Digital Video Recorder
Quick Guide
See "INSTRUCTION MANUAL" for menu settings
or details of the operation.
DSR-5716P
DSR-5709P
Contents
1 NAMES AND FUNCTIONS OF PARTS .......... 1
Front panel....................................................... 1
1 PREPARING FOR USE................................... 3
Operation display ............................................. 3
display area...................................................... 4
Changing the language.................................... 4
Setting the time ................................................ 5
2 MONITORING VIDEO FROM A CAMERA ..... 7
Viewing on a full screen ................................... 7
Viewing on quad screens................................. 8
Viewing on multi 9 or multi 16 screens ............ 9
Enlarging video ................................................ 9
3 RECORDING ................................................. 10
Normal recording ........................................... 10
Timer recording.............................................. 10
Alarm recording.............................................. 11
Normal recording easy setup ......................... 11
4 PLAY ............................................................. 12
Playing video on a full screen ........................ 12
Fast-forward and fast-rewind playback .......... 12
Viewing still images........................................ 13
Frame advance (forward/reverse).................. 13
5 SEARCHING FOR RECORDED VIDEO ....... 14
Alarm log search ............................................ 14
Alarm search.................................................. 15
Alarm thumbnail search ................................. 18
Time/date search ........................................... 20
Copying to a USB memory ............................ 22
Copying to a CD-R/RW or DVD+R/+RW ....... 24
Folder structure of copied video..................... 28
Advertisement
Table of Contents
Related Manuals for Sanyo DSR-5709P
Summary of Contents for Sanyo DSR-5709P
-
Page 1: Table Of Contents
Digital Video Recorder Quick Guide See “INSTRUCTION MANUAL” for menu settings or details of the operation. DSR-5716P DSR-5709P Contents 1 NAMES AND FUNCTIONS OF PARTS ... 1 Front panel... 1 1 PREPARING FOR USE... 3 Operation display ... 3 Changing the display position of the operation display area... -
Page 2: Names And Functions Of Parts
The ALARM indicator lights up during pre-alarm recording. USB terminal Connects to a recordable CD/DVD drive or a USB memory. For compatibility, refer to the SANYO homepage. http://www.sanyosecurity.com/ When the USB port on the rear panel is also connected at the same time, only the front port will be used preferentially. - Page 3 NAMES AND FUNCTIONS OF PARTS DSR-5709P POWER FULL ERROR 14. [EXIT/OSD] button and indicator EXIT: Exits the main menu or a sub-menu. When a menu is displayed, the indicator turns off. (The EXIT operation is disabled while the WARNING screen is displayed or a setting for menu item is being selected (with light flashing) on the menu screen.) OSD:...
-
Page 4: Preparing For Use
PREPARING FOR USE Operation display When the power is turned on, the operation display is shown at the top of the monitor screen. This area indicates the date, time, picture quality and other information needed for operation. Operation 01-01-07 00:00:00 REC REPEAT EN A ALARM 0000000 display area (5)(6) 01-01-07 00:00:00 REC REPEAT EN A ALARM 0000000... -
Page 5: Changing The Display Position Of The Operation Display Area
PREPARING FOR USE (8) Camera title display The camera number or camera title is displayed. Also, when an alarm occurs the camera number and alarm “EA”, “SA”, or “ES” are displayed. When an external alarm signal is activated; “EA” flashes to the left of the camera number. When a motion sensor alarm signal is activated;... -
Page 6: Setting The Time
PREPARING FOR USE Turn the shuttle dial clockwise. “ENGLISH” flashes. <LANGUAGE/LANGUE/SPRACHE/IDIOMA> Turn the jog dial to select the language and then turn the shuttle dial clockwise. The language is selected and the cursor moves to the next item. Press the [EXIT/OSD] button. The setting is completed and the display returns to the normal screen. - Page 7 PREPARING FOR USE Turn the jog dial to select “01” and then turn the shuttle dial clockwise. “01” flashes (indicating the day). <LANGUAGE/LANGUE/SPRACHE/IDIOMA> [KEY] 01-01-2007 MON 00:00:00 <SUMMER TIME SET> MODE LST-SUN OFF LST-SUN <EXT.CLOCK SET> ADJUST. TIME Turn the jog dial to select “26” and then turn the shuttle dial clockwise.
