Daewoo DWM-160C Service Manual page 19

ass'y panel (DWM-160C's)
NO. PART NAME
1 KNOB
2 PANEL B
3 SCREW TAPPING
4 LEVER W.S SELECT
5 HOSE SPRAY
6 TIMER SPIN
7 TIMER WASH
TIMER WASH
8 SWITCH DRAIN
9 LEVER CONTROL
10 LINK VALVE
11 BRACKET PANEL
12 SCREW TAPPING
13 SWITCH DRAIN
14 HARNESS DRAIN
ACCESSORY ASS'Y (DWM-160C)
NO. PART NAME
1 COVER SAFETY
2 HOSE DRAIN O AS
3 HOSE DRAIN O AS
PART CORD SPECIFICATION
3613403800 DWM-160C, ABS
3614239000 HIPS
7122401411 T2S TRS 4X14 MFZN
3613702300 PP
3613201201 PE-LD
3619911200 S-160CA
3619911100 S-DT15NT
3619911300 S-K16NT
3619043700 VP531A-2H,250VAC/15A
3613701400 POM
3617804200 PP BAND W6 L=784
3610606200 PP
7122401411 T2S TRS 4X14 MFZN
3619045300 VO, SZM-V15-18FA-91
3612790600 160CP SW DRAIN L=1100
PART CORD SPECIFICATION
3611419900 LDPE(DIA:286)
3613222910 1100MM, HANGER, NON CLAMP
3613218800 LD-PE/EVA L=1600 PUMP
Q'TY REMARKS
4.0
1.0
3.0
1.0
1.0
1.0
1.0 OPTION
1.0 OPTION
1.0
2.0
1.0
1.0
3.0
1.0 PUMP MODEL
1.0 PUMP MODEL
Q'TY REMARKS
1.0
1.0 NON PUMP
1.0 PUMP MODEL
