- Page 1 Quick REFERENCE GUIDE N E V E R S T O P E L E V A T I N G Y O U R V E T E X P E R I E N C E.
- Page 2 Dedicated VET Software and Probes Comfort while scanning Easy to Move Quick Start-up Eco-Friendly Widen Connectivity Integrated long-life battery...
-
Page 3: Table Of Contents
Index System Overview ..............4 System Adjustments ............6 - Standby ..............7 Control Panel ..............8 Exam Flow ................9 Peripherals & Connections ..........15... -
Page 4: System Overview
System Overview Monitor Speaker Touch screen ports Speaker Probe holder Cable hangers Handle Orientation lever Lifting lever Pull-out keyboard werty Probe con- nector Connection panels locks (left side) Probe connectors... - Page 5 Monitor arm lock Handle Peripheral plate Power cord hook Main plug Main switch Brake Brake...
-
Page 6: System Adjustments
System Adjustments 180° Control Panel rotation 26 cm 45° Sliding alphanumeric keyboard Height adjustment Fully orientable articulated arm... -
Page 7: On/Off - Standby
ON/OFF - Standby Connect the system to the mains Switch on with the mains switch button Press the O button Boot-up time 25 sec. stand-by <45 sec. 15 sec. 15 sec. -
Page 8: Control Panel
Control Panel Navigation bar to know in Encoders which exam phase you are Speaker Ports Menu Touch™ 1 2 3 4 5 6 Mode buttons Annotations Bodymark Measure Encoders and trackball 4 configurable buttons... -
Page 9: Exam Flow
Exam Flow Inserting Patient and Operator ID... - Page 10 Selecting Probe, Application and Preset...
- Page 11 Real-time scanning Two level menu Resolu on Contrast Smooth Penetra on Sharp Sharp imaging optimization parameters adjusted in 3 swipes...
- Page 12 Visualizing archived images (multimodality) on the main screen or on the touchscreen...
- Page 13 Visualizing all the measurements Report Preview...
- Page 14 Saving in Native, DICOM or Multimedia formats on Local Archive, USB, CD/DVD or Network...
-
Page 15: Peripherals & Connections
Peripherals & Connections... - Page 16 Manufactured by ESAOTE S.p.A Via Enrico Melen, 77 16152 Genova, ITALY Phone +39 010 6547 1 - Fax +39 010 6547 275 info@esaote.com - www.esaote.com...