-
Page 8: Monitoring Video From A Camera
MONITORING VIDEO FROM A CAMERA [CAMERA SELECT] button Viewing on a full screen Example: Selecting Camera 2 Press the No. 2 [CAMERA SELECT] button. The CAMERA SELECT indicator lights up and video from Camera 2 is displayed on a full screen. Viewing enlarged live images Press the [ZOOM] button during monitoring of camera video. -
Page 9: Viewing On Quad Screens
MONITORING VIDEO FROM A CAMERA Press the [ZOOM] button to return to normal magnification. Magnification is cancelled and the display returns to the normal screen. The ZOOM indicator turns off. ZOOM Magnified video has a slightly coarser appearance when compared with normal video. Images cannot be enlarged in multi-screen format. -
Page 10: Viewing On Multi 9 Or Multi 16 Screens
MONITORING VIDEO FROM A CAMERA Viewing on multi 9 or multi 16 screens Press the [MULTI] button. The MULTI indicator lights up and video from 16 separate cameras is displayed simultaneously. Press the [MULTI] button again to display multi 9 screens. The DSR-5709P can only display video from nine cameras. -
Page 11: Recording
RECORDING FULL indicator Normal recording Use the following procedure to record monitored video. Be sure to set the time when using the digital video recorder for the first time. Recording is not possible until the time is set. ( P.5) Press the [REC/STOP] button. -
Page 12: Alarm Recording
RECORDING Alarm recording Use the following procedure to record alarm video when an alarm signal is detected. Set alarm recording. ( INSTRUCTION MANUAL P.98) When an alarm signal is detected When an alarm signal is detected, “ALARM” flashes in the operation display and alarm recording starts (indicated by “REC”.) Whenever an alarm occurs, the number of alarms... -
Page 13: Play
PLAY Use the following procedure to play normal or timer recording video stored in the hard disk. [CAMERA SELECT] buttons Playing video on a full screen Press the [CAMERA SELECT] button for the camera to play and then press the [PLAY/STOP] button. -
Page 14: Viewing Still Images
PLAY Viewing still images Pause playback and display still images. Press the [STILL] button during playback. The STILL indicator lights up and playback video is paused. appears in the operation display. STILL 01-01-07 00:00:00 Press the [STILL] button again to resume normal playback. -
Page 15: Searching For Recorded Video
SEARCHING FOR RECORDED VIDEO [FUNC.] button [SEARCH] button [ALARM] button Alarm log search Use the following procedure to perform an alarm search or alarm thumbnail search by defining the period (month, week, day or time) of the alarm recorded video. Press the [SEARCH] button while the digital video recorder is recording or stopped. -
Page 16: Alarm Search
SEARCHING FOR RECORDED VIDEO Turn the jog dial to select the date, time or minute and then turn the shuttle dial clockwise. The selected day (or hour or minutes) is indicated with a yellow frame. Alarm recording areas are indicated in red and areas with no recordings in gray. - Page 17 SEARCHING FOR RECORDED VIDEO (6) CHANNEL: Search by specifying a camera number. ( P.17) (7) Preview: Displays the selected alarm video. Turn the jog dial to select the video for playback from the list. A preview of the selected alarm video is displayed in the preview screen.
- Page 18 SEARCHING FOR RECORDED VIDEO Press the [FUNC.] button. The cursor moves to the list. FUNC. DATE TIME CH TOTAL ALARMS :0000028 0000028 10-05 19:15 01 0000027 10-05 18:57 02 0000026 10-05 18:55 03 0000025 10-05 18:52 03 0000024 10-05 22:05 01 0000023 10-05 21:59 05 0000022 10-05 21:33 04 0000021 10-05 21:25 06...
