UPER P3TDE6/P3TDER User's Manual
2-4

I/OPorts/Control Panel Connectors

The I/O ports are color coded in conformance with the PC 99 specification.
See Figure 2-3 below for the colors and locations of the various I/O ports.
Mouse
(Green)
Keyboard
USB
(Purple)
Ports
Figure 2-3a.
Mouse
(Green)
Keyboard
USB Ports
(Purple)
Figure 2-3b.
Note: On the P3TDER, the COM2 connector is replaced by a VGA connec-
tor. COM2 is a header located near the Ultra160 SCSI channel B header
(JA3) on the motherboard.
Parallel Port
(Burgundy)
COM1
(Turquoise)
I/O Port Locations and Definitions: P3TDE6
Parallel Port (Burgundy)
COM1 Port
(Turquoise)
I/O Port Locations and Definitions: P3TDER
2-6
COM2 LAN (Ethernet)
VGA (Monitor)
LAN1
Port (Blue)
Port
LAN2
