- Page 1 DISHWASHER ZDF 301 www.video.uk.electrolux.com Instruction Book 117995 01/0...
-
Page 2: Table Of Contents
Contents Safety instructions Something not working Disposal Service and Spare Parts Economical and ecological dishwashing Customer Care Department Description of the appliance Guarantee Conditions The control panel Installation instructions Fitting under a counter Prior to using for the first time Levelling The water softener Water supply connections... -
Page 3: Safety Instructions
Safety instructions It is most important that this instruction book should be retained with the appliance for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is left with the appliance in order that the new owner can get to know the functioning of the appliance and the relevant safety information. -
Page 4: Description Of The Appliance
Description of the appliance Upper basket stop Water hardness dial Salt container Detergent dispenser Control panel Rating plate Rinse aid dispenser Filters Lower spray arm 10. Upper spray arm 11. Upper basket 12. Worktop IN144... -
Page 5: The Control Panel
The control panel Delay start button Start/cancel indicator light On-Off indicator light Phase indicator lights Programme selection marker Programme selector dial Control indicator lights Programme guide Start/cancel button Programme selector dial and On-Off indicator Phase indicator lights: have the following meanings: light: the selection of a washing programme occurs by Wash... -
Page 6: Prior To Using For The First Time
Prior to using for the first time Before using your dishwasher for the first time: b) Setting electronically (The dishwasher must be switched off) 1. Ensure that the electrical and water connections comply with the installation instructions The dishwasher is factory set at level 5. 2. -
Page 7: Filling With Dishwasher Salt
Filling with dishwasher salt Rinse aid Only use salt specifically designed for use in Rinse aid is automatically added during the last rinse, ensuring dishwashers. thorough rinsing, and spot and streak free drying. All other types of salt not specifically designed for use in The dispenser, which is positioned inside the door, holds about a dishwasher, especially table salt, will damage the water 110 ml of rinse aid, which is sufficient for between 16 and 40... -
Page 8: In Daily Use
In daily use Check if it’s necessary to refill with dishwasher salt or rinse Loading cutlery and dishes Sponges, household cloths and any object that can Load cutlery and dishes into the dishwasher. absorb water may not be washed in the dishwasher. Fill with dishwasher detergent . -
Page 9: The Cutlery Basket
The cutlery basket The upper basket The upper basket is designed for plates (dessert plates, Long bladed knives stored in an upright position are a saucers, dinner plates of up to 24 cm in diameter), salad potential hazard. bowls, cups and glasses. Long and/or sharp items of cutlery such as carving knives must be positioned horizontally in the upper basket. -
Page 10: Adjusting The Height Of The Upper Basket
Adjusting the height of the upper basket Use of detergent If washing very large plates you can load them in the lower Only use detergents specifically designed for use in basket after moving the upper basket to the higher position. dishwashers. -
Page 11: Different Kinds Of Detergent
Different kinds of detergent Detergent tablets Use of "3 in 1" combi detergents Detergent tablets from different manufactures dissolve at These products are detergents with a combined cleaning, different rates. For this reason, some detergent tablets do not rinsing and salt function. attain their full cleaning power during short washing 1. -
Page 12: Washing Programmes
Washing programmes Programme Degree of soil Position Cycle description (2) Consumption values of the Energy Water Programme type of load programme consumption consumption duration (in kWh) (in litres) (in minutes) selector dial Hot prewash Main wash up to 70°C Heavy soil. Intensive 70°... -
Page 13: Starting A Washing Programme
Starting a washing programme 1. Check that the baskets have been 5. To interrupt or cancel a washing loaded correctly and that the spray programme in progress arms can rotate freely Interrupt or cancel a washing programme in progress ONLY if it’s absolutely necessary. Attention! Hot steam may escape when the door is opened. -
Page 14: Maintenance And Cleaning
Maintenance and cleaning Clean the external surfaces of the machine and control panel 9. Put the filter combination in place and lock by turning the with a damp soft cloth. If necessary use only neutral handle clockwise to the stop. During this process ensure detergents. -
Page 15: Something Not Working
Something not working Certain problems are due to the lack of simple maintenance or oversights, which can be solved with the help of the instructions given here, without calling out an engineer. Important: If you call out an engineer to a fault listed below or to repair a fault caused by incorrect use or installation a charge will be made, even if the appliance is in guarantee. - Page 16 ...the wash results are not satisfactory The dishes are not clean The wrong washing programme has been selected. The dishes were arranged in such a way as to stop water reaching all parts of the surface. The baskets must not be overloaded. The spray arms do not rotate freely due to incorrect arrangement of the load.
-
Page 17: Service And Spare Parts
Service and Spare Parts In the event of your appliance requiring service, or if you wish to purchase spare parts please contact your local Service Force Centre by telephoning: 08705 929929 Your telephone call will be automatically routed to the Service Force Centre covering your post code area. -
Page 18: Guarantee Conditions
Guarantee Conditions Standard Guarantee Conditions European Guarantee We, Zanussi-Electrolux, undertake that if within 12 months of If you should move to another country within Europe then your the date of purchase this ZANUSSI-ELECTROLUX appliance guarantee moves with you to your new home subject to the or any part thereof is proved to be defective by reason only of following qualifications: faulty workmanship or materials, we will, at our option repair or... -
Page 19: Installation Instructions
Installation instructions Any electrical and/or plumbing work required to install The water inlet hose must not be kinked, crushed, or entangled this appliance should be carried out by a qualified when it is being connected. electrician and/or plumber or competent person. The inlet hose must hang down vertically from the supply tap. -
Page 20: Electrical Connection
Electrical connection WARNING: THIS APPLIANCE MUST BE EARTHED. The manufacturer declines any responsibility should this safety measure not be observed. If the plug that is fitted to your appliance is not suitable for the socket, it must be cut off and the appropriate plug fitted. Important The wires on the mains lead are coloured in accordance with the following code:... -
Page 21: Hints For Test Centres
Hints for test centres Testing in accordance with EN 60704 must be carried out with appliance fully loaded and using the test programme (see "Washing programmes" chart). Test in accordance with EN 50242 must be carried out when the salt container and rinse aid dispenser have been filled with salt and rinse aid respectively and using the test programme (see "Washing programmes"... - Page 24 From the Electrolux Group. The World’s No.1 choice. The Electrolux Group is the world’s largest producer of powered appliances for kitchen, cleaning and outdoor use. More than 55 million Electrolux Group products (such as refrigerators, cookers, vacuum cleaners, chain saws and lawn mowers) are sold each year to a value of approx. 14 billion USD in more than 150 countries around the world.
