SpeakerEnable/Disable

You may want to disable the
onboard speaker.
gives you this option.
table on the right for jumper set-
tings.
Onboard LAN/NIC
Enable/Disable
P3TDE6: Jumper JP58 only
P3TDER: Jumpers JP58 & JP62
Change the setting of jumper JP58/
JP62 to enable or disable the
onboard LAN or NIC (Network In-
terface Card) on the motherboard.
See the table on the right for
jumper settings.
ting is open.
Third Power Supply Failure
Alarm Enable/Disable
(P3TDE6 only)
This feature is for Supermicro Hot-
Swap Triple Redundant Power
Supplies only. When enabled, the
system will notify you in the event
of a power supply failure.
feature assumes that three power
supply units are installed in the
chassis, with one acting as a
backup. If you only have one or
two power supply units installed,
you should disable this with JP55
to prevent false alarms.
table on the right for jumper set-
tings.
Jumper JP56
See the
The default set-
This
See the
2-16
S p e a k e r E n a b le /D is a b le
J u m p e r S e tting s (J P 5 6 )
Jumper
P osition D efinition
O pen D isabled
C losed E nabled
O n b o a rd L A N 1 /L A N 2
E n a b le /D is a b le
J u m p e r S e tting s
(J P 5 8 & J P 6 2 )
Jumper
P osition D efinition
O pen E nabled
C losed D isabled
P o w e r S u p p ly F a ilu re
A la rm E n a b le /D is a b le
J u m p e r S e tting s (J P 5 5 )
Jumper
P osition D efinition
O pen D isabled
C losed E nabled
