In this section, we take Vigor2927Lac as an example. There are two types of antennas provided for
Vigor2927Lac, which must be installed in different locations carefully and correctly. Wrong
installation might cause bad signal of wireless connection. Therefore, pay attention to the
installation of antennas by referring to the following illustration.
SMA jack for LTE
Antenna (with
extension base)
SMA jack for
WLAN Antenna
(for ac/ax model)
The number of antennas used for RF models will vary based on your
model. For detailed information, refer to www.draytek.com.
Follow the steps below for installing the SIM card (for L model) into
the card slot:
1.
Assemble the extension base with the antenna.
2.
While installing the SIM card into the card slot, note that the
back plate of the SIM card slot must be removed first.
Assemble the SIM1 and SIM2 with the card cassette. Later
3.
insert the cassette into the SIM card slot and the direction of
card notch must be on the left side.
S
o
f
t
w
a
r
e
C
o
n
S
o
f
t
w
a
r
e
C
o
n
Make sure your PC connects to the router correctly.
Open a web browser on your PC and type
http://192.168.1.1. A pop-up window will open
to ask for username and password. Please enter
"admin/admin" as the Username/Password and
click Login.
Then, the Main Screen will pop up.
a
l
l
a
t
i
o
n
a
l
l
a
t
i
o
n
f
i
g
u
r
a
t
i
o
n
f
i
g
u
r
a
t
i
o
n
Magnetic antenna must be
installed on the extension
base before connecting to
Vigor router.
Extension
Base
