M2-W6510-32C Switch
Hardware Installation and Reference Guide
Version V1.0
copyright © 2023 Micas

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M2-W6510-32C and is the answer not in the manual?

Questions and answers

Summary of Contents for Micas M2-W6510-32C

  • Page 1 M2-W6510-32C Switch Hardware Installation and Reference Guide Version V1.0 copyright © 2023 Micas...
  • Page 2: Copyright Statement

    This document is provided “as is”. The contents of this document are subject to change without any notice. Please obtain the latest information through the Micas Networks website. Micas Networks endeavors to ensure content accuracy and will not shoulder any responsibility for losses and damages caused due to content omissions, inaccuracies or errors.
  • Page 3 Appendix A "Connector and Connection Media"  Appendix B “Lightening Protection”  Appendix C “Cabling Recommendations in Installation”  Appendix D “Site Selection”  Obtaining Technical Assistance  Micas Networks Website: https://www.micasnetworks.com/  Technical Support Website: https://www.micasnetworks.com/support  Case Portal: https://www.micasnetworks.com/case  Community: https://www.micasnetworks.com/company/contact...
  • Page 4: Symbol Conventions

    Symbol Conventions Means reader take note. Notes contain helpful suggestions or references. Means reader be careful. In this situation, you might do something that could result in equipment damage or loss of data.
  • Page 5: Product Overview

    M2-W6510-32C switch is data-center-oriented high density 50G/100G access switch, providing 25G/50G/100G access, low latency, and complete data center features. M2-W6510-32C switch provides 32 100G ports. Each 100G port supports 2x50G mode. M2-W6510-32C switch can be used to compose a high-performance and high-reliability data center network.
  • Page 6: Product Appearance

    442 mm x 560 mm x 44 mm, 1RU (17.40 in. x 22.05 in. x 1.73 in.) (L x W x H) M2-W6510-32C switch is a class A product. In a domestic environment, this product may cause radio interference in which case the user may be required to take adequate measures.
  • Page 7: Front Panel

    Hardware Installation and Reference Guide Product Overview Front Panel Figure 1- 2 Front Panel of the W6510-32C Notes: USB2.0 Port SYS Indicator Console Port Power Indicator MGMT Port Fan Indicator QSFP+ Port Indicator Asset Tag QSFP+ Port The W6510-32C supports 100G QSFP28 module. Rear Panel Figure 1- 3 Rear Panel of the W6510-32C - 5 -...
  • Page 8: Asset Tag

    To protect the data and avoid device damage, use qualified USB flash disks of good brands. At the same time, the local USB port is compatible with most of the USB controllers except some USB flash disks. The M2-W6510-32C switch supports debugging, configuration, maintenance, management and host software uploading of Console ports.
  • Page 9 Hardware Installation and Reference Guide Product Overview  QSFP28 port: There are 32 100G QSFP28 ports, which support optical modules and DAC copper cables. These ports can also work in 2x50G or 4x25G mode. Indicator Indicator on the Panel Indicator Panel Identification Status Meaning...
  • Page 10: Power Supply

    -F as well. Heat Dissipation The working temperature of the M2-W6510-32C switch is 0°C to 45°C (32°F to 113°F), and the heat dissipation design needs to ensure the stability, safety and maintainability in such environment. The M2-W6510-32C switch adopts fan ventilation and forced convection to ensure the device can work normally in specified environment.
  • Page 11 Hardware Installation and Reference Guide Product Overview Maintain a minimum clearance of 20 cm around the switch for ventilation. It requires at least three fan modules to work normally. Install a blank panel to the empty slot to prevent dust from entering the switch.
  • Page 12: Preparation Before Installation

    Hardware Installation and Reference Guide Product Overview 2 Preparation before Installation 2.1 Safety Precautions To avoid body injury and device damage, please carefully read the safety precautions before you install the M2- W6510-32C. The following safety precautions do not cover all possible dangers. 2.1.1 Installation Safety ...
  • Page 13: Laser Safety

    Do not let any clothes touch a circuit board. An antistatic wrist strap can only prevent human static electricity from damaging the circuit board, but cannot prevent any static electricity on clothes. 2.1.5 Laser Safety Among the modules supported by the M2-W6510-32C, there are a great number of optical modules that are Class I laser product. Precautions: ...
  • Page 14: Ventilation Requirements

     Be sure that the cabinet is firm enough to bear the weight of the M2-W6510-32C and its installation accessories.  Be sure that the dimensions of the cabinet is appropriate for installation of the M2-W6510-32C that can reserve a certain space for the front, back, left and right panels for heat dissipation.
  • Page 15: System Grounding Requirements

    2.2.5 System Grounding Requirements A good grounding system is the basis for the stable and reliable operation of the M2-W6510-32C. It is the key to prevent lightning stroke and resist interference. Please carefully check the grounding conditions on the installation site according to the grounding requirements, and perform grounding properly as needed.
  • Page 16: Emi Consideration

