Jumper Settings

Explanation of
Jumpers
To modify the operation of the
motherboard, jumpers can be
used to
optional settings.
create shorts between two pins
to change the function of the
connector. Pin 1 is identified
with a square solder pad on
the printed circuit board. See
the motherboard layout pages
for jumper locations.
No te : On two pin jumpers,
"Closed" means the jumper is
on and "Open" means the
jumper is off the pins.

CMOS Clear

Refer to the table on the right for
the jumper settings to clear CMOS.
Always remove the AC power
cord from the system before
clearing CMOS.
power supply, you must completely shut down
the system, remove the AC power cord and
then use JBT1 to clear CMOS. Replace JBT1
back to the pin 1-2 position before powering
up the system again. Do not use the PW_ON
connector to clear CMOS.
choose between
Jumpers
NOTE: For an ATX
C o n n e c t o r
Pins
J u m p e r
C a p
Setting
C M O S C le a r J u m p e r S e ttin g s
Jumper
P osition
1-2
2-3
Position
1-2
2-14
3 2 1
3 2 1
Pin 1-2 short
(J B T 1 )
D efinition
N ormal
C M O S C lear
Position
2-3
