ACPI/PC 98 Features
• Microsoft OnNow
• Slow blinking LED for suspend state indicator
• Main switch override mechanism
• External modem ring-on
Onboard I/O
• AIC-7899 for dual channel Ultra160 SCSI
• ATI Rage 8 MB Graphics Card (P3TDE6)
• Integrated ATI Rage XL Graphics Controller (P3TDER)
• Intel 82559 for integrated onboard Ethernet
1 Ethernet port (P3TDE6)
2 Ethernet ports (P3TDER)
• 2 EIDE bus master interfaces support Ultra DMA/33 (P3TDE6)
• 2 EIDE bus master interfaces support Ultra DMA/100 (P3TDER)
• 1 floppy port interface (up to 2.88 MB)
• 2 Fast UART 16550A compatible serial ports
• 1 EPP/ECP (Enhanced Parallel Port/Extended Capabilities Port)
• PS/2 mouse and PS/2 keyboard ports
• 2 USB (Universal Serial Bus) ports
Other
• Internal/external modem ring-on
• Recovery from AC power loss control
• Wake-on-LAN (WOL)
CD/Diskette Utilities
• BIOS flash upgrade utility
• Device Drivers
Dimensions
• SUPER P3TDE6
Extended ATX: 12.05" x 13" (306 x 330 mm)
• SUPER P3TDER
Full ATX: 12.05" x 11.475" (306 x 291 mm)
1-11
Chapter 1: Introduction
