Alliance Laundry Systems Speed Queen FF7009WN Installation Instructions Manual

Alliance Laundry Systems Speed Queen FF7009WN Installation Instructions Manual

Advertisement

Installation Instructions
for Dryers
Original Instructions
Keep These Instructions for Future Reference.
CAUTION: Read the instructions before using the machine.
(If this machine changes ownership, this manual must accompany machine.)
Part No. D514320ENR6
www.speedqueen.com
April 2022

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Speed Queen FF7009WN and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Alliance Laundry Systems Speed Queen FF7009WN

  • Page 1 Installation Instructions for Dryers Original Instructions Keep These Instructions for Future Reference. CAUTION: Read the instructions before using the machine. (If this machine changes ownership, this manual must accompany machine.) Part No. D514320ENR6 www.speedqueen.com April 2022...
  • Page 3 Installation and service must be performed by a appliance. qualified installer, service agency or the gas sup- plier. W053 W052 This product uses FreeRTOS V7.2.0 (www.freertos.org). © Copyright, Alliance Laundry Systems LLC - Part No. D514320ENR6 DO NOT COPY or TRANSMIT...
  • Page 4 A “T-Handle” type gas shut-off valve must be installed in the gas supply line to this appliance. • This appliance must not be installed in a bedroom or bath- room. © Copyright, Alliance Laundry Systems LLC - Part No. D514320ENR6 DO NOT COPY or TRANSMIT...
  • Page 5: Table Of Contents

    Installer Checklist.................24 © Copyright 2021, Alliance Laundry Systems LLC All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means without the expressed written consent of the publisher.
  • Page 6: Dimensions

    28 in. [711 mm] 23.5 in. [597 mm] NOTE: Exhaust openings are 4 inch [102 mm] metal * With leveling legs turned into base. ducting. © Copyright, Alliance Laundry Systems LLC - Part No. D514320ENR6 DO NOT COPY or TRANSMIT...
  • Page 7 For maximum drying per- formance, we recommend that more clearance be al- lowed around the dryer than the clearances that are listed throughout this manual. © Copyright, Alliance Laundry Systems LLC - Part No. D514320ENR6 DO NOT COPY or TRANSMIT...
  • Page 8: Installation

    W299 Parts Included An accessories bag has been shipped inside your dryer. It in- cludes: • Product literature © Copyright, Alliance Laundry Systems LLC - Part No. D514320ENR6 DO NOT COPY or TRANSMIT...
  • Page 9 Installation DRY2500N_SVG 1. Dryer Base 2. Level 3. Leveling Leg Figure 2 © Copyright, Alliance Laundry Systems LLC - Part No. D514320ENR6 DO NOT COPY or TRANSMIT...
  • Page 10 Front View (Closet Door) 2 (G) DRY2637N_SVG 1. Closet Door 2. Centered Air Openings (G) (2 Openings minimum) 3. Outer Wall of Enclosure Figure 3 © Copyright, Alliance Laundry Systems LLC - Part No. D514320ENR6 DO NOT COPY or TRANSMIT...
  • Page 11: Connect Dryer Exhaust System

    To reduce the risk from substances in the fuel or from fuel combustion, make sure this appliance is installed, operated, and maintained according to the instructions in this manual. W115 © Copyright, Alliance Laundry Systems LLC - Part No. D514320ENR6 DO NOT COPY or TRANSMIT...
  • Page 12: Exhaust Direction

    Be certain old exhaust ducts are cleaned before installing your haust system is shown in Table 2 . new dryer. • Use 4 inch [102 mm] diameter rigid or flexible metal duct. © Copyright, Alliance Laundry Systems LLC - Part No. D514320ENR6 DO NOT COPY or TRANSMIT...
  • Page 13: Gas Dryers - Connect Gas Supply Pipe

    7.87 ft. [2.4 m] , as required to meet UL2158, clause 7.3.2.A. Gas Dryers - Connect Gas Supply Pipe © Copyright, Alliance Laundry Systems LLC - Part No. D514320ENR6 DO NOT COPY or TRANSMIT...
  • Page 14 Orifice Size Part feet [m] inches [mm] 3000 [915] 0.0890 [2.26] D503778 6000 [1830] 0.0860 [2.18] 58719 8000 [2440] 0.0820 [2.08] D503779 Table 3  continues... © Copyright, Alliance Laundry Systems LLC - Part No. D514320ENR6 DO NOT COPY or TRANSMIT...
  • Page 15: Electric Dryer Only - Connect Electrical Plug

    © Copyright, Alliance Laundry Systems LLC - Part No. D514320ENR6 DO NOT COPY or TRANSMIT...
  • Page 16: Connecting Power Cord With Three-Wire Plug

    Longer than 15 ft. (4.5 m) – use 8 AWG Wire Length Wire Less than 15 ft. [4.5 m] Listed No. 10 AWG Copper wire only Table 5  continues... © Copyright, Alliance Laundry Systems LLC - Part No. D514320ENR6 DO NOT COPY or TRANSMIT...
  • Page 17 15. Direct Connection 16. Power Cord Connection Figure 6 1. Disconnect power to dryer. 2. Remove access cover from rear of dryer. D695I_SVG Figure 7 © Copyright, Alliance Laundry Systems LLC - Part No. D514320ENR6 DO NOT COPY or TRANSMIT...
  • Page 18: Connecting Power Cord With Four-Wire Plug

    Connecting Power Cord with Four-Wire Plug NOTE: Four-wire cord is required for new branch-cir- cuit installations, mobile homes or where codes do not permit grounding through neutral. © Copyright, Alliance Laundry Systems LLC - Part No. D514320ENR6 DO NOT COPY or TRANSMIT...
  • Page 19: Reverse Door, If Desired

    10. Reinstall access cover and screw. Reverse Door, if Desired NOTE: Doors with windows cannot be reversed. © Copyright, Alliance Laundry Systems LLC - Part No. D514320ENR6 DO NOT COPY or TRANSMIT...
  • Page 20 DRY1918N_SVG Figure 20 7. Reinstall nine screws removed in Step 2. DRY1916N_SVG Figure 17 4. Rotate door panel 180 degrees as shown. DRY1919N_SVG Figure 21 © Copyright, Alliance Laundry Systems LLC - Part No. D514320ENR6 DO NOT COPY or TRANSMIT...
  • Page 21: Wipe Out Inside Of Dryer

    This appliance is to be supplied through a residual current device separately fused 15 Amp circuits. (RCD) having a rated residual operating current not exceeding 30 © Copyright, Alliance Laundry Systems LLC - Part No. D514320ENR6 DO NOT COPY or TRANSMIT...
  • Page 22: Recheck Steps

    The dryer is equipped with a cord having an equipment earth/ Gas Dryers ground conductor and a three-prong earth/ground plug. The © Copyright, Alliance Laundry Systems LLC - Part No. D514320ENR6 DO NOT COPY or TRANSMIT...
  • Page 23 3. 1/8 in. [3.1 mm] Pipe Plug (For checking manifold pressure) 4. Shut-off Valve Open Position 5. Shut-off Valve Closed Position 6. Shut-off Valve Handle Figure 27 © Copyright, Alliance Laundry Systems LLC - Part No. D514320ENR6 DO NOT COPY or TRANSMIT...
  • Page 24: Installer Checklist

    Cord. CHECK CHECK D679I_SVG1 Start and Run Dryer in Heat Setting to Verify Dryer is Heating. CHECK Refer to the manual for more detailed information © Copyright, Alliance Laundry Systems LLC - Part No. D514320ENR6 DO NOT COPY or TRANSMIT...