    Hardware Installation and Reference Guide Preparation before Installation 2.2.6 EMI Consideration Various interference sources, from either outside or inside the device or application system, affect the system in the conductive ways such as capacitive coupling, inductive coupling, and electromagnetic radiation. There are two types of electromagnetic interferences: radiated interference and conducted interference, depending on the type of the propagation path.
  • Page 17: Unpacking And Checking

    Hardware Installation and Reference Guide Preparation before Installation The M2-W6510-32C switch is not shipped with a tool kit. You need to prepare a tool kit by yourself. 2.5 Unpacking and Checking Goods Checklist Chassis, Yellow/green grounding cables; Quick installation guide; Packing list, Pouched...
  • Page 18: Product Installation

    Preparation before Installation 3 Product Installation The M2-W6510-32C Ethernet switch must be used and fixed in the room. Make sure you have carefully read part 2, and be sure that the requirements set forth in part 2 have been met.
  • Page 19: Cabinet Installation

    Precautions Before mounting M2-W6510-32C into the cabinet, first verify that the front and back brackets of the cabinet are at the right locations. If the bracket is too far forward, the front panel of the equipment may be too close to the front door, so that the front door cannot be closed when the equipment is connected with network cables and pigtail fibers.
  • Page 20: Mounting The Switch In A Four-Post Rack

    Hardware Installation and Reference Guide Product Installation you should reserve space of at least 10mm between the front panel of the equipment and that of the cabinet after installation. Before mounting into a cabinet, you need to make sure the following conditions are met: ...
  • Page 21: Installing And Removing A Fan Module

    Hardware Installation and Reference Guide Product Installation Sliding the Switch into the Rack Slide the rack-mount guides onto the guide rails (noted by ① in Figure 3) , and then gently slide the switch all the way into the rack (noted by ②). Securing the Switch to the Rack Secure the switch to the rack posts using the quick-release thumb screws (see Figure 4).
  • Page 22: Installing A Power Module

    Hardware Installation and Reference Guide Product Installation Figure 3- 5 Removing a Fan Module Pull out the fan module slowly. Install a filler panel on the location where a fan module is removed to ensure normal ventilation and dissipation and avoid dust in the chassis. 3.6 Installing and Removing a Power Module Wear anti-static gloves before the following operations.
  • Page 23: Installing Power Cord Retainer

    Hardware Installation and Reference Guide Product Installation Insert the power module smoothly. Please pay attention to the direction of the power panel to avoid wrong insertion. If it is difficult or even impossible to insert the module, pull out the module, make sure the Expansion module and guide rail are well aligned, and then insert the module again.
  • Page 24: Removing A Power Module

    Hardware Installation and Reference Guide Product Installation Check whether the power cord container is correctly installed. If you can remove the strap without pressing buckle A, the strap may be installed incorrectly. Try the other side of the strap. Attach the power cord container to the installation hole of the power module. Plug the power cord into the connector.
  • Page 25: Simple Connection Steps

    3.7 Grounding A PGND is installed on the back of M2-W6510-32C. First connect the PGND to the grounding terminal of the cabinet and then connect the grounding terminal to the grounding bar of the equipment room.
  • Page 26: Connecting The External Interface Cables

    Hardware Installation and Reference Guide Product Installation Connect the RJ45 connector to the Console interface of the management engine module with shipped console cable, and connect the DB9 connector to the NM or control terminal. By default, the baud rate is 115200, data bit 8, parity check none, stop bit 1, and flow control none. 3.9 Connecting the External Interface Cables Precautions ...
  • Page 27: Verifying The Power Supply

    Hardware Installation and Reference Guide Product Installation  Verify that the cabinet has been fastened completely, and does not move or tilt.  Verify that the equipment has been installed in the cabinet, and all the cables have been fastened to the cabinet. ...
  • Page 28: System Debugging

    Hardware Installation and Reference Guide Product Installation 4 System Debugging 4.1 Establishing the Configuration Environment Establishing the Configuration Environment Connect the PC to the console port of the switch through the console cable, as shown in Figure 4-1. Figure 4- 1 Schematic diagram of the configuration environment Connecting the Console Cable Connect one end of the DB-9 jack of the console cable to the serial port of the PC.
  • Page 29 Hardware Installation and Reference Guide Product Installation Figure 4- 2 Enter the name of the new connection and click OK. A window appears as shown in Figure 4-3. In the column of Connect Using field, select the serial port you want to use. Figure 4- 3 After the serial port is selected, please click OK.
  • Page 30: Power-On Startup

    Hardware Installation and Reference Guide System Debugging After the serial port parameters are set, click OK to enter hyper terminal window. 4.2 Power-on Startup Checking before Power-on  Check if the switch is fully grounded.  Check if the fan module and the power module are correctly installed. ...
  • Page 31: Monitoring And Maintenance

