Figure 2-2. Side View of DIMM Installation into Slot
PC100
Notches
To Install: Insert module vertically and press down until it
snaps into place. Pay attention to the notches.
Top View of DIMM Slot
To Remove:
Use your thumbs to gently push near the edge of both ends of
the module. This should release it from the slot.
D I M M
Note: Notches
should align
with the
receptive points
on the slot
DIMM Slot
2-5
Chapter 2: Installation
PC100
Notches