-
Page 19: Alarm Thumbnail Search
SEARCHING FOR RECORDED VIDEO Press the [FUNC.] button. The cursor moves to the list. FUNC. < ALARM SEARCH > DATE TIME CH TOTAL ALARMS :0000028 0000028 10-05 19:15 07 0000027 10-05 18:57 07 0000026 10-05 18:55 07 0000025 10-05 18:52 07 0000024 10-05 22:05 07 0000023 10-05 21:59 07 0000022 10-05 21:33 07... - Page 20 SEARCHING FOR RECORDED VIDEO Turn the jog dial to select the video for playback. The alarm number for the selected video flashes. 0000028 0000025 0000022 To display the next or previous recording Turn the jog dial clockwise or counter-clockwise accordingly. Press the [ALARM] button to display the next nine recordings, and...
-
Page 21: Time/Date Search
SEARCHING FOR RECORDED VIDEO Search by entering a camera number In the search screen, press the [FUNC.] button and select “CHANNEL” with the jog dial. FUNC. 0000028 0000027 SEARCH :0000028 CHANNEL :-- 0000025 0000024 0000022 0000021 Turn the shuttle dial clockwise. The “CHANNEL”... - Page 22 SEARCHING FOR RECORDED VIDEO Turn the shuttle dial clockwise while “CHANNEL” is selected. The “CHANNEL” input field flashes. RECORDING TOP : RECORDING END : CHANNEL : -- SEARCH DATE 25-10-06 12:32 PREVIEW -> VIEW CHANGE:JOG Press the [CAMERA SELECT] 5 button. The cursor moves to “DATE TIME”.
-
Page 23: Saving (Copying) Recorded Video
SAVING (COPYING) RECORDED VIDEO Copying to a USB memory Copies video saved in recording area or archive area onto a USB memory. [PLAY/STOP] button [STILL] button Shuttle dial Jog dial [MARK/COPY] button Example: Copying 20 images Insert a USB memory. The digital video recorder has one USB port each on the front and rear panels;... - Page 24 SAVING (COPYING) RECORDED VIDEO Turn the shuttle dial clockwise. “PICTURES” flashes. COPY TO : USB MEMORY UNIT AUDIO HOW MANY : 1 COPY CH COPY START FORMAT/ERASE: USB MEMORY Turn the shuttle dial clockwise while “PICTURES” is flashing. The cursor moves to “HOW MANY”. COPY TO : USB MEMORY UNIT AUDIO...
-
Page 25: Copying To A Cd-R/Rw Or Dvd+R/+Rw
-> [MARK/COPY] button Example: Copying the maximum video to the copy destination For compatibility, refer to the SANYO homepage. http://www.sanyosecurity.com/ Connect a recordable CD or DVD drive and insert a disc. The digital video recorder has one USB terminal on the front and one on the back, but they cannot be used simultaneously. - Page 26 SAVING (COPYING) RECORDED VIDEO Press the [MARK/COPY] button. The COPY indicator lights up and the copy setting screen is displayed. MARK/COPY COPY TO : ARCHIVE AREA UNIT AUDIO HOW MANY : 1 COPY CH COPY START FORMAT/ERASE: USB MEMORY FORMAT/ERASE START Turn the jog dial to select “COPY TO”...
- Page 27 SAVING (COPYING) RECORDED VIDEO Specify the channel to copy You can copy multiple channel videos at the same time. Use the [CAMERA SELECT] button on the front panel to specify a channel(s) whose video you want to copy.The specified channel(s) turns white from grey. The channel(s) which was playing the video when the [MARK/COPY] button was pressed turns green, and it is fixed as a copy channel(s).
- Page 28 SAVING (COPYING) RECORDED VIDEO You can carry out up to 99 write sessions to a CD-R/ DVD+R, or up to 99 write sessions within the same date to a CD-RW/DVD+RW. Copying data requires at least 20MB of free space on a disc.
-
Page 29: Folder Structure Of Copied Video
IMG00200 Month SOUND INFO 1. The first layer consists of a single folder named “SANYO”, under which a number of session-specific folders are created as the second layer. 2. The second layer consists of a number of session-specific folders that are named in this format: DDMMYY (the recording date for the first image copied in the copy session) followed by a two-digit serial number. - Page 30 1AC6P1P3156-- L8HBP/XE, L8HBQ/XE (0207KP-SY) SANYO Electric Co., Ltd. Printed in Japan...