    5 Monitoring and Maintenance 5.1 Monitoring Indicator When the M2-W6510-32C is running, users can monitor the status of host and each module by inspecting corresponding indicators.  When the Status indicator is red, it means the system has a fault, in which case you can determine and eliminate the fault by viewing with the management software.
  • Page 32: Power Supply Maintenance

    Replacing Lithium Battery The built-in lithium batteries can support the real time clock of the M2-W6510-32C switch without external power supply. Please contact the technical support representatives of Micas Networks for replacing lithium batteries. Technical staff of Micas Networks will replace the battery of the same model.
  • Page 33: Troubleshooting

    Check the indicators on the device and the modules Check the connection of the serial ports and its parameters Check the connection of the fibers or cables of various ports Contact Technical Support of Micas Networks for hardware problems - 31 -...
  • Page 34: Common Troubleshooting Procedures

    Check whether the configuration of the serial port on the hyper terminal is the same as that described in M2-W6510-32C Software Configuration Guide. If not, modify the serial port configuration parameters. If there is still no serial port printed information, please contact Micas Customer Service Department for technical support.
  • Page 35 Check whether the module is inserted correctly. If the newly inserted module still cannot be powered on even though the checking is ok, please contact Micas Customer Service Department for technical support. Fault 7: The link cannot be set up between fiber interfaces.
  • Page 36: Appendix A Connectors And Connection Media

    Hardware Installation and Reference Guide Troubleshooting Appendix A Connectors and Connection Media 10GBASE-T/1000BASE-T/100BASE-TX Port 10GBASE-T/1000BASE-T/100BASE-TX is a port that supports self-adaptation of three rates, and automatic MDI/MDIX Crossover at these three rates. 10GBASE-T complies with IEEE 802.3an standard, and the supported cables and cabling distances are listed in the following table.
  • Page 37: Fiber Connection

    Hardware Installation and Reference Guide Troubleshooting Figure A-1 Four twisted pairs of the 1000BASE-T In addition to the above cables, the 100BASE-TX can use up to 100m of 100-ohm CAT5. Figure A-2 shows the definition of pin signal concerning the 100BASE-TX: Figure A-2 Definition of pin signal concerning the 100BASE-TX Socket Plug...
  • Page 38: Appendix B Lightning Protection

    Hardware Installation and Reference Guide Appendix A Connectors and Connection Media Appendix B Lightning Protection Installing AC Power Arrester (lightning protection cable row) The external lightning protection cable row should be used on the AC power port to prevent the switch from being struck by lightning when the AC power cord is introduced from the outdoor and directly connected to the power port of the switch.
  • Page 39 Hardware Installation and Reference Guide Appendix A Connectors and Connection Media Installing the Ethernet Port Arrester During the switch usage, the Ethernet port arrester should be connected to the switch to prevent the switch damage by lightning before the outdoor network cable connects to the switch . Tools: Cross or straight screwdriver, Multimeter, Diagonal pliers Installation Steps: Tear one side of the protection paper for the double-sided adhesive tape and paste the tape to the framework of the...
  • Page 40 Hardware Installation and Reference Guide Appendix B Lightning Protection You should pay attention to the following conditions during the actual installation to avoid influencing the performance of the Ethernet port arrester:  Reversed direction of the arrester installation. You shall connect the external network cable to the “IN” end and connect the switch Ethernet port to the “OUT”...
  • Page 41: Appendix C Cabling Recommendations In Installation

    Hardware Installation and Reference Guide Appendix B Lightning Protection Appendix C Cabling Recommendations in Installation When the switches are installed in standard 19-inch cabinets, the cables are tied in the binding rack on the cabinet by the cable management bracket, and top cabling or bottom cabling is adopted according to the actual situation in the equipment room.
  • Page 42 Hardware Installation and Reference Guide Appendix B Lightning Protection  Cables of different types (such as power cords, signal cables, and grounding cables) should be separated in cabling and bundling and no mixed bundling is allowed. When they are close, crossover cabling can be adopted. In the case of parallel cabling, power cords and signal cables should maintain a distance not less than 30 mm.
  • Page 43 Hardware Installation and Reference Guide Appendix C Cabling Recommendations in Installation  Cables not to be assembled or remaining parts of cables should be folded and placed in a proper position of the cabinet or cabling slot. The proper position indicates a position that will not affect device running or cause device damage or cable damage during commissioning.
  • Page 44 Hardware Installation and Reference Guide Appendix C Cabling Recommendations in Installation Figure D-4 Cable fastening  The hard power cord should be fastened at the terminal connection area to prevent stress on terminal connection and cable.  Do not use self-tapping screws to fasten terminals. ...
  • Page 45: Appendix D Site Selection

    Hardware Installation and Reference Guide Appendix C Cabling Recommendations in Installation Appendix D Site Selection  The machine room should be at least 5km away from the heavy pollution source such as the smelter, coal mine and thermal power plant, 3.7km away from the medium pollution source such as the chemical industry, rubber industry and electroplating industry, and 2km away from the light pollution source such as the food manufacturer and leather plant.
