UPER P3TDE6/P3TDER User's Manual

Motherboard Features

CPU
• Single or dual Pentium
sors with a 512K L2 cache at front bus speeds of 133 and 100 MHz.
Note: Please refer to the support section of our web site for a complete listing of supported
processors (http://www.supermicro.com/TechSupport.htm). You must use the server version
of the processors mentioned above.
M e m o r y
• Four 168-pin DIMM sockets supporting up to 4 GB of registered ECC
SDRAM
Note: The memory speed must match the front side bus speed being used. (Both 133 or 100
MHz.) Also, memory modules must be installed in pairs (first in the two slots of Bank0, then in
both slots of Bank1, if needed).
Chipset
• ServerWorks ServerSet III HE Super Light
Expansion Slots
P3TDE6:
• Two 64-bit, 66/33 MHz PCI slots
• Four 64-bit, 33 MHz PCI slots
• One 2x/AGP Pro (ATI 8 MB Rage Graphics Card included)
BIOS
®
• 4 Mb AMI
• APM 1.2, DMI 2.1, PCI 2.2, ACPI 1.0, Plug and Play (PnP)
PC Health Monitoring
• Seven onboard voltage monitors for CPU core, chipset voltage, +5V
and +12V
• Fan status monitor with firmware/software on/off control
• Environmental temperature monitor and control
• CPU fan auto-off in sleep mode
• Power-up mode control for recovery from AC power loss
• System overheat LED and control
• System resource alert
®
III FCPGA 500 MHz-1.40 GHz FCPGA proces-
Flash ROM
P3TDER:
• One 64-bit, 66/33 MHz PCI
1-10
