder 020.0146 Screw SSM6x25 050.0011/X Slide 032.0016 Rack Aluminum rail(left) - set 020.0086/X Aluminum rail(right) - set...
- Page 26 Fuse 5x20 F2A 020.0016 Fuse holder 020.0011 Magnet Switch 020.0011/2 Magnet switch heavy duty 020.0206 LED indicator set 050T.1009 Potentiometer 100K (turn) 020.0257 Capacitance 020.0111 Washer M6 DIN7980 020.0201/2 Sensor 050.1003 Electro Magnet 50/50T EXPLODED DRAWING HMT MAX50T FRAME HMT_MAX50T_V1...
-
Page 27: Ce/Emc Declaration Of Conformity
Designation/ function Magnetic Drilling Machine Type HMT MAX50T Ratings and principal 230-240V, 50/60Hz, Class I Characteristics HMT MAX50T | 1375W Applicable EC Directives Machinery Directive 2006/42/EC Relevant standard(s) / EN 55014-1:2006/+A1:2009/+A2:2011 Specification(s) / Directive(s) EN 55014-2:1997/+A1:2001/+A2:2008 EN 61000-3-2:2006/+A2:2009/+A2:2009 EN 61000-3-3 :2008...
