Order toll-free in the U.S. 24 hours, 7 A.M. Monday to midnight Friday: 877-877-BBOX
CUSTOMER
FREE technical support, 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746
SUPPORT
Mail order: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018
INFORMATION
Web site: www.blackbox.com • E-mail: info@blackbox.com
Express
Ethernet Switch
LB8405A-R3-US
March, 2006
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Black Box LB8405A-R3-US
Summary of Contents for Black Box LB8405A-R3-US
- Page 1 Order toll-free in the U.S. 24 hours, 7 A.M. Monday to midnight Friday: 877-877-BBOX CUSTOMER FREE technical support, 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746 SUPPORT Mail order: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018 INFORMATION Web site: www.blackbox.com • E-mail: info@blackbox.com...
- Page 2 Express Ethernet Switch LB8405A-R3-US FEDERAL COMMUNICATIONS COMMISSION AND CANADIAN DEPARTMENT OF COMMUNICATIONS RADIO FREQUENCY INTERFERENCE STATEMENT Class B Digital Device. This equipment has been tested and found to comply with the limits for a Class B computing device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 3 Express Ethernet Switch LB8405A-R3-US 8. Servicio—El usuario no debe intentar dar servicio al equipo eléctrico más allá a lo descrito en las instrucciones de operación. Todo otro servicio deberá ser referido a personal de servicio calificado. 9. El aparato eléctrico debe ser situado de tal manera que su posición no interfiera su uso. La colocación del aparato eléctrico sobre una cama, sofá, alfombra o superficie similar puede...
-
Page 4: Table Of Contents
Express Ethernet Switch LB8405A-R3-US Table of Contents Table of Contents......................4 About This Manual......................5 Packing List........................5 Introduction ........................6 Product Features ......................6 Front & Back Panel .....................7 LEDs..........................7 Installation ........................8 Selecting a Site for the Switch..................8 Connecting to Your Network ..................8 Specifications .........................9... -
Page 5: About This Manual
Express Ethernet Switch LB8405A-R3-US About This Manual This manual describes the Black Box Express Ethernet Switch in these basic sections: • FCC Statement • Introduction • Product Features • Installation Packing List Please inspect the contents and report any apparent damage or missing items immediately to Black Box. -
Page 6: Introduction
Express Ethernet Switch LB8405A-R3-US Introduction LB8405A-R3-US is a 5-port Fast Ethernet switch, integrating 10/100BaseTX networks in a cost-effective desktop package. The TX ports are auto MDIX and capable of auto negotiate speed and half/full duplex modes. Product Features • 5-port for 10/100BaseTX. -
Page 7: Front & Back Panel
Express Ethernet Switch LB8405A-R3-US Front & Back Panel LB8405A-R3-US is a space saving pocket size 5-port Ethernet switch designed for wall-mount or desktop. LED indicators and TX ports are located on front and back panels respectively. Back panel is equipped with five TX ports and a DC receptacle. The front panel displays arrays of LEDs indicating power &... -
Page 8: Installation
Express Ethernet Switch LB8405A-R3-US Installation Selecting a Site for the Switch As with any electronic device, you should place the switch where it will not be subject to extreme temperatures, humidity, or electromagnetic interference. Specifically, the site you select should meet the following requirements: •... -
Page 9: Specifications
Express Ethernet Switch LB8405A-R3-US Specifications IEEE 802.3, 10BaseT, Applicable IEEE 802.3u, 100BaseTX/FX Standards Per unit – Power Status LED Indicators Per Port – LNK/ACT 10BaseT 2-pair UTP/STP Cat. 3,4,5, up to 100m 100BaseTX 2-pair UTP/STP Cat.5, up to 100m Cable 100BaseFX 50 or 62.5/125µm Multi-mode fiber optic cable, up to 2km...
