Summary of Contents for Center 306
- Page 1 SE-305 Datalogger SETUP TIME HOLD CLOCK INTV °C/°F RANGE -200°C 1370°C -328°F 2498°F POWER-UP OPTIONS...
-
Page 2: Table Of Contents
CONTENTS TITLE PAGE I. Introduction …………………………………………………………………………….…..1 II. Specifications …………………………………………………………………………… 1 III. Symbol Definition and Button Location ……………………………….2 IV. Operation Instructions …………………………………………….……………… 3 4.1 Power-Up…………………………………………………………………………………..3 4.2 Connection the Thermocouples………………………………………………………...3 4.3 Selecting the Temperature Scale………………………………………………………. 3 4.4 Data-Hold Operation……………………………………………………………………… 3 4.5 DataLogger………………………………………………………………………………… 3 4.6 Clock Setup ……………………………………………………………………………….. -
Page 3: Introduction
Data Logger Instruction Manual I. Introduction: This instrument is a digital thermometer for use with any K-type thermocouple as temperature sensor. Temperature indication follows National Bureau Standards IEC584 temperature/voltage table for K-type thermocouples. Its internal memory can keep up to 16312 records.(note1.) It uses RS232 interface to perform bi-directional communication with PC. -
Page 4: Symbol Definition And Button Location
Data Logger Instruction Manual III. Symbol Definition and Button Location: : This indicates that the minus temperature is sensed. ℃℉ : Centigrade and Fahrenheit indication. : Thermocouple Type Indication MAX : The Maximum value is now being displayed : The Minimum value is now being displayed : This indicates auto power off is enabled. -
Page 5: Operation Instructions
Data Logger Instruction Manual IV. Operation Instructions: 4.1 Power-Up Press the power button to turn the thermometer ON or OFF. When the user powers on, the LCD will show how much memory space is available to use. For example: It indicates that there are 16,000 records memory space available. 4.2 Connection the Thermocouples For measurement, plug the thermocouple into the input connectors. -
Page 6: Recording Interval Setup
Data Logger Instruction Manual 4.7 Recording Interval Setup : 1: press and hold “MAX MIN” button and then power on the meter: 2: press “HOLD"(INTV) 3: press "REC" ▲ or "°C/°F" ▼ to increase or decrease number, press “HOLD" (INTV) to adjust next item, then press “HOLD” (INTV) to finish. -
Page 7: Digital Output
Data Logger Instruction Manual 4.13 Digital Output: The Digital Output is a 9600bps N 81 serial interface. The RX is a 5V normal high input port. The TX is a 5V normal high output port. The command of Digital Output is list below: RS232 command Function Remarks... - Page 8 Data Logger Instruction Manual bit3: 1→Indicates the LCD is displaying time. bit4: no use bit5: 1→HOLD, 0→not HOLD bit6: 1→LOW BATTERY , 0→BATTERY NORMAL bit7: 1→°C 0→°F BYTE: bit7 bit6 bit5 bit4 bit3 bit2 bit1 bit0 Auto Power Off memory full resolution sign resolution sign bit0: 1→T1 is OL, 0→not OL...
-
Page 9: Setup Se305 (Thermo Datalogger)-Rs232 Interface Software
Data Logger Instruction Manual V. Setup SE305 (Thermo DataLogger) RS232 interface software: — The SE305 package contains: 1.One setup CD. 2.Custom designed RS232 cable for SE305 System Required: Windows 98/ NT 4.0/ NT2000/ XP / VISTA. Minimum Hardware Required: 486-100 MHz PC compatible , 16 MB RAM ; At least 5 MB hard disk space available to install SE305 program. - Page 10 Data Logger Instruction Manual View | Control Panel: By opening the Panel Window, the user can control meter via the button in this window. View | Real-Time Graph: Open Real-Time Graph display to graph the present data. Real Time | Run - Start collecting real time data . Stop - Stop collecting real time data .
- Page 11 CENTER TECHNOLOGY CORP. 4 / F NO. 415, Jung-Jeng Rd., 238 Shu-Lin Chien, Taipei, Taiwan E-Mail : center@centertek.com http : / / www.centertek.com 306-03...
