Summary of Contents for Medion LIFETAB E10911
- Page 1 User Manual 25,5 cm / 10″ Tablet PC MEDION LIFETAB ® ® E10911 (MD 60527)
-
Page 2: Table Of Contents
Table of contents Information about this user manual ............5 1.1. Explanation of symbols ..................5 1.2. Proper use ........................ 7 Safety information ..................7 2.1. Restricted group of people ................7 2.2. Information regarding the mains adapter ........... 8 2.3. - Page 3 Optional accessories for your Lifetab® ............. 23 Frequently asked questions..............24 Cleaning and care ..................25 Storing the device when not in use ............25 EU – Declaration of Conformity ..............26 15.1. Trademark information ..................27 Technical specifications ................27 16.1.
-
Page 4: Information About This User Manual
1. Information about this user manual Thank you for choosing our product. We hope you enjoy using this device. Please read the safety instructions and the user manual carefully before using this product for the first time. Note the warnings on the device and in the user manual. - Page 5 Follow the instructions in the user manual! Devices with this symbol are intended solely for indoor use. Due to the 5 GHz frequency range of the wireless LAN solution used, the device may only be used inside buildings in the EU. Protection class II Electrical devices in protection class II are devices that have double and/or reinforced insulation throughout, and do not have...
-
Page 6: Proper Use
1.2. Proper use This is an information electronics device. Your tablet PC is intended to be used for the following purposes: ...accessing the internet via WLAN ...playing audio and video files ...editing and managing electronic documents and multimedia content etc. The device is only intended for private use and not for industrial/ commercial use. -
Page 7: Information Regarding The Mains Adapter
Children must not be allowed to play with the device. Cleaning and maintenance must not be carried out by children. DANGER! Risk of choking and suffocation! There is a risk of choking and suffocation if plastic film or small parts are breathed in or swallowed. ... - Page 8 Children younger than 8 must be kept away from the device and the mains adapter. Avoid exposing the device and the mains adapter to water droplets or spray and do not place any liquid-filled containers, such as vases, on or next to the device or the mains adapter. Liquids penetrating the device may impair the electrical safety of the product.
-
Page 9: Restricted Use
Do not expose plug connections to impacts/pressure, e.g. from lateral forces. This could cause internal and external damage to the device. Do not apply force when connecting cables and plugs and make sure that connectors are the right way round. ... -
Page 10: Information On The Integrated Rechargeable Battery
• In places where it is compulsory to switch off radio-controlled equipment, e.g. on major construction sites or in places where blasting operations are carried out. Due to the 5 GHz WLAN technology used, the tablet PC may only be used inside buildings. ... -
Page 11: General Instructions On How To Handle Lithium-Ion Batteries
Do not take the rechargeable batteries apart or deform them. Leaked liquids must not come into contact with the skin, eyes or mucous membranes. Do not swallow the liquid under any circumstances. Always wear appropriate protective gloves when handling leaking rechargeable batteries. -
Page 12: Data Backup
Only operate the tablet PC at an ambient temperature of between +5°C and +30°C and relative air humidity of between 20% and 80% (non-condensing). Do not drop, knock or shake the tablet PC. Being rough with the device can cause damage to internal parts. ... -
Page 13: If There Are Defects
If the device is exposed to strong sunlight for a prolonged period, the screen may appear defective if the display has not been updated. Updating the display will get rid of any such effects. 3.3. If there are defects ... -
Page 14: Device Overview
• Warranty documents 5. Device overview 5.1. Front Rear camera (on the back of the device, not shown) Front camera On/Off button Increase volume (+) Decrease volume (-) Touch display Speaker... -
Page 15: Left-Hand Side Of The Device
5.2. Left-hand side of the 5.3. Top device Microphone Headphone socket USB-C port Micro SIM card slot Micro SD card slot 6. Preparing for fi rst use 6.1. Power supply NOTICE! Risk of damage! There is a risk of causing damage to the device by using unauthorised accessories. -
Page 16: Charging The Battery
The battery will also be charging when you are using the tablet PC with the mains adapter connected. If the mains adapter is plugged into the mains socket, it will still use a small amount of electricity even if the tablet PC is not connected to the mains adapter. -
Page 17: Removing The Sim Card
