S
UPER P3TDE6/P3TDER User's Manual
2-5

Connecting Cables

Power Supply Connector

P3TDE6 20-pin connector:
After you have installed the
motherboard, memory and PCI
cards, you are ready to connect
the cables. For the P3TDE6, at-
tach an ATX power supply cable
to either ATX#1
PWR_SEC is used only when you
have dual CPUs. See the table on
the right for pin definitions.
P3TDER 24-pin connector:
The power supply connector on
the P3TDER
(Superset ATX)
tion, however it also supports a
20-pin PS connector. Make sure
that the orientation of the PS con-
nector is correct.
on the right for pin definitions.

Power LED

The Power LED connection is lo-
cated on JF1/JF2.
table on the right for P3TDE6 JF1
or page 2-7 for JF1/JF2 pin defini-
tions.

IDE/HDD LED

The IDE/HDD (Hard Drive) LED con-
nection is located on JF1/JF2. At-
tach the IDE hard drive LED cable
to the correct pins to display disk
activity. Refer to the table on the
right for P3TDE6 JF1 or page 2-7
for JF1/JF2 pin definitions.
or ATX#2.
meets the SSI
24-pin specifica-
See the table
Refer to the
2-8
A T X P o w e r S u p p ly 2 0 -p in C o n n e c to r
P in D e fin itio n s (P 3 T D E 6 )
P in N um ber D efinition P in N um ber D efinition
1 3.3V
2 3.3V 3
3 G round
4 5V
5 G round
6 5V
7 G round
8 P W -O K
9 5V S B
10 12V
AT X Pow er Supply 24-pin Connector
Pin Definitions (P3T DER)
Pin Number Definition
Pin Number Definition
13 +3.3V
14 -12V
15 COM
16 PS_ON#
17 COM
18 COM
19 COM
20 Res(NC)
21 +5V
22 +5V
23 +5V
24 COM
P W R _ L E D P in D e fin itio n s
(J F 1 )
P in
N umber D efinition
1
3
5
ID E _ L E D P in
D e fin itio n s
(J F 1 )
P in
N umber
7
9
11 3.3V
12 -12V
13 G round
14 P S -O N
15 G round
16 G round
17 G round
18 -5V
19 5V
20 5V
1 +3.3V
2 +3.3V
3 COM
4 +5V
5 COM
6 +5V
7 COM
8 PW R_OK
9 5VSB
10 +12V
11 +12V
12 +3.3V
+5V
K ey
G N D
D efinition
+5V
H D A ctive
