  • Page 1 User manual Dishwasher ZDF 511...

  • Page 2: Table Of Contents

    Thank you for selecting our appliance We wish you lots of enjoyment with your new appliance and we hope that you will consider our brand again when purchasing household appliances. Please read this user manual carefully and keep it throughout the product life cycle as a reference document.

  • Page 3: Safety Information

    Safety information In the interest of your safety and to ensure the correct use, before installing and first using the appliance, read this user manual carefully, in- cluding its hints and warnings. To avoid unnec- essary mistakes and accidents, it is important to ensure that all people using the appliance are thoroughly familiar with its operation and safety features.
  • Page 4 Installation • Check your dishwasher for any transport damage. Never connect a damaged ma- chine. If your dishwasher is damaged con- tact your supplier. • All packaging must be removed before use. • Any electrical and plumbing work required to install this appliance must be carried out by a qualified and competent person.

  • Page 5: Control Panel

    Control panel On/Off button Programme selection buttons Delay start button Indicator lights Digital display Function buttons Setting mode IMPORTANT! Always remember that when performing oper- ations as: – selecting a washing programme, – setting the water softener, – activating/deactivating the rinse aid dispens- the appliance MUST be in setting mode: •...
  • Page 6 In this case the programme has to be cancelled (see instructions “Cancel a washing pro- gramme in progress”). Function buttons Digital display IMPORTANT! Select the washing programme and the delay start with the door slightly opened. The start of the programme or the countdown of the delay In addition to the dishwashing programme selection, the following functions can also be set with the help of these buttons.
  • Page 7 Programme selection buttons • Starting the washing programme: 1. Press the On/Off button. 2. Press the button corresponding to the required programme, the corresponding light remains illu- minated while the other programme lights turn off. In the digital display will appear, flashing, the run- ning time of the programme (in minutes).
  • Page 8 Delay start button IMPORTANT! The selection of the washing programme and delay start can occur also with the door closed. Keep in mind that in this way, once a washing programame button is pressed you have ONLY Programme in progress light End of programme light 3 in 1 light Salt refilling light...

  • Page 9: Washing Programmes

    Washing programmes Programme Intensive 70° Heavy soil AUTO 65° 50° Normal / Light soil. Eat-Load-Run Light soil 30 min. 50° Normal soil Rinse and Hold Any. Partial load (to be completed later in the day). 1) Ideal for washing a partially loaded dishwasher. This is perfect daily programme, made to meet the needs of a family of 4 persons who only wish to load breakfast and dinner crockery and cutlery.

  • Page 10: First Use

    For this reason the programme duration, water and energy consumption levels can vary within the stated range for "Auto" programme (see "Washing programmes chart"). First use Before using your dishwasher for the first time: • Ensure that the electrical and water connec- tions comply with the installation instructions •...

  • Page 11: Setting The Water Softener

    Water hardness Clarke °TH 23 - 27 33 - 39 18 - 22 26 - 32 13 - 17 19 - 25 5 - 12 7 - 18 < 5 < 7 The water softener must be set in both ways: manually, using the water hardness dial and electronically.

  • Page 12: Filling With Dishwasher Salt

    1. Press the On/Off button. The dishwasher must be in setting mode. 2. Simultaneously press and hold function buttons B and C, until the lights of function buttons A, B and C start flashing. 3. Press function button A, the lights of func- tion buttons B and C turn off while the light of function button A goes on flashing.

  • Page 13: Filling With Rinse Aid

    Remove any trace of salt. Replace the cap tightly turning it clockwise until it stops with a click. IMPORTANT! Top up the special salt when the light on the control panel illuminates. Filling with rinse aid Open the lid. CAUTION! Never fill the rinse aid dispenser with any other sub- stances (e.g.

  • Page 14: Adjusting The Dosage Of Rinse Aid

    Adjusting the dosage of rinse aid Increase the dose if there are drops of water or lime spots on the dishes after washing. Open the lid. Loading cutlery and dishes Sponges, household cloths and any object that can absorb water may not be washed in the dishwasher.
  • Page 15 For washing in the dishwasher the following cutlery and dishes are not suitable: • Cutlery with wooden, horn, china or mother-of- pearls handles. • Plastic items that are not heat resistant. • Older cutlery with glued parts that are not temper- ature resistant.

  • Page 16: Upper Basket

    The two rows of prongs on the lower basket can be easily lowered to allow you to load pots, pans and bowls. Load upper basket. Light For taller items, the cup items (plastic bowls etc.) racks can be folded up- must be loaded in the up- wards.

