Rohl Perrin & Rowe U.3720L Installation Instructions

9.20705*
9.25552
9.18705*
9.20730*
9.18730*
9.26709*
9.26705*
9003700U Issue 5
Consult your local ROHL showroom for additional information and specifications. For complete warranty details and a list of showrooms, go to www.rohlhome.com.
INSTALLATION INSTRUCTIONS
• U.3705L / U.3706X
6 " - 16" CENTERS
2
Ø
Ø1 3/8" Ø1 1/8"
HOLE
COLD IN
HOT IN
1/2" NPT
1/2" NPT
• U.3720L
• U.3721X
6 " - 16"
2 1/4"
Ø
Ø
Ø 1 1/8"
1 3/8"
HOLE
• Temp Range:
Min 34ºF
Max 185ºF
• Recommended
Working Pressure:
Min 15 psi
Max 75 psi
Ideal performance obtained with equal hot & cold pressures.
The Traditional Bathroom Collection
Installation & User Guide
3 HOLE
WIDESPREADS
1/2"
Ø 2 "
7 1/2" CENTERS MAX
6 1/2"
• U.3730L
• U.3731X
5 1/2"
www.rohlhome.com
7 1/4"
2 1/8"
Ø
5 1/2"
1 1/4"
Ø
• U.3700L
• U.3701X
5 1/4"
• U.3760L
• U.3761X
4 1/2"