During active data transfer via the mobile phone network, you may be charged for the amount of data you use. We recommend signing up for a flat-rate internet package to limit these costs. Contact your mobile network provider for more information about the costs and, if necessary, the most appropriate tariff for you. -
Page 18: Putting The Tablet Pc Into Sleep Mode
7.4. Putting the tablet PC into sleep mode Briefly press the On/Off button once to put the tablet PC into sleep mode. Some apps will continue to use power even when the device is in sleep mode. The device usually remains ready for use in sleep mode for several days before it needs to be connected to the mains adapter. -
Page 19: Enabling Wlan
8.2. Enabling WLAN We recommend that you follow the steps below to connect the tablet PC to a WLAN network: Open the SETTINGS app. Open the network and Internet configuration menu. Enable the WLAN function in the corresponding submenu. A list of all of the available WLAN access points near you will then appear. -
Page 20: Connecting The Tablet Pc To A Pc
9. Connecting the tablet PC to a PC You can connect your tablet PC to a PC using the supplied USB cable so that data can be transferred between the two devices. Plug the USB-C connector of the USB cable into the corresponding port on the tablet PC and then plug the USB connector into an empty USB port on your PC. -
Page 21: Removing The Micro Sd Memory Card
If you decide to use the inserted memory card as internal tablet memory, it will be used in addition to the device’s internal memory. This means that you may not be able to access saved data and apps when the memory card is not inserted. -
Page 22: Connecting A Usb Memory Device
An optional protective case with detachable Bluetooth® keyboard and an active stylus pen for inputting notes and drawings can be purchased for your Lifetab from the MEDIONshop (www.medion.com). Enter the following article numbers to retrieve the respective accessory in the... -
Page 23: Frequently Asked Questions
12. Frequently asked questions How do I reset the tablet PC to factory settings? Open the SETTINGS app. You can reset the system back to factory settings in the advanced system settings. NOTICE! Loss of data! When you do this, all of the data on the tablet PC’s internal memory will be deleted. -
Page 24: Cleaning And Care
Why are Bluetooth and WLAN disabled? Check whether flight mode has been enabled. If so, all radio connections, including Bluetooth and WLAN, will have been disabled. Switch flight mode off. How do I set the resolution for video recordings? The default setting for the video resolution on your tablet PC is 1280 x 720 pixels (HD). -
Page 25: Eu - Declaration Of Conformity
Ecodesign Directive 2009/125/EC (and Ecodesign Regulation 2019/1782) • RoHS Directive 2011/65/EU You can download the complete EU Declaration of Conformity at www.medion. com/conformity. Due to the 5 GHz frequency range of the integrated wireless LAN solution, the device may only be used inside buildings in the EU (see table). -
Page 26: Trademark Information
Google LLC and are used by MEDION under licence. The USB™ word mark and the logos are registered trademarks of the USB Implementers Forum, Inc. and are used by MEDION under licence. Other trademarks are the property of their respective owners. - Page 27 Battery (built-in) Capacity: 6000 mAh Energy: 22.8 Wh Ambient conditions Temperatures (in operation): +5°C to +30°C Temperatures (not in operation): 0°C to +60°C Relative humidity: 20% to 80% Display Type: 25.5 cm/10" IPS panel Native resolution: 1920 x 1200 pixels Display colours: 16.7 million (with 8 Bit) Bluetooth®...
-
Page 28: Information About The Radio Technology Used
Audio formats supported by Android™ WAV, MP3, MP2, AAC, AMR-NB, AMR-WB, MIDI, Vorbis, APE, AAC-plus v1, AAC-plus v2, FLAC, WAV, ADPCM Front camera Resolution: 2 megapixels Video resolution: 1280 x 720 pixels Back camera Resolution: 8 megapixels Video resolution: 1920 x 1080 pixels Connections Headphones: 3.5 mm, CTIA... -
Page 29: Disposal
In our Service Community, you can meet other users, as well as our staff, and you can exchange your experiences and pass on your knowledge there. You will find our Service Community at community.medion.com. • Alternatively, use our contact form at www.medion.com/contact. -
Page 30: Privacy Statement
19. Privacy statement Dear customer, We wish to inform you that we, MEDION AG, Am Zehnthof 77, 45307 Essen, Germany process your personal data as a data controller. For matters regarding data protection, we are supported by our company data protection officer who can be contacted at MEDION AG, Datenschutz, Am Zehnthof 77, D –... -
Page 31: Licence Information
You can access the source code for this product in the following ways: • Visit the MEDION Service page at http://www.medion.com/gb/service/ and type the name, MD number or MSN number of your device into the search box. You can find this information on the back of your device. Select the “Software”...