  • Page 17: Use Of Detergent

    To move to the higher position proceed as follows: 1. Pull out the basket until it stops. 2. Carefully lift both sides upwards until the mecha- nism is engaged and the basket is stable. To lower the basket to the original position proceed as follows: 1.

  • Page 18: In 1 Function

    For programmes with pre- When using detergent wash add an additional tablets: place detergent detergent dose in com- tablets in compartment A. partmentB. "3 in 1 function" This appliance is equipped with the "3 in 1 func- tion", that allows the use of the "3 in 1" combi detergent tablets.

  • Page 19: Unloading The Dishwasher

    function "indicator light illuminates. This means that the function is active. To deactivate the function press the same but- tons again until the indicator light correspond- ing to the "3 in 1" symbol turns off. If the drying results are not satisfactory we suggest that you: 1.

  • Page 20: Care And Cleaning

    Care and cleaning Cleaning the filters IMPORTANT! NEVER use the dishwasher without filters. In- correct repositioning and fitting of the filters will produce poor washing results. Clean filters A, B and C thoroughly under running water. Put the flat filter A back in Replace the filters and the base of the washing lock by turning the handle...

  • Page 21: Environmental Concerns

    Internal cleaning Ensure that the seals around the door, the de- tergent and rinse aid dispensers are cleaned regularly with a damp cloth. We recommend every 3 months to run the wash programme for heavy soiled dishes using de- tergent but without dishes. Prolonged periods of non- operation If you are not using the machine for any pro-...

  • Page 22: Something Not Working

    correctly, you will help prevent potential nega- tive consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. For more detailed information about Something not working The dishwasher will not start or stops during operation.
  • Page 23 Fault code and malfunction The programme does not start. Once these checks have been carried out; close the dishwasher’s door and switch on the appliance. Press the button of the programme that was running before the intervention of the alarm. The programme will continue from the point at which it was interrupted.

  • Page 24: Technical Data

    The dishes are not clean The dishes are wet and dull There are streaks, milky spots or a bluish coating on glasses and dishes Water drops have dries onto glasses and dishes If after all these checks, the problem persists, contact your local Service Force Centre.

  • Page 25: Consumption Values

    Noise level Consumption values The consumption values are intended as a guide and depends on the pressure and the temperature of the water and also by the var- Programme Programme duration (in Intensive 70° AUTO 50° 65° Eat-Load-Run 30 min. ECO 50°...

  • Page 26: Installation

    Rinse aid setting Upper basket cup racks: position A Installation WARNING! Any electrical and/or plumbing work required to install this appliance should be carried out by a qualified electrician and/or plumber or compe- tent person. Water connection WARNING! The dishwasher must not be connected to open water appliances or instantaneous water heat- ers.

  • Page 27: Inlet Hose

    Inlet hose Connect the inlet hose to a water tap with an external thread of 3/4”. The inlet hose can be turned either to the left or the right to suit the installation by means of the locknut. The locknut must be correctly fitted to avoid water leaks.

  • Page 28: Electrical Connection

    Electrical connection CAUTION! Safety standards require the appliance to be earthed. Prior to using the appliance for the first time, ensure that the rated voltage and type of supply on the rating plate match that of the supply where the appliance is to be installed. The fuse rating is also to be found on the rating plate.

  • Page 29: Guarantee Conditions

    Guarantee conditions Guarantee/Customer Service Standard guarantee conditions We, Zanussi-Electrolux , undertake that if within 12 months of the date of the purchase this Za- nussi-Electrolux appliance or any part thereof is proved to be defective by reason only of faulty...

  • Page 30: European Guarantee

    address below or visit our website at www.electrolux.co.uk Customer Care Department Electrolux Major Appliances Addington Way Luton Bedfordshire, LU4 9QQ Tel: 08705 727 727 (*) (*) Calls may be recorded for training purposes European Guarantee This appliance is guaranteed by Electrolux in each of the countries listed at the back of this user manual, for the period specified in the ap- pliance guarantee or otherwise by law.
  • Page 31 LU4 9QQ 4, Limnou Str., 54627 Thessaloniki Slavonska avenija 3, 10000 Zagreb Long Mile Road Dublin 12 C.so Lino Zanussi, 26 - 33080 Por- cia (PN) Kr. Barona iela 130/2, LV-1012, Ri- Ozo 10A, LT 08200 Vilnius Rue de Bitbourg, 7, L-1273 Hamm H-1142 Budapest XIV, Erzsébet...
  • Page 32 Россия +7 495 937 7837 129090 Москва, Олимпийский проспект, 16, БЦ "Олимпик"...
  • Page 36 156996220-00-20032007 Subject to change without notice...
