Universal Serial Bus (Usb); Wake-On-Lan; Power Supply Fail Header; Sled1 (Scsi Led) Indicator - Supero SUPER P3TDE6 User Manual

S
UPER P3TDE6/P3TDER User's Manual

Universal Serial Bus (USB)

Two Universal Serial Bus ports
are located beside the keyboard/
mouse ports. USB0 is the bottom
connector and USB1 is the top
connector. See the table on the
right for pin definitions.

Wake-On-LAN

The Wake-On-LAN header is des-
ignated as WOL. See the table on
the right for pin definitions.
must enable the LAN Wake-Up set-
ting in BIOS to use this feature.
You must also have a LAN card
with a Wake-on-LAN connector
and cable.

Power Supply Fail Header

(P3TDE6 only)
Connect a cable from your power
supply to the header labelled JP54
to provide warning of power sup-
ply failure. This warning signal is
passed through the PWR_LED pin
on JF1 to provide indication of a
power failure on the chassis.
This feature is only available when
using Supermicro power supplies.
See the table on the right for pin
definitions.
SLED1 (SCSI LED)
Indicator
The SLED connector is used to
provide an LED indication of SCSI
activity. See the table on the right
for pin definitions.
U n ive rs a l S e ria l B u s P in D e fin itio n s
U S B 0
P in
N umber
1
2
3
4
5
N umber
You
P o w e r S u p p ly F a il H e a d e r P in D e fin itio n s
P in
N umber
N umber
2-12
U S B 1
P in
D efinition N umber D efinition
+5V 1
P 0- 2
P 0+ 3
G round 4 G round
N /A 5
W a k e -O n -L A N P in
D e fin itio n s (W O L )
P in
D efinition
1 +5V S tandby
2 G round
3 W ake-up
(J P 5 4 )
D efinitio n
1 P /S 1 F a il S ignal
2 P /S 2 F a il S ignal
3 P /S 3 F a il S ignal
4 R eset (from M B )
S C S I L E D P in D e fin itio n s
(S L E D 1 )
P in
D efinition
1 P ositive
2 N egative
3 N egative
4 P ositive
+5V
P 0-
P 0+
K ey
