A+ SERVER 2042G-TRF/6RF User's Manual
USB Wake-Up
JPUSB1 jumper allows you to "wake up"
the system by pressing a key on the USB
keyboard or by clicking the USB mouse of
your system. These jumpers are used in
conjunction with the USB Wake-Up function
in the BIOS. See the table on the right for
jumper settings and jumper connections. (the
default is Enabled)
BMC Jumper
JPB1 is used to enable or disable theBMC
(Baseboard Management Control) Chip and
the onboard IPMI connection.This jumper is
used together with the IPMI settings in the
BIOS. The default position is on pins 1 and
2 to Enable BMC. See the table on the right
for jumper settings.
Wake-Up Enable (JPUSB1)
Jumper Settings
Jumper Setting
Pins 1-2
Pins 2-3
BMC Jumper Enable (JPB1)
Jumper Settings
Jumper Setting
Pins 1-2
Pins 2-3
5-22
Backpanel USB
Defi nition
Enabled (default)
Disabled
Defi nition
Enabled (default)
Disabled
