Daewoo DWM-160C Service Manual page 23

ass'y main
NO. PART NAME
1 ASSY CABINET
2 PLATE UPPER
3 SCREW TAPPING
4 COVER BACK
5 SCREW TAPPING
6 BASE UNDER
7 SCREW TAPPING
8 CUSHION SPOT
9 CUSHION MOTOR
10 MOTOR WASH
11 SPECIAL SCREW
12 PULLEY MOTOR AS
PULLEY MOTOR AS
13 WASHER PLAIN
14 WASHER SPRING
15 NUT HEX
16 BELT V
17 UNIT DRAIN PUMP AS
18 FIXTURE PUMP
19 SCREW TAPPING
20 UNIT CAPACITOR
21 CAPACITOR WASH
22 CAPACITOR SPIN
23 HARNESS CONDENSER
24 CORD POWER AS
25 COUPLING DRUM AS
26 SPECIAL BOLT AS
PART CORD SPECIFICATION
PRCACA6200 DWM-160C 0.6T
3614525100 SGCC 0.6T
7122401011 T2S TRS 4*10 MFZN
3611419800 SECC 0.4T
7112400811 T1 TRS 4*8 MFZN
3610390800 PP
7122401011 T2S TRS 4*10 MFZN
450M712010 PP
450M712020 NR
3618961900 220~240V/50HZ,W1S35VD060
3618961600 110V/60HZ,W1S35ED060
3618961800 220V/60HZ,W1S35UD060
3618962000 W1S35GD060
3616003100 M5X35 WASHER
3618431700 PRESS(SGCC1.2T,D31),2.1MM
3618431600 PRESS(SGCC1.2T,D24),4.3MM
7400108411 PW-1-8.4 MFZN
7401008011 SW-8 MFZN
7392800011 M8*P1.25 MFZN
450M700020 M-32
3616590700 M-24
3618964800 AC 220~240V, 50HZ,PLASET
3618964900 AC 110V, 60HZ,PLASET
3612005700 PP
7112402011 T1 TRS 4X20 MFZN
3618948200 9.7/5.2 400/440 CON-4P
3618948600 45.6/25 200/200 CON-4P
4505E11000 25+25UF
4509C11020 200V 20.8UF*2
4509C11010 MF CAPACITOR 200V 20.8MF
3612706710 CONN A,B
3611332100 T VACTFK 2*0.75 2.3M GY
3611331700 A VACTFK 2*0.75 2.3M GY
3611331310 VCTF 3*0.75 2.3M GY
3611331630 H05VV-F 3*0.75 WH
3611331650 H05VV-F 3*0.75 BK
3611331110 VCTF 3*0.75 2.3M GY
3611331810 H05VV-F 3*0.75 2.3M BK
3611332100 VCTFK 2*0.75 2.3M GY
3611331930 C SJT 3*18AWG 2.3M GY
3611331700 A VCTFK 2*0.75 2.3M GY
3611331700 FH05VV 3*0.75 2.3M BK
3617002100 DWM-160C
3616008000 6B-1-M8X12
Q'TY REMARKS
1.0
1.0
4.0
1.0
4.0
1.0
7.0
1.0
3.0
1.0 N(P), M(P)
1.0 T(P)
1.0 L
1.0 D,S
3.0
1.0 50HZ
1.0 60HZ
1.0
1.0
1.0
1.0 DWM-160C
1.0 DWM-170C
1.0 NP, MP
1.0 TP
1.0
1.0
1.0 L,N(P),M(P)
1.0 T(P)
1.0 D, DUAL
1.0 S, DUAL
1.0 D,S,DUAL
1.0 DUAL
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
2.0
21
