350
INFRARED THERMOMETER
CAUTION
LASER RADIATION -
DO NOT STARE INTO BEAM
OUTPUT < 1mW AT 630
670mm
CLASS II LASER PRODUCT
OPEN
CENTER Technology Corporation

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 350 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Center 350

Summary of Contents for Center 350

  • Page 1 INFRARED THERMOMETER CAUTION LASER RADIATION - DO NOT STARE INTO BEAM OUTPUT < 1mW AT 630 670mm CLASS II LASER PRODUCT OPEN CENTER Technology Corporation...
  • Page 2 350-00 DEC. 2002...

  • Page 3: Table Of Contents

    CONTENT Page I. SAFETY INFORMATION --------------------- 2 II. CAUTIONS --------------------------------------- 2 III. GENERAL SPECIFICATION ---------------- 3 IV. NAME AND FUNCTION ---------------------- 4 V. OPERATION INSTRUCTIONS: Measuring Trigger ---------------------------- 5 Distance to Spot Ratio (D/S) -------------- 5 Emissivity -------------------------------------- 5 Maintenance ------------------------------------ 6 Replace Battery -------------------------------- 6...

  • Page 4: Safety Information

    Infrared Recorder SAFETY INFORMATION • Read the following safety information carefully before attempting to operate or service the meter. • Only qualified personnel should perform repairs or servicing not covered in this manual. • Periodically wipe the case with a dry cloth. Do not use abrasives or solvents on this instrument.

  • Page 5: General Specification

    Infrared Recorder • Away from electrical welders, induction heaters and EMF sources. • When using this thermometer under large or abrupt ambient temperature changes, allow 15 minutes for unit to stabilize before use. • Do not keep this thermometer in the environment of high temperature for a long time.

  • Page 6: Name And Function

    Infrared Recorder IV. NAME AND FUNCTION SCAN CAUTION LASER RADIATION - DO NOT STARE INTO BEAM OUTPUT < 1mW AT 630 670mm CLASS II LASER PRODUCT OPEN LASER ° C ° F Laser emitting hole Infrared sensor aperture ○ ○ Laser on/off switch °C/°F switch ○...

  • Page 7: Operation Instructions: Measuring Trigger

    Infrared Recorder V. OPERATION INSTRUCTIONS • Measuring Trigger To measure a temperature, point the unit at an object and pull the trigger. Be sure to consider distance-to-spot size ratio and field of view. The laser is used for aiming the target for reference.

  • Page 8: Maintenance

    Infrared Recorder give inaccurate readings. Please note this during applications. • Maintenance Blow off loose particles using a lens blow. Gently brush remaining debris away with a lens brush. Carefully wipe the surface with a moist cotton swab. The swab may be moistened with water.
  • Page 9 CENTER TECHNOLOGY CORP. 4 / F NO. 415, Jung-Jeng Rd., 238 Shu-Lin, Taipei, Taiwan E-Mail : center@centertek.com http : / / www.centertek.com 350-00 Distributor in Australia Pacific Sensor Technologies Pty Ltd Unit 4, 3 Neutron Place Rowville, VIC 3178 Australia 1300 662 720 | sales@pacificsensortech.com.au...
